Page 1 833IS User Guide 5500116-10...
Page 2: Important Safety Notice
All other trademarks mentioned in this document are the property of their respective owners. Mention of third party programs is for information purposes only constitutes neither and endorsement nor a recommendation. Perle Systems Limited assumes no responsibility with regard to the performance of these products.
Page 3 Equipment must be used with an appropriately approved power supply cordset. Caution Changes or modifications to a Perle product not expressly approved by Perle Systems Limited may void the users authority to operate the equipment.
Page 4 European Community (EC) Mark of Conformity This product is in conformity with the protection requirements of EC Council Directive 89/ 336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. Perle cannot accept responsibility for any failure to satisfy the protection requirements resulting from non-recommended modification of the product.
Page 5: Industry Canada Requirements
If you experience trouble with this equipment, please contact the Perle Technical Assistance Center at the following address for information about obtaining service; Perle Systems Limited 60 Renfrew Drive Markham, Ontario L3R 0E1 1-800-33 PERLE All repairs should only be performed by Perle Systems Limited or an authorized agent of Perle .
Page 6: Federal Communications Commission (Fcc) Requirements
60 Renfrew Drive Markham, Ontario L3R 0E1 1-800-33 PERLE All repairs should only be performed by Perle Systems Limited or an authorized agent of Perle . When ordering service from the telephone company, you may need to provide the following information;...
Page 7: About This Book
Novice Users can rely on the Guide to provide them with simple and easy to understand steps. The extensive indexing, cross-referencing, illustrations and full glossary are not only intended to help set up the 833IS, but also realize its full potential. Take advantage of the Quick Install Chapter to get an overview of what’s ahead.
Page 8 Chapter 2: Site Preparation: This chapter provides a complete description of the Electrical, Environmental and Cable Requirements of the 833IS. Chapter 3: Setting Up and Installing the Perle 833IS: Familiarize yourself with the unit’s physical appearance as well as the basic functions. Make the LAN connections and verify its correct operation.
Page 9 Cards, protocols or users. Provides information about Security, Groups, Servers, and more. Management Chapter 10: Managing the Perle 833IS: Intended for experienced users. Learn about Manager Statistics, Front Panel, and the Event Log. Also learn about upgrading your software. Appendix 1: Menu Descriptions: Gives the user a quick overview of the Front Panel Menu Descriptions in table format.
Page 10 What’s in the Guide Perle 833IS User Guide...
Page 11: Table Of Contents
LAN-to-LAN... 3 Section 1: Installation... Chapter 1: Quick Installation Overview... Preparing the Site... 7 Setting up and Installing the 833IS Hardware... 8 Setting up the LAN Connection... 9 Configuring the 833IS... 9 Attaching to the Telephone Network... 10 Verifying Correct Operation... 10 Chapter 2: Site Preparation...
Page 12 Off-Line Configuration... 57 Loading Firmware... 58 Download via Manager... 58 Download via TFTP... 59 Section 2: Configuration... Chapter 5: Configuring the Perle 833IS... How the 833IS Works... 63 Dial-In Access... 63 Dial-Out Access... 66 Configuration Overview... 67 Using Configuration Files... 68 Creating...
Page 13 SNMP... 189 SNMP Configuration... 190 Community and Community Tables... 191 Logging Configuration... 192 Section 3: Management... Chapter 10: Managing the Perle 833IS... 833IS Manager Statistics ... 199 Viewing Statistics... 199 Accessing Interface Statistics ... 202 Ethernet Interface... 202 Token Ring Interface... 203 ISDN BRI Line Interface...
Page 14 Accounting Messages... 282 Appendix 5: Cisco Configuration Mode... Introduction to Cisco Configuration Mode... 285 Overview of 833IS... 286 Differences Between 833IS and Cisco Products... 288 Command Overview... 291 Installation and Configuration of 833IS with Cisco Configuration Mode... 291 Monitoring the 833IS ... 296 Differences between 833IS Manager and Cisco Configuration Mode...
Page 15 Glossary... Index... Perle 833IS User Guide...
Page 16 Perle 833IS User Guide...
Page 17: Introduction
Modem and lines as Dial-Out modems. To the PC application, the PerleDSP Modem and line attached to the 833IS look like a modem connected to the PC COM port. Most PC applications that require a modem are supported. With appropriate software, users can connect to a BBS, Internet provider, or any other service accessible by the telephone network.
Page 18 Token authentication access systems such as Security Dynamics SecurID and Axent can work with the 833IS to meet high security requirements. The internal database of the 833IS supports up to 500 users, each with their own password. Fixed Callback and Roaming Callback are supported to meet both security requirements and toll management.
Page 19: Lan-To-Lan
Router. The Virtual Connection feature can be used to provide cost effective connections between two LANs. Expandable You can size the hardware of the 833IS to meet the needs of your business. The 833IS supports the addition of an expansion card. As your remote access needs System grow, this card can be used to address the added demand.
Page 20 High Reliability Design High Reliability There are no moving storage devices such as floppy or hard drives in the 833IS. All program storage is on Flash Read Only Memory (ROM). Design Perle 833IS User Guide...
Page 21: Section 1: Installation
Section 1: Installation Chapter 1: Quick Installation Overview Chapter 2: Site Preparation Chapter 3: Setting Up and Installing Chapter 4: Using the Perle 833IS Manager Perle 833IS User Guide...
Page 22 Perle 833IS User Guide...
Page 23: Chapter 1: Quick Installation Overview
Attaching the 833IS to the Telephone Network Verifying Correct Operation of the 833IS The 833IS can be set up either using the 833IS Windows Based Manager or by following a "Cisco mode" setup procedure. The Quick Installation Overview will cover installation via the 833IS Manager. For information on Cisco mode installation and operation, please refer to "Appendix 5: Cisco Configuration Mode".
Page 24: Setting Up And Installing The 833Is Hardware
,W LV QRW UH.RPPHQGHG WKDW \RX DWWD.K WKH /$1 RU WKH WHOHSKRQH QHWZRUN ZLULQJ DW WKLV WLPH ,I WKH 833IS LV SRZHUHG XS ZLWK D .RQILJXUDWLRQ WKDW GRHV QRW PDW.K WKH .DUULHU©V UHTXLUHPHQWV HUURUV .RXOG EH JHQHUDWHG DW WKH &HQWUDO 2IIL.H 6RPH .DUULHUV ZLOO GLVDEOH RU GLV.RQQH.W WKH VHUYL.H LI H[.HVVLYH HUURUV DUH HQ.RXQWHUHG...
Page 25: Setting Up The Lan Connection
Some parameters may have to be set from the Front Panel to allow the Manager to connect to the 833IS. Depending on the LAN type and network protocol used by the Manager (IP or IPX), this step may not be required. See “Set up the basic parameters”...
Page 26: Attaching To The Telephone Network
Attaching to the Telephone Network Attaching to the Telephone Network See “Attaching to the Telephone Network” on page 42. Now that the 833IS is configured, the telephone cables can be attached to the unit. To attach the telephone line: 1. Power down the 833IS.
Page 27: Chapter 2: Site Preparation
Site Preparation Overview The following is a checklist of recommended tasks that should be completed before installing the 833IS. Some may not apply to your installation, or you may wish to add new items. Identify and contact the following individuals:...
Page 28: Electrical Requirements
Electrical Requirements Electrical Specification The 833IS should not share electrical circuits with equipment that can cause electrical noise and interference. For your safety, you must connect equipment only to a properly wired and grounded outlet. An improperly wired outlet can place hazardous voltage on the accessible metal parts of the unit.
Page 29: Environmental Requirements
Sufficient clearances must be maintained at both sides of the unit to allow proper air flow to the internal fans. For rack mounting, the 833IS requires 1.5 rack mount spaces (i.e. the 833IS height is 1.5U). It is not necessary to leave empty spaces above or below the unit in the rack.
Page 30: Cable Planning And Requirements
Cable Planning and Requirements LAN Cabling Depending on the type of system card inserted into the 833IS, the unit can support either an Ethernet or a Token Ring interface. The type of LAN cabling you will need will depend on the following factors: The type of LAN.
Page 31 Category 3, 4 and 5 UTP cable is acceptable. For best results, Category 4 and 5 cable is recommended. Cables are attached to a 10Base-T hub in a star configuration. Maximum length from 833IS to hub is 100m (328 ft.). 10 Base-T Hub Perle 833IS User Guide...
