Configuring the Unit

The IOLAN SCG features several different configuration methods (i.e. HTTP, Telnet,
SNMP) as well as an external Windows based Utility (DeviceManager). For the
most up to date documentation on any IOLAN SCG feature refer to the Perle
website at www.perle.com

Initial Setup for the IOLAN SCG

1. Connect power to the IOLAN SCG.
2. Set an IPv4 address from the Front Panel.
3. Connect an Ethernet cable to the IOLAN SCG, then to your network.
4. Connect Serial Devices.

Connecting the Power

When the power is connected to the IOLAN, the System Ready LED will cycle
through several sequences and will end in a solid green once the unit is fully
booted and ready to be configured. If the LED is not solid green after two minutes,
see the IOLAN SCG Hardware Installation Guide-Enhanced Models for more
information.

Setting an IPv4 address through the Front Panel

To enter IPv4 setup information:
1. From the Main Menu (IOLAN name, date and time), press the Down arrow to
scroll to Configuration, now press the Center button for Enter.
2. Press the Down arrow.
The display should read Eth1 DHCP : OFF
3. Press the Down arrow again.
The display should now read:
Eth1 IPv4
000.000.000.000
4. Press the Center button for Enter to go into Edit mode. A cursor will flash
under the first zero (0) in the IP address.
5. To enter values:
Use the left or right arrow to move the cursor to the left or right
position.
IOLAN SCG Quick Start Guide – Expandable Models
3