Page 32 If you are using STP cable, make sure that all cables and connection points are shielded. Cables are attached to a 100Base-TX hub in a star configuration. Maximum length from 833IS to hub is 100m (328 ft.). There are other cabling types that are available for Ethernet: 10Base5 (AUI).
Page 33: Token Ring
Chapter 2: Site Preparation Token Ring The following physical interfaces are available for Token Ring: STP (Shielded Twisted Pair). UTP (Unshielded Twisted Pair). Token Ring Interfaces/LAN Cable Connection Perle 833IS User Guide...
Page 34 Terminated with RJ-45 plugs. Cables are attached to a MAU in a star configuration. Type 1 or Type 3 MAU Token Ring Network Perle 833IS User Guide Type 1, 2, 6 or 9 STP (Type 1 MAU) Category 3, 4, 5...
Page 35: Telephony Cabling
Demarc. You are responsible for the wiring from the Demarc to the 833IS. Depending on the carrier, the Demarc may either be brought to the 833IS or it may terminate some considerable distance from the unit. You will need to work with the carrier in advance to determine where the ISDN BRI service will be brought, and if necessary, arrange for the wiring from the Demarc to the 833IS.
Page 36 Enable 100 termination - Jumper block To disable termination, remove the jumpers. Note that a BRI U interface has no user adjustable termination. Disable 100 termination - Jumper block Perle 833IS User Guide...
Page 37: Chapter 3: Setting Up And Installing
Power Cord ISDN Cables Documentation Package Software Package Rack Mount The Rack Mount Kit allows you to mount the 833IS into a standard 19" equipment rack. Power Cord The appropriate power cord for your location is provided. ISDN Cables Standard UTP cables with an RJ-45 connector used to connect the ISDN interfaces to the termination point provided by the service provider.
Page 38: Unpacking The 833Is
2. Remove Accessory Tray containing the Power Cords. 3. Remove the Documentation and Diskette packets from the side cavity between the unit and outer carton. 4. Lift the 833IS out of the shipping carton. 5. Remove the packing material. Perle 833IS User Guide...
Page 39: Familiarize Yourself With The Unit
Familiarize Yourself with the Unit 833IS Views The diagrams below show the major hardware components of the 833IS. Back Panel Front Panel The card(s) in your unit may be slightly different, depending on the type of card(s) you purchased. Slot 2 may not be occupied on your unit.
Page 40: 833Is Chassis Description
Start selected function or confirm entered data. Escape. Returns to the previous submenu or cancels the current command. Description Indicates that the 833IS is powered up. Blinks continuously when the 833IS is operational. Blinking will start after System initialization is complete. Perle 833IS User Guide...
Page 41: Feature Cards
Feature Cards The 833IS can hold up to two Feature cards. The card in Slot 1 is called the System card, and the card in Slot 2 is called the Expansion card. The system card must be present in the 833IS, but the Expansion card is optional. Both cards come with different interfaces as described below.
Page 42: Expansion Card
Feature Cards Expansion Card The 833IS is an expandable unit and therefore provides for the insertion of an optional expansion card in slot 2. The following expansion cards are currently supported: Card name BRIU56 BRIS56 BRIU BRIS These cards allow the user to double the number of ISDN ports as well as doubling the number of modems available in the system.
Page 43: Serial Number Label
This switch is used to turn off all power to the unit. When the power is cycled, the unit will restart its power up sequence. The 833IS can maintain its program and log information event when no power is applied to the unit.
Page 44: Attaching The Rack Mount
Assembling the Hardware Attaching the Rack The Rack Mount Kit provided can be used if you wish to install the 833IS in a Mount standard 19" equipment rack. Use the screws included in the Rack Mount Kit to attach the Rack Mount brackets to the 833IS.
Page 45: Factory Default Mode
"Factory Default Mode" on page 235. Once the 833IS has Firmware and is fully configured, the unit is in Normal mode. The unit can be restored to Factory mode from the Manager (“Configure Menu” on page 53) or Front Panel (“Control”...
Page 46: Token Ring
3. Power on the 833IS. Token Ring If you are attaching the 833IS to a Token Ring network, you will need either: A UTP cable (Type 3 wiring), or A STP (Shielded Twisted Pair) adapter cable (DB9 to either Type 1 or Type 6 Token Ring wiring).
Page 47: Setting Up The 833Is Lan Connection
If you are using the Cisco mode setup procedure, follow the steps for an IP connection. IPX is not supported for the Cisco mode setup. The 833IS can be connected to the LAN via an Ethernet or Token Ring connection depending on the specific system card purchased with the unit.
Page 48: Ipx Connection To The Manager
No configuration is required for the Manager to communicate with a 833IS using the Manager IPX. By listening to the traffic on the LAN, the 833IS learns about all the networks that it can reach. It automatically discovers the IPX network numbers for the networks and all supported frame types on the network.
Page 49: Set Up The Basic Parameters
Management PC is connected. Set up the basic The LAN cable should not be connected to the 833IS at this time. Power up the parameters 833IS by turning on the power switch at the rear. The power LED should be lit.
Page 50 Setting up the 833IS LAN Connection When editing a field, the keys behave as follows: Left Selects a menu. Position the cursor to the correct editing position. View selections within a menu or change values at the cursor position. Enter Accept changes and exit edit mode.
Page 51 For these units, you can use this panel to override the auto port detect feature of the 833IS. Once set, the 833IS will no longer try to auto detect this port, even after a restart of the unit. The only way to re-enable the auto detect feature is via this menu item.
Page 52 Note: if the 833IS is powered off before the 833IS Firmware is downloaded this manager setup configuration will have to be repeated. If you are using an IP address server, determine the MAC address of the 833IS by doing the following:...
Page 53: Verifying Connection
Verifying Connection On the LAN card, there is a Link LED which flashes to indicate network activity. If this LED does not flash, check the physical cabling between the 833IS LAN adapter and the Hub or MAU (Multistation Access Unit).
Page 54: Manager Status
Only displayed for an Ethernet interface. Displays the physical port being used to communicate to the hub. Valid options are: RJ45, BNC. The BNC option is valid only for versions of the 833IS that contain a BNC port. Speed Display the operating speed of the interface. For Token Ring the valid options are 4Mbps or 16Mbps.
Page 55: Ip Status
BOOTP, RARP, Configured, or None. If None is displayed, it indicates that the 833IS could not acquire an IP address or the IP protocol is not used. If you were using an Address server and Default is displayed, check the setup of the Address server.
Page 56: Ipx Status
IPX broadcast messages. # RIP Entries Displays the number of entries within the 833IS's IPX RIP table. There will be one RIP entry for each IPX router detected. Note that a Novell file server defines an "internal" network within the server itself, so there will be a RIP entry for each Novell file server.
Page 57: Configuring The 833Is
Set up the type of security that you wish to use to control remote access to your network. See “Security” on page 169. If you select "User Database" as your method of security, add users to the 833IS's user database and set their access rights and capabilities. See “Chapter 8: Configuring the User Database”...
Page 58: Attaching To The Telephone Network
Firmware and "Section 2: Configuration" for instructions on configuring the 833IS, You can now verify that remote users can dial into the 833IS and access the services. Also, you can install Perle Dial-Out software on LAN PCs, and verify that the Dial-Out is functioning correctly.
Page 59: Chapter 4: Using The Perle 833Is Manager
Downloads Firmware to an 833IS. Creates Configuration Files to be downloaded to an 833IS. Will upload a configuration file from an 833IS. This uploaded file can be modified, saved on the Manager PC, or downloaded to another 833IS. Displays Statistics for an 833IS.
Page 60: System Requirements
System Requirements System Requirements The minimum PC requirements for the 833IS Manager software are: Hard drive with at least 4 MB free storage space. Windows 95 or 98, or Windows NT 4.0 workstation, or Windows 2000 Windows compatible mouse. LAN Connection The Manager software requires IP or IPX network facilities to be available on the Manager PC.
Page 61: Installing The Manager Software
No configuration is required for the Manager to communicate with a 833IS using IPX. By listening to the traffic on the LAN, the 833IS learns about all the networks that it can reach. It automatically discovers the IPX network numbers and all supported frame types on the network.
Page 62 Installing the Manager Software 833IS to do this. The MAC address can be obtained from the Front Panel. You can configure an IP address from the Front Panel. IP Subnet Mask An IP network can be partitioned into subnetworks, or subnets. For IP networks on a single LAN segment, there are likely no subnets defined.
Page 63: Connecting To The Server
833IS Servers on the network. Using IP The IP address of the 833IS needs to be defined to the Manager. To do this, perform the following steps: 1. Start the Manager. The following screen will be displayed: 2.
Page 64: Troubleshooting
4. Enter the IP address of the Server in the IP Address field. 5. Click on Add. The 833IS is now defined to the Manager. When the Manager connects via IP, it will check for the defined Servers. If you are using Domain Name Servers (DNS) on the Manager PC, you can enter the name of the 833IS.
Page 65: Completing The Connection
When the 833IS Manager connects to the network, it automatically locates all 833IS Connection IPX Servers and all defined 833IS IP servers on the network and displays them in the Server List window. To complete the connection to a server: 1.
Page 66 3. If the User ID and Password are valid, then the Manager main screen is displayed. 4. If this is the first time that this 833IS is connecting to the Manager you will have to download Firmware to the 833IS. If the 833IS has Firmware, the Manager checks the Firmware level.
Page 67: Using The Manager Main Screen
The Menu bar contains the following menus—File; View; Configure; Statistics; Event Log; Window; and Help. Tool Bar A quick way to use the main functions of Perle 833IS. Each function is represented by a button. Status Bar Gives information about menus and menu items when they are selected, and about the status of some keys on the keyboard.
Page 68: Menu Bar
Create a new configuration. Open Open an existing configuration. Close Close the selected configuration file. Server List Show all Perle 833IS servers found. Save Save the currently selected configuration file. Save As Save the currently selected configuration file as a new file. Print Print the currently selected configuration file.
Page 69 The most recent files that were opened are listed here. Select a file from the list to open that file. Exit Quit Perle 833IS Manager. If unsaved changes have been made to any files, you will be prompted to save or cancel the changes. View Menu...
Page 70 The columns in the table are date, time, event and user name if applicable. Change Log Filter This will lets the user select any of the event types recorded by the 833IS. Only those events will be recorded. Clear Event Log This will clear all the data from the connected server’s log file.
Page 71 Chapter 4: Using the Perle 833IS Manager PPP Debug This popup menu displays the following PPP Debug options. Enabling any of the following options, displays PPP level information in the Event Log for each dial-in connection. Authentication Displays all PPP authentication packets in the Event Log Negotiation Displays PPP packets that are transmitted and received during PPP startup(i.e.
Page 72: Tool Bar
Lists the windows that are currently open. Select a window to make it active. Help Menu The following options appear under the Help menu: Index Displays the Perle 833IS Manager Help index. Using Help Displays general information about using Windows Help. About Perle RAS Manager Display the version number of the Perle RAS Manager program and a copyright notice.
Page 73: Off-Line Configuration
Save the currently selected configuration file. Print the current configuration information. Display the list of Perle 833IS remote access servers. Select a server to make a connection. Get the current configuration from the connected Perle 833IS. Get the Statistics data from the Perle 833IS and display it in the System Statistics window.
Page 74: Loading Firmware
This Firmware is shipped with the Installation disks. Download via If you wish to install a new version of Firmware in your 833IS, you can download Manager the Firmware from the Manager. You will be prompted to update your Firmware when you connect to a Server under these conditions: If the Manager detects that there is no Firmware.
Page 75: Download Via Tftp
4. After the download had completed, the Manager will display “Download complete”. The following dialog box will appear: 5. For the Firmware to take effect, the 833IS must be restarted. When the Server has completed its restart, it will appear in the Server List Window. If you choose to restart the 833IS, any existing sessions will be abruptly terminated.
Page 76 Loading Firmware Perle 833IS User Guide...
Page 77: Section 2: Configuration
Section 2: Configuration Chapter 5: Configuring the Perle 833IS Chapter 6: Configuring the Interfaces Chapter 7: Configuring the Protocols Chapter 8: Configuring the User Database Chapter 9: Configuring the Server Perle 833IS User Guide...
Page 78 Perle 833IS User Guide...
Page 79: Chapter 5: Configuring The Perle 833Is
The 833IS supports two main modes of operation - Dial-In and Dial-Out. Dial-In Access The 833IS lets a user Dial-In with a PC from a remote location to gain access to a LAN. To the remote user, the PC behaves as if it is directly connected to the LAN.
Page 80 BRI line connected to port 1 of the first card but internally, the data would be handled by the modem on the second card. This flexibility allows the 833IS to allocate its available resources in an effective and efficient manner. Client The Perle Server can support three types of clients.
Page 81 Chapter 5: Configuring the Perle 833IS Bridge Client This client operates with the Server as a bridge. The Perle Remote Client can operate as a bridging client as well as a routing client. The Client establishes a WAN connection to the Server. Once a connection has been established with the PC Client, the Perle Server encapsulates LAN frames destined for the PC in PPP.
Page 82: Dial-Out Access
Modem and lines of the 833IS as Dial-Out modems. To the PC application, the PerleDSP Modem and line attached to the 833IS look like a modem connected to the PC COM port. Most PC applications that require a modem are supported. With appropriate software, users can connect to a BBS, Internet provider, or any other service accessible by the telephone network.
Page 83: Configuration Overview
See “Appendix 2: AT Command Set” on page 241. Configuration Overview The 833IS is a very flexible Server and the Manager allows you to fully exploit this potential. To simplify the configuration process, the Manager has been designed with intelligent defaults that will meet the needs of the majority of installations.
Page 84: Using Configuration Files
Server IP or IPX parameters. Using Configuration Files The Configuration file contains all the system and user configurations for the 833IS. Once a file has been created, it can be used to set the configuration for one Server or as a base for any number of Servers.
Page 85: Saving
The configuration file needs to be downloaded to the 833IS for the parameters to take effect. For system changes to take effect, the 833IS must be reset. If a system reset is done, all sessions will be terminated. The only changes which do not require a system reset to take effect are changes to the user data base.
Page 86: Configuration Main Window
7. At this point you will be prompted to Cancel or Reset. Configuration Main On power up, the 833IS automatically detects which Feature cards are installed. If a Window valid configuration has been defined for a Feature card, that card will be started.
Page 87 The configured Asset ID of the Server. This can be used to display a tracking identifier such as the serial number of the Server. Card This area displays information about the type of cards in this 833IS. It also is used to add and remove cards. Type The type of Feature Card installed in this slot.
Page 88: Adding
If the Manager is currently attached to the 833IS being configured, the Card list will display all cards detected by the 833IS as well as any slots that have Feature card configurations. If the Manager is off-line, the Card list will be based on Feature card configurations only.
Page 89: Removing
1. Click and drag the card you wish to remove over to the Available Cards area. The card is now removed from the configuration. Interface This area displays information about the Interfaces in this 833IS. It also is used to select an Interface to configure. Slot The slot of the Interface.
Page 90: Setting The Date And Time
Setting the Date and Time Setting the Date and Time The date and time is used to time stamp 833IS log messages. To set the 833IS Server date and time: 1. From the Configure menu, select Set Date and Time. The following dialog box appears: 2.
Page 91: Chapter 6: Configuring The Interfaces
Depending on your specific needs, the 833IS can support a variety of specific interfaces. The following is a list of the interface currently supported by the 833IS product family. Please note that not all of the interfaces listed below will necessarily be present on your 833IS unit.
Page 92: Editing
The interface selection screen will display all interfaces present on each slot. Editing To Edit an interface on the Manager: 1. In the Interface area, highlight the interface you wish to edit. Click Edit. 2. The configuration screen for the selected interface will appear. Perle 833IS User Guide...
Page 93: Configure The Ethernet Lan Interface
This specifies the MAC address used by the Ethernet interface for the server. Use Burned In Address The burned in MAC address was allocated from a range assigned to the 833IS. It is guaranteed to be unique from all other burned in MAC addresses. In most installations this address should be used.
Page 94: Configure The Token Ring Lan Interface
This specifies the MAC address used by the Token Ring interface for the server. Use Burned In Address The burned in MAC address was allocated from a range assigned to the 833IS. It is guaranteed to be unique from all other burned in MAC addresses. In most installations this address should be used.
Page 95 Chapter 6: Configuring the Interfaces Enable BCP/NetBEUI MAC Address Pool Certain protocols require that the 833IS emulate a LAN adapter and supply a MAC address on behalf of the Dial-In Client. This option allows you to define a pool of 16 MAC addresses, starting at the Base MAC Address defined below.
Page 96: Configure The Isdn Bri Line Interface
833IS must be driven from the same clock. In most applications, the 833IS is connected to the telco network, and all clocks from the telco are guaranteed to be derived from the same clock. If you are connecting the 833IS to a PBX, ensure that the PBX is providing the line clock.
Page 97: Isdn Bri U Interface Configuration
S/T line. It is strongly recommended that at least one S/T BRI line always provide line clock. The 833IS will synchronize to the lowest number BRI line that provides clocking. When clocking is lost, it will switch to an internal clock while it looks for another BRI line providing clocking.
Page 98 The Service Profile Identifier is a string assigned to an interface or channel by the service provider. The SPID configured on the 833IS is sent to the service provider at start-up. This is used by the service provider to assign class of service to a channel.
Page 99: Isdn Bri S/T Interface Configuration
The ISDN BRI S/T interface configuration screen is as follows: Interface Configuration Network Protocol Specifies the network protocol used by the carrier. These network protocols are supported: US NI-1 AT&T 5ESS Chapter 6: Configuring the Interfaces Perle 833IS User Guide...
Page 100 When checked, channel is available for dial out calls. Automatic - The Terminal Endpoint Identifier (TEI) is negotiated automatically between the 833IS and the carrier. Fixed - The Terminal Endpoint Identifier is constant whose value is between 0 and 63. This information is supplied by the carrier.
Page 101 Minitel Servers to allow the first 3 minutes of a connection to be free (i.e billing starts when the call is connected, but the CONNECTED message is delayed for 3 minutes using a caveat in the Q.931 specification. Perle 833IS User Guide Chapter 6: Configuring the Interfaces...
Page 102: Configuring The Perle Dsp Modem Interface
Configuring the Perle DSP Modem Interface Configuring the Perle DSP Modem Interface No configuration is necessary for the modems to operate in the 833IS. The modem configuration screen allows you to: Disable a modem on the card. Change the name of the modem from the default name.
Page 103 It is not recommended that you do another modem reset (do not perform an AT&F), because there are additional parameters required for the correct operation of the 833IS. You should minimize the changes to only those items required for your environment. All commands must be valid AT commands as defined in Appendix 2.
Page 104: Modems
V.90. Modems have parameters that can be set to disable the V.90 modem. This can be done either in the client modem or by setting the Modem Initialization String in the 833IS modem. Perle 833IS User Guide...
Page 105: Chapter 7: Configuring The Protocols
See “Client Handling” on page 64 for details. WAN Transport Protocols are used to transport data across the dial in connection between the client PC and the 833IS or between the 833IS and a router on another LAN. These Perle 833IS User Guide...
Page 106 Since IP and IPX are used for management of the 833IS, you have to define the 833IS itself as a node on the IPX or IP network. This requires setting up IP or IPX address parameters for the 833IS itself.
Page 107: Configuring The Protocols
If a security feature that uses the IP or IPX protocol has already been configured, you will not be allowed to disable the protocol. Perle 833IS User Guide Chapter 7: Configuring the Protocols...
Page 108: Configuring Ip Protocol
Each client dialing in requires a unique IP address. The 833IS supports multiple methods for defining and supplying IP addresses to clients. For the 833IS router to be able to route IP packets, it has to know how to reach the destination. The 833IS supports the following methods: RIPV1 and RIPV2.
Page 109 (such as NetBEUI over IP) are not supported. If a router dials in to the WAN, the 833IS can route traffic from the dial in router to the LAN. This feature is referred to as "LAN-to-LAN". Note that it is not possible to route from this dial in router to a client or router on the Internal WAN network.
Page 110: Wan
The IP Protocol - WAN screen is as follows: WAN Network Clients dialing in to the 833IS must be assigned IP addresses on an Internal WAN Address Network. This section defines the Internal WAN Network used by the 833IS and should be completed after consulting with your IP Network Administrator.
Page 111 To set the WAN Network Address, the following fields must be defined: IP Address Enter the IP address that will be used by the 833IS on the Internal WAN Network for its router port. Be careful to ensure that this address does not conflict with any dial- in client IP addresses.
Page 112: Wan Ip Addresses
Configuring IP Protocol WAN IP Addresses Clients dialing in to the 833IS using the IP protocol need their own IP address. All clients are assigned IP addresses on the Internal WAN Network that has a subnet address distinct from the subnet address of the 833IS LAN port segment. The 833IS will route packets between the LAN port segment and the Internal WAN Network.
Page 113 ...there will be no IP address assigned and the connection will not be established. DHCP By default, the 833IS will look for all DHCP servers on the network. If you wish to configure the addresses of the DHCP servers or change the lease parameters, click on the DHCP button.
Page 114: Dhcp
This is referred to as an address lease. If DHCP is enabled, the 833IS will give the dial in client an IP address that was leased from the DHCP server. When the 833IS leases an address from the DHCP server, it specifies the length of time of the lease.
Page 115: Ip Pool
Remove. Lease Duration This field specifies the length of time that the DHCP server will allow the 833IS to use the leased IP address on behalf of the client. The range is 1 to 65535 minutes. Longer lease times will increase the chances that the client can reconnect to the 833IS and get the same IP address.
Page 116 IP Pool display Displays the base address and count for the IP Pool entries. To remove IP addresses from the pool, highlight the entry in the IP Pool display and click Remove. Perle 833IS User Guide...
Page 117: Server Ip Address
IP address there. The Perle 833IS can acquire the IP address from a BOOTP or RARP server if it has been configured from within these servers. You will need the MAC address of the Perle 833IS to do this. This address can be obtained from the Front Panel.
Page 118 When checked, the 833IS will attempt to acquire the Server IP address from a RARP server. Specify an IP Address When checked, the 833IS will use the IP address defined in the IP address and subnet mask fields. IP Address Enter a valid IP address in this field.
Page 119: Dns/Wins
Chapter 7: Configuring the Protocols DNS/WINS The 833IS can forward the address of a Domain Name Server (DNS) or Windows Internet Name Server (WINS) to a dial in client. If DHCP is enabled, the DHCP server can provide these addresses. You can also configure DNS and WINS addresses.
Page 120: Routing
The IP Protocol - Routing screen has the following settings: Enable Dynamic Routing on LAN When checked, the 833IS will use the IP RIP table built from RIP messages received from other routers to determine how to route a message.
Page 121 RIPv2 messages. If RIPv2 is not being used at all then the Authentication Protocol defaults to the only valid selection which is No Authentication. Perle 833IS User Guide Chapter 7: Configuring the Protocols Do not send RIPs...
Page 122: Static Routes
There is room in this table to keep entries for 600 routers. If there are more routers than this in the networks to which your 833IS is connected (both local and LAN to LAN), some of the RIP table entries will be overwritten and unavailable.
Page 123 Also, a Static Route for a remote router that does not support RIP would allow that remote router to be included in the Routing Tables of the 833IS and of all other routers on the network that support RIP.
Page 124: Add/Edit Ip Static Routes
Subnet Mask The subnet mask of the network that you wish to reach. If destination type is host, the subnet mask is automatically set to 255.255.255.255 to ensure that the host address is uniquely defined. Perle 833IS User Guide...
Page 125: Ip Filter
If destination type is host, the entry will define a route to a single host. Destination Port Specifies whether the destination is reached via the 833IS’s LAN port or via a WAN port through a LAN-to-LAN connection. If the destination is to be reached via the LAN port, click on LAN and enter the IP address of the router that will be used to reach the destination.
Page 126: Filter Definition
Shared User Database Filters can be configured and assigned to a user record on the Remote Perle 833IS. These records will be sent to the Local Perle 833IS when a user dials in and makes a connection. RADIUS To use packet filtering with the RADIUS security server: 1.
Page 127 Filter Definition window will appear. See “Add/Edit IP Filter Definition” on page 112 for details on how to modify the filter definition. Delete To delete a filter definition, select a filter from the list and click Delete. The filter definition will be removed. Perle 833IS User Guide...
Page 128: Add/Edit Ip Filter Definition
Boolean AND function. If the two results are equal, then the address matches. Destination Address This field is the IP address of the station to which the IP packet is being sent. The address should be entered in dotted decimal notation. Perle 833IS User Guide...
Page 129: Filter Assignment
See “IP Filter” on page 109 for more details on how the filters are used. To assign IP filters for the 833IS, click Filter Assignment. The Server Filter Assignment window appears. The fields are as follows: If you select TCP or UDP, the Port Number section appears.
Page 130: Configuring Ipx
This is a pull-down list for previously defined packet filters. Assigned Filters This area can contain a list of up to 10 IP filters to be assigned to the 833IS for processing. Select a filter name from the Defined Filters pull-down list and click Add to add the filter to the Assigned Filters list.
Page 131: Ipx Protocol
Type Auto Detected The 833IS will monitor the LAN to see if there are any frames of that type. If it does, it determines the network number from the frame number. If you do not have any Novell servers on the subnetwork or the servers are removed from service on a regular basis, you should configure the network number.
Page 132 0 are reserved. Dial-In Network Number People dialing in to the Perle 833IS look like they are on a subnetwork separate from the LAN. This subnetwork requires its own network number. The following options are available from the drop box: Auto Generated: The 833IS will automatically choose a network number at power up time.
Page 133: Routing
The IPX Protocol - Routing screen has the following settings: Enable Dynamic Routing on LAN When checked, the 833IS will use the IPX RIP table built from RIP messages received from other routers to determine how to route a message.
Page 134 Configuring IPX the Perle 833IS IPX routing tables to store 250 RIP entries and 500 SAP entries. If your network has more routers and services than this, some of the table entries will be overwritten and those routes and services will be unavailable.
Page 135 Displays the SAP list for the selected entry. For each IPX Static Route table entry, you must configure the services you wish to have available. One server may have multiple services on it, and you need to have a separate SAP entry for each one. Perle 833IS User Guide Chapter 7: Configuring the Protocols...
Page 136: Add/Edit Ipx Static Routes
Network Number is formatted as 1 to 8 hex digits. Destination Port Specifies whether the destination is reached via the 833IS’s LAN port or via a WAN port through a LAN-to-LAN connection. To specify a WAN destination, click on WAN and then select the desired WAN connection from the drop-down menu. TO specify a LAN destination, click on LAN and select anetwork number and enter a node address.
Page 137: Ipx Sap Table List
To configure a new SAP entry, click on the Add button. Edit To edit an existing entry, select an entry from the table, and click the Edit button. Delete To delete an existing entry, select an entry from the table, and click the Delete button. Perle 833IS User Guide...
Page 138: Add/Edit Ipx Sap Entries
Manager's network must be defined. A SAP entry is not created for the Manager. If you are using any security servers configured for IPX (i.e. Novell Bindery, Axent, NT Domain) to provide 833IS security, you must set the routing path and SAP entries for these servers. Perle 833IS User Guide...
Page 139: Filter Definition
Filter Definition window will appear. See “Add / Edit IPX Filter Definition” on page 124 for details on how to modify a filter definition. Delete To delete a filter definition, select a filter from the list, and click Delete. The filter definition will be removed. Perle 833IS User Guide...
Page 140: Add / Edit Ipx Filter Definition
The address of the network that contains the station that is sending the IPX packet. It can be up to 8 characters long. Source Node Address Enter the node address of the station that is sending the IPX packet. It consists of 12 hexadecimal characters. Perle 833IS User Guide...
Page 141: Filter Assignment
Filter” on page 109 for more details on how the filters are used. If you select Other, make an entry in the Type field. The field can be up to 3 numeric characters. Perle 833IS User Guide Chapter 7: Configuring the Protocols...
Page 142: Configuring The Bridge Function (Bcp)
Configuring the Bridge Function (BCP) To assign IPX filters for the 833IS, follow these steps, click Filter Assignment. The Server Filter Assignment window appears. See “Filter Definition” on page 110 for information about the fields and buttons. Configuring the Bridge Function (BCP) Bridging is used to transport supported protocols other than IP, IPX, NetBEUI and ARA.
Page 143: Protocol Filter
You can enter the MAC address in the user database for some users and use the internal pool for the others. The 833IS LAN adapter will see every MAC address that is present on the LAN. For best performance, the Ethernet and Token Ring LAN adapters incorporate an Address Filter.
Page 144 The filter settings have no effect on Routing clients such as Perle Remote or Windows Dial Up Networking clients. Filter Broadcast When checked, the 833IS will not pass any broadcast messages received from the LAN to the WAN client. Filter Multicast When checked, the 833IS will not pass any multicast messages received from the LAN to the WAN client.
Page 145: Configuring Ppp
It is recommended that you do not change these values during the initial installation of the 833IS. When a client dials in to the 833IS, the PPP stacks on each side attempt to negotiate a common set of operating parameters. Modern clients can typically handle a wide range of operating parameters and will successfully negotiate with the 833IS.
Page 146 The dial in client you are using does not support the negotiation of Multilink PPP. On connect, the 833IS will check with the client to see if it wishes to use Multilink PPP. Some clients (for example, MacPPP) do not support this negotiation and will fail to connect.
Page 147: Apple Ppp
Recent versions of this client also supports PPP transport of AppleTalk, known as MacIP. MacIP is not supported by the 833IS. On connect, the 833IS will check with a dial in client to see if it wants to use Multilink PPP.
Page 148: Using Appletalk
The Perle 833IS has built-in support for the AppleTalk networking protocol and no special configuration is required. This allows an Apple Remote Access (ARA) client running on a Macintosh to dial in to the 833IS and access the AppleTalk network. AppleTalk is supported on both Ethernet and Token Ring connected Perle 833ISs.
Page 149: Using Netbeui
This permits clients such as the Windows 95 and Windows NT Dial up Networking clients to be used in a NetBIOS environment. NetBEUI requires that the client dialing into the 833IS emulate a LAN adapter. The 833IS supplies a MAC address from an address pool for this emulated LAN adapter.
Page 150 Using NetBEUI Perle 833IS User Guide...
Page 151: Chapter 8: Configuring The User Database
Configuring the Internal User Database Configuring the Standard Profile Overview of the User Database For a user to gain access to the 833IS, the user must be defined to the system. You can do this in a number of different ways: 833IS Internal Database You can define the user in the internal database of the 833IS.
Page 152: Internal User Database
This strategy makes sense if you have a small number of users that require the special services. Internal User The internal user database of the 833IS can store user records for 500 users. These Database user records are used: For password authentication if the 833IS has been configured for User Database security.
Page 153: Configure The Internal User Database
Displays whether a user's access is enabled or disabled, and if enabled, whether the user has administration privileges. Use Standard Displays whether the user is using the Standard profile. Adds a user to the database. Chapter 8: Configuring the User Database Perle 833IS User Guide...
Page 154 User Database Access Options for access to the User Database. The options are Public and Private. Public The User Database on this server will be accessible to any Perle 833IS on the LAN which has been configured for Search Remote. Private The User Database will be accessible only to users that connect to this local Perle 833IS.
Page 155: Add/Edit User
User Disabled A user record is enabled by default. If you want to prevent a user from accessing the 833IS, but do not want to delete the user from the database, click on this checkbox. User ID Enter the name of the user. The User ID field is case sensitive. Maximum length is 32 characters.
Page 156 When checked, the values in the Standard Profile will be used for this User. If you wish to use Fixed Callback (i.e. callback from the 833IS to a number stored in the user database), the Standard Profile cannot be used.
Page 157: User Profile
The User Profile screen is as follows: Enable Lan To Lan When checked, this option allows a remote Router to access the 833IS. Enabling this will bring up a Lan To Lan tab that allows parameters for the remote router to be set.
Page 158 This feature is can be used by remote IP or IPX dial in clients to save on connection charges. With client virtual connect enabled, the client can drop the physical connection, but the 833IS will keep the session active. The client can then reconnect and the 833IS will reassign the same session, and client IP address.
Page 159: Protocols
Automatically reconnects if data is to be sent Reconnect to the 833IS is driven solely by the client in this mode. The 833IS cannot redial the client. In practice this is not a real limitation, as servers will typically only send data in response to a request from the client.
Page 160 If the user is on an Ethernet lan, the valid address range is 020000000000 - 02FFFFFFFF00. If the user is on a Token Ring lan, the valid address range is 400000000000 - 40FFFFFFFF00. Perle 833IS User Guide...
Page 161: User Callback
You can enable both roaming and fixed callback for a single user. If both are enabled, the 833IS will callback the roaming number if it is supplied at connect. If it is not supplied, fixed callback will be done.The dial-in client must support both fixed and roaming callback for this to work.
Page 162 When checked, this option will enable Roaming Callback. If a client asks for roaming callback during connect, the 833IS will callback with the number supplied by the client. If a client does not request roaming callback, the session will be established as if roaming callback was not checked.
Page 163: Lan To Lan
The Alternate phone number is optional. Lan To Lan The LAN to LAN features allows a router to dial in to the 833IS. The network on the router's LAN can then communicate with the network on the 833IS LAN using IP or IPX.
Page 164: Routing Information
"Reconnect Every" field. For IP, by default the 833IS will send RIP V2 with no multicasts so as to be RIP V1 compatible, and receive RIP V1 or RIP V2. This can be changed in the LAN to LAN RIP Setup submenu.
Page 165: Authentication
Security settings of the 833IS. Authentication that relies on token security (SecureID, Axent) cannot be used with the LAN to LAN feature, as the dial in router has no mechanism for responding to the security challenge. The 833IS will Chapter 8: Configuring the User Database...
Page 166: Dialing The Router
Dialing the router If the 833IS is configured to call the dial up router, the phone number of the router is configured in the "Primary Phone Number" field. When the 833IS needs to dial out, it will use an available channel that is enabled for dial out. You may wish to ensure that the 833IS always has a channel to dial the router.
Page 167: Lan To Lan Configuration
Password and Confirm fields. Phone Numbers Enable Multilink PPP The 833IS uses Multilink PPP to support up to two physical links for each remote router connection. Each physical link has a unique phone number. Chapter 8: Configuring the User Database...
Page 168: Connection
This field is used to enter the phone number of the remote router. The calls can be made on reserved channel numbers if necessary. The phone number fields are only required if the connection is initiated from the 833IS or virtual connection is enabled.
Page 169 The Configure Virtual Connection screen is as follows: Enable Virtual Connection When enabled, the 833IS will take down the physical links to the remote router but maintain the virtual connection at the protocol level (IP or IPX). The remote router must be setup to support virtual connection.
Page 170: Rip Setup
Send version 2 RIPs (no multicasts) so as to be version 1 compatible Send version 2 RIPs Do not process received RIPs Process received version 1 RIPs Process received version 1 or version 2 RIPs Process received version 2 RIPs Perle 833IS User Guide...
Page 171: Standard Profile
Bridged protocols may generate data traffic even though the user may not be performing any functions. This may cause the connection to remain open even when the user is inactive. Perle 833IS User Guide...
Page 172 This feature is used by remote Dial-in clients to save packet charges. The client drops the physical link to the 833IS when the line is idle but maintains the logical end-to-end connection (IP/IPX). The client reestablishes the physical link whenever there is end-to-end data to send.
Page 173 Automatically reconnects if data is to be sent Reconnect to the 833IS is driven solely by the client in this mode. The 833IS cannot redial the client. In practice this is not a real limitation, as servers will typically only send data in response to a request from the client.
Page 174 To assign IP filters for the user, click this button to open the User Filter Assignment window. IPX Filter To assign IPX filters for the user, click this button to open the User Filter Assignment window. Perle 833IS User Guide...
Page 175: Ip Filter Assignment
Up to 10 IP filters can be assigned to the user record. The server will process these filters from the top down, so the order may be important. For instructions on how to define IP filters, see “Filter Assignment” on page 113. Chapter 8: Configuring the User Database Perle 833IS User Guide...
Page 176: Ipx Filter Assignment
Database of specified remote Perle 833IS servers on the LAN. Two Remote Servers can be defined for the local server. When a user connects to the Perle 833IS, a search for the user record will occur in the following order: This option will work only if the remote Perle 833IS servers defined below have been configured for Public User Database Access.
Page 177 Databases button. The Shared User Database dialog box appears. The fields are as follows: Search Remote Set the check box of the Search Remote field to enable the Perle 833IS to search on remote servers. Remote Server 1, Remote Server 2 Specify the location of Remote Server 1 and optionally Remote Server 2 by selecting the Protocol supported by the remote server.
Page 178 Standard Profile Perle 833IS User Guide...
Page 179: Chapter 9: Configuring The Server
Dial-Out contains advanced settings that do not need to be changed for most installations. The 833IS supports a number of different types of user authentication security. If you are using the password security provided in the Internal 833IS User database, you do not need to change these settings.
Page 180: Configuring The Server
If you will be using an SNMP Manager such as HP OpenView to monitor the 833IS, you will need to set the SNMP parameters. If you will be using a Sys Log Server to receive the 833IS event log information then you will need to up the syslog parameters.
Page 181 Chapter 9: Configuring the Server equipment. This name is used for reference only and appears within the Manager and the Front Panel of the 833IS. Enable Front Panel Password When checked, the Front Panel password is enabled. The Front Panel can be password protected to prevent unauthorized persons from accessing it.
Page 182: Dial-Out
The Dial-Out screen is as follows: Auto Dial On Attach When checked, the 833IS will automatically dial the number in the Phone Number field when the Dial-Out client acquires a Dial-Out connection. Phone Number Enter the phone number to be dialed in this field if Auto Dial On Attach is checked.
Page 183 Chapter 9: Configuring the Server Flow Control Flow Control regulates the internal flow of data between the 833IS software and the modem.The 833IS has been set up to use hardware flow control and this value should not have to be changed. However, if you enable software flow control in the modem (via the modem initialization strings), you may need to modify these values.
Page 184: Trigger Characters
There is provision for up to 16 trigger characters. Enter the trigger character in decimal (range 0-255). You can also enter the trigger in hexadecimal by setting the display to hexidecimal. Perle 833IS User Guide...
Page 185: Security
Using a password. At the time of connect, the user must provide a user ID and password. If the password is incorrect, the call is disconnected. The password can be set up in the 833IS Internal User database, or an external database such as Novell Bindery or RADIUS.
Page 186 Once a dial up session has been established, then the user is bound by the same network security as a user that is directly on the LAN. Although the 833IS does not control LAN security, in some cases you can restrict which networks and servers are available to the 833IS.
Page 187: Configuring User Authentication Security
User Database User Database Security uses the user ID and password stored within an 833IS User database. This database could be configured on the Local 833IS or on a remote 833IS. When the remote Client connects, it communicates with the 833IS using either the CHAP or PAP security protocols.
Page 188: Netware Bindery
Please note that the 833IS does not support native NDS messages. The 833IS can use the Bindery to control password access to the 833IS. On the Bindery server, a group is created containing all users that can access the 833IS.
Page 189: Radius
If authentication is rejected, the 833IS will notify the user. 4. If the user is authenticated, the 833IS looks for a local user record for the user. If one is found, it is loaded into the working user record. If no local user is found, the standard user record will be used.
Page 190 In previous releases, a user record in the local data base was used for this purpose. Now, a record in the local database will only be used if the 833IS cannot communicate with a Radius Server. Do not put a record in the local database if you want to ensure that Radius authentication is used under all conditions for administration.
Page 191 Host Retry The length of time in minutes after which the 833IS should retry a RADIUS host which had previously become unreachable. At the expiration of this retry time, the 833IS will attempt to communicate with the RADIUS host. If no response is received, the RADIUS will remain in an off-line state.
Page 192: Axent
This key must match the key configured on the RADIUS server. Timeout Value The length of time in seconds for the 833IS to wait for a reply from the RADIUS server. The default is 3 seconds. Number of Retries The number of times the 833IS will retry a request if no answer is received from the RADIUS server.
Page 193 Agent Key Enter the Agent Key for the 833IS. This is a 1 to 16 digit hexadecimal value and must match the Agent Key configured on the Axent server. This key is used to authenticate the 833IS as a valid Axent agent.
Page 194 Configuring User Authentication Security Agent ID Enter the Agent ID for the 833IS. This is a 1 to 16 digit hexadecimal value and must match the Agent ID configured on the Axent server. This key is used to identify the 833IS as a valid Axent agent.
Page 195: Securid
SecurID token. When the remote Client connects, the 833IS will ask the ACE/Server to start the authentication process. The 833IS then acts as a path between the remote Client and the ACE/Server. The remote Client enters a TTY or terminal mode.
Page 196 833IS is moved to another network with a new SecurID server. If the Node Secret is reset, or the 833IS is reset to factory defaults, then the SecurID server must be configured to resend the Node Secret to the 833IS.
Page 197: Nt Domain
Chapter 9: Configuring the Server NT Domain NT Domain enables the Perle 833IS to use a Windows NT’s domain user database for dial-in user authentication. The Perle 833IS server will collect the userid and password from the dial-in client and will forward an authorization request to the Primary Domain Controller (PDC).
Page 198: Group Settings
ISDN BRI Interface configuration screen). When a Dial-In call comes in, the 833IS will allocate the next available modem from the main modem pool. For a discussion on the main channel and modem pool, please See “Channels” on page 186.
Page 199 Dial-In When a call comes in, the 833IS checks to see if the channel is assigned to a group. If it is, the group profile for that call is used. Based on this profile, the 833IS will allocate one of the modems assigned to the group. Also, other settings can optionally be defined for this group: User standard profile.
Page 200: Group Main
Displays whether this group is enabled for callback. To create a new group, click on Add. Edit To edit an existing group, highlight that group and click on Edit. Remove To remove an existing group, highlight that group and click on Remove. Perle 833IS User Guide...
Page 201: Add/Edit Group
When enabled, the channels for this group will be allocated from the main channel pool. If a channel is required for Dial-Out or callback, the channel attributes that were defined in the ISDN BRI Line configuration will be used. For example, if a Perle 833IS User Guide Chapter 9: Configuring the Server...
Page 202 Group Settings channel is required for Dial-Out for this group, the 833IS will select the next available channel from the main pool that has been enabled for Dial-Out. When disabled, the next available channel that appears in the Channels In Group box will be used.
Page 203: Group Advanced
The Dial-Out settings will replace the system Dial-Out settings for any Dial-Out sessions using this group. The parameters for the Dial-Out Group settings are the same as the main Dial-Out settings. For details on these settings, see “Dial-Out” on page 166. Perle 833IS User Guide Chapter 9: Configuring the Server...
Page 204: Bridge Filter - Group
“Chapter 7: Configuring the Protocols” on page 89. Fields are as follows: Filter Broadcast When checked, the 833IS will not pass any broadcast messages received from the LAN to the WAN client. Filter Multicast When checked, the 833IS will not pass any multicast messages received from the LAN to the WAN client.
Page 205: Snmp
The 833IS Agent supports read access of the SNMP information only. Configuration and control is performed via the 833IS Manager. The 833IS can be controlled by an SNMP Manager that has dialed in to the 833IS. Internets: MIB II. Point-to-Point Protocol.
Page 206: Snmp Configuration
Enter a description of the physical location of the 833IS. Trap Host When the SNMP Agent in the 833IS detects a serious condition or activity, it will send a message known as a trap. A Trap Host is an IP workstation that is set up to receive SNMP trap messages.
Page 207: Community And Community Tables
Community tables act like passwords by controlling SNMP access. They list all SNMP communities and their corresponding access levels. When the SNMP Agent on the 833IS receives a request for information, it looks for the name of the requester in the community table. If it is not found, the request is denied and an error is returned to the user.
Page 208: Logging Configuration
Event Log or a Syslog server. Syslog The 833IS can send Event Log messages in real time to a Syslog server. Messages sent to Syslog are assigned an error level that indicates the severity of the condition. Some of the benefits of using the Syslog feature are the following:...
Page 209 The levels are as follows: 0: Emergencies - System unusable 1: Alerts - Immediate action needed 2: Critical 3: Errors 4: Warnings 5: Notifications - Normal but significant condition 6: Informational - Informational messages only Perle 833IS User Guide...
Page 210 Event Log is filled. Error Level The error levels are as follows: 0: Emergencies - System unusable 1: Alerts - Immediate action needed 2: Critical 3: Errors 4: Warnings 5: Notifications - Normal but significant condition Perle 833IS User Guide...
Page 211 Chapter 9: Configuring the Server 6: Informational - Informational messages only 7: Debugging - For Perle use only Perle 833IS User Guide...
Page 212 SNMP Perle 833IS User Guide...
Page 213: Section 3: Management
Section 3: Management Chapter 10: Managing the Perle 833IS Appendix 1: Menu Descriptions and Maps Appendix 2: AT Command Set Appendix 3: Specifications Appendix 4: RADIUS Server Attributes Appendix 5: Cisco Mode Reference Guide Perle 833IS User Guide...
Page 214 Perle 833IS User Guide...
Page 215: Chapter 10: Managing The Perle 833Is
Status of current calls, and what modems and lines are used by those calls. Viewing Statistics To view the statistics of an 833IS, connect to the server and choose Get Statistics from the Statistics menu. Please See “Connecting to the Server” on page 47 for details on how to connect to a server.
Page 216 Information Name Name of this 833IS as defined in the Server configuration. Asset ID Asset ID of this 833IS as defined in the Server configuration. Time The current time as set within this 833IS. Up time Time elapsed since the 833IS was last started or reset.
Page 217 Click on this button to access the Statistics for this interface. IP Protocol Click on this button to access the IP Protocol Statistics. IPX Protocol Click on this button to access the IPX Protocol Statistics. Perle 833IS User Guide Chapter 10: Managing the Perle 833IS...
Page 218: Accessing Interface Statistics
Highlight the interface you are interested in, and click on the Interface button. The next screen displayed will be based on the interface selected. Ethernet Interface Connection The physical connection used for the Ethernet on the 833IS. MAC Address The MAC address configured for this Ethernet connection. Perle 833IS User Guide...
Page 219: Token Ring Interface
Bytes Received The total number of bytes received by this Ethernet connection for the 833IS since last start or reset. Bytes Transmitted The total number of bytes transmitted by the 833IS on this Ethernet connection since last start or reset.
Page 220: Isdn Bri Line Interface
Indicates the interface number. Interface Status Status of the physical layer. The possible values for this field are connected or disconnected. In Discards The total number of received frames which have been discarded. The possible reasons are: buffer shortage. Perle 833IS User Guide...
Page 221 Displays the current status for the selected channel. Valid statuses are: Idle - Channel is not in use. Connecting - Channel is attempting to connect. Active - Channel is connected. Disabled - Channel is disabled in configuration. Chapter 10: Managing the Perle 833IS Perle 833IS User Guide...
Page 222 This area displays User and Session information for the current call. User The name of the user dialed into the 833IS. Valid for dial in only. Department The department as configured in the User record. Valid for dial in only.
Page 223: Perle Dsp Modem Interface
Idle: The modem is not currently assigned to a call. Disabled: The modem is disabled via configuration. Attempts Number of incoming call attempts for this modem since card start or reset. Chapter 10: Managing the Perle 833IS Perle 833IS User Guide...
Page 224 The modulation scheme used by the modem for the last call. Call Status This area displays User and Session information for the selected modem in the modem status window. User The name of the user dialed into the 833IS. Valid for dial in only. Perle 833IS User Guide...
Page 225: Ip Protocol
Chapter 10: Managing the Perle 833IS Department The department as configured in the User record. Valid for dial in only. Group If this modem has been configured to be part of a group, the group name is displayed here. IP Address If IP protocol is being used in this connection, the IP address of the client is displayed here.
Page 226 Acquired By The method used to acquire the IP address. Valid values are: BOOTP: RARP: Address was acquired from a RARP server. Configuration: Address was acquired from a BOOTP server. Address was configured in the 833IS. Perle 833IS User Guide...
Page 227 Network Number The network number of the network that can be accessed. Hops The number of routers that are between this network and the network that the 833IS is on. Update This button will display the updated number of RIPS in the table.
Page 228: Ipx Protocol
Ethernet or Token Ring 802.2 frames are not used. 802.3 The network number for Ethernet 802.3 frames. Field is blank if Ethernet 802.3 frames are not used. Dial-In Network Number The network number of the Dial-In network. Perle 833IS User Guide...
Page 229 Network Number The network number of the network that can be accessed. Hops The number of routers that are between this network and the network that the 833IS is on. Ticks The amount of time in ticks to reach the network. A tick is equal to 55 milliseconds.
Page 230 47h - Advertising Print Server The Perle 833IS server uses the number “26h” as its server type. Hops The number of routers that are between this Server and the network that the 833IS is Network Address The network address of this Server.
Page 231 Chapter 10: Managing the Perle 833IS Node Address The node address of this Server. Socket The IPX socket number that is used to communicate with this Server. Perle 833IS User Guide...
Page 232: User Statistics
The User Statistics screen is as follows: User The name of the user dialed into the 833IS. Valid for dial in only. Modem Displays modem number and name as defined by configuration. Type Displays the type of call for the selected channel.
Page 233 The time since the start of the current call. Disconnect User Select a user with your mouse and click on the Disconnect button. This user will be disconnected from the 833IS. Perle 833IS User Guide Chapter 10: Managing the Perle 833IS...
Page 234: Event Log
Event Log Event Log The 833IS has a non-volatile Event Log that is used to track key activities in the 833IS. This user log can be uploaded to the 833IS Manager for display or printing. The following types of events are recorded:...
Page 235 Chapter 10: Managing the Perle 833IS PPP Debug This popup menu displays the following PPP Debug options. Enabling any of the following options, displays PPP level information in the Event Log for each dial-in connection. Authentication Displays all PPP authentication packets in the Event Log Negotiation Displays PPP packets that are transmitted and received during PPP startup(i.e.
Page 236: 833Is Front Panel
833IS Front Panel 833IS Front Panel The Front Panel consists of a keypad and LCD display at the front of the 833IS. It is used for the initial setup of the 833IS and monitoring the operational status. 833IS Front Panel...
Page 237: Navigating The Front Panel
Once the 833IS has been fully configured, the Front Panel is in Normal mode. In this mode, many of the statistics that are available from the 833IS Manager can be displayed on the Front Panel. You also have access to these control functions: Reset the entire 833IS.
Page 238 833IS Front Panel Enter Key Accept changes and exit edit mode. ESC Key Discard changes and exit edit mode. Perle 833IS User Guide...
Page 239: Appendix 1: Menu Descriptions And Maps
Indicates the start of Status displays. Status is organized into System, Card, and Network Status displays. Front Panel Main Screen Map Perle 833IS Control Control Menu Descriptions on page 224. Status Menu Descriptions on page 226. Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps Status...
Page 240: Control
Set WAN (internal) Network Number. Select Enable or Disable to enable or disable yor LAN connection. Set your LAN speed. Select Auto Detect, 10 Mb or 100 Mb for Ethernet. Select 4 Mb or 16 Mb for Token Ring LAN. Perle 833IS User Guide...
Page 241: Control Menu Map
IP S u b n e t M a s k V ie w R e s o u rc e s D e fa u lt G ate w a y Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps C o n tro l...
Page 242: Status
Indicates the start of Card Status displays. Card Status is organized into LAN, Line, and Modem displays. Indicates the start of Network Status displays. Network Status is organized into IP, IPX, BCP, NetBEUI, and ARA displays. Perle 833IS User Guide...
Page 243: Status Menu Map
Asset ID Card Type † Start Date Card Status Up Time Firmware BIOS † Card Status descriptions on page 228. Network Status descriptions on page 232. †† Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps †† Status Network...
Page 244: Card Status
MAC address of Ethernet card. Indicates one of the following ports, if the card is connected to the Ethernet network. This panel is only displayed for versions of the 833IS with a BNC Ethernet interface in addition to the RJ-45 interface. RJ-45...
Page 245: Card Status Continued
Indicates the total number of outbound frames which were discarded. Possible reasons are: buffer shortage. Out Errors n Indicates the number of frames which could not be transmitted due to errors. Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps...
Page 246: Card Status Continued
This could be due to the modem incompatibility or an incorrect call type (voice, fax). Number of bytes presented to the modem since Start-up. Number of bytes received from this modem since Start-up Perle 833IS User Guide...
Page 247: Card Status Menu Map
Out Octets n LAN Frames TX Out Discards n Overruns Out Errors n Display only when the unit includes both a BNC and RJ-45 Ethernet interface. Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps PerleDSP12, Modem Status T1/PRI, E1/PRI PerleDSP18...
Page 248: Network Status Display
Indicates whether RARP will be sent at startup to attempt to acquire the 833IS IP address. Indicates whether a BOOTP request will be sent at startup to attempt to acquire the 833IS IP address. Current number of IP RIP entries. Indicates whether the IPX is enabled or disabled.
Page 249 Indicates whether the BCP is enabled or disabled. NetBEUI NetBEUI Enable/ Indicates whether the NetBEUI is enabled or disabled. Disable ARA Enable/Disable Indicates whether the ARA is enabled or disabled. Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps...
Page 250: Network Status Display Menu Map
Mask IPX SNAP By: IPX 802.3 By: RARP IPX 802.3 # IPX SNAP # BOOTP IPX 802.2 By: IPX Network # IPX 802.2 # # RIP Entries #SAP Entries Perle 833IS User Guide Status Status NetBEUI NetBEUI Enable/Disable Enable/Disable Status...
Page 251: Factory Default Mode
Factory Default mode, this message will display, with the address of the device that sent the ping command. Factory Default Setup Provides the base configuration for the 833IS so that it can communicate with the Manager Menu Description Manager Setup Indicates the start of the Factory Mode Setup displays.
Page 252: Factory Default Mode And Setup Map
Can be configured only when the unit includes both BNC and RJ-45 Ethernet interface. Description Options are BNC, RJ45, Auto Detect. This panel is only available for versions of the 833IS with a BNC Ethernet interface in addition to the RJ45 interface. Manager Continues with “Factory Default Mode Menu Map”...
Page 253: Factory Default Mode
Address Found By Indicates how the IP address was determined: BOOTP RARP Configured Default IP Address IP address of the 833IS. IP Subnet Mask IP subnet mask of the 833IS. Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps...
Page 254 # RIP entries # SAP entries Description Number of IPX frames received since last start-up. Number of IPX frames transmitted since last Start-up. Current number of IPX RIP entries. Current Number of the IPX SAP entries. Perle 833IS User Guide...
Page 255: Factory Default Mode Menu Map
Port* IP Frames Tx Speed Overruns # RIP Entries Address Found IP Address Overruns IP Subnet Mask Perle 833IS User Guide Appendix 1: Menu Descriptions and Maps Status IPX Frames Rx IPX Frames Tx # RIP Entries # SAP Entries...
Page 256 Factory Default Mode Menu Map Perle 833IS User Guide...
Page 257: Appendix 2: At Command Set
(such as ATA, ATH) are not handled solely by the modem. Although there are significant differences between making a call on an ISDN line and a standard phone line, the 833IS will make all the necessary conversions.
Page 258 Selects CCITT operation at 300 or 1200 bps during Call Establishment and a subsequent connection. (Default for W-class models.) Selects BELL operation at 300 or 1200 bps during Call Establishment and a subsequent connection. (Default for US models.) n = 0 or 1. n = 1. Perle 833IS User Guide...
Page 259 Select dialing: dial the numbers that follow until the next command is encountered. Method of dialing (tone, pulse) will be based on the configuration of the 833IS. Select dialing: dial the numbers that follow until the next command is encountered. Method of dialing (tone, pulse) will be based on the configuration of the 833IS.
Page 260 If on-hook, the modem will go off-hook and enter command mode. For US models, the modem will remain off-hook. For W-class models, the modem will return on-hook after a period of time determined by S7. n = 0 or 1. Perle 833IS User Guide...
Page 261 Disables result codes to the DTE. n = 0 or 1. Establishes S-Register n as the last register accessed. Sets S-Register n to the value v. Reports the value of S-Register n. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 262 Upon connection, the modem reports the line speed, the error correction protocol, and the DTE speed, respectively. Subsequent responses are disabled. Upon connection, the modem reports the DCE speed (e.g., CONNECT 14400). Subsequent responses are disabled. n = 0, 1, or 2. Perle 833IS User Guide...
Page 263 If dial tone detection is enforced and dial tone is not detected, NO CARRIER will be reported. Enables monitoring of busy tones; send all messages. Result Codes: n = 0 to 4. ERROR Otherwise. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 264 NO ANSWER CONNECT 0600 CONNECT 2400 CONNECT 4800 CONNECT 9600 CONNECT 7200 CONNECT 12000 CONNECT 14400 CONNECT 19200 CONNECT 38400 CONNECT 57600 CONNECT 115200 CONNECT 230400 CONNECT 75TX/1200RX CONNECT 1200TX/75RX DELAYED BLACKLISTED Perle 833IS User Guide n Value in ATXn Command...
Page 265 CARRIER 21600 CARRIER 24000 CARRIER 26400 CARRIER 28800 CONNECT 16800 CONNECT 21600 CONNECT 24000 CONNECT 26400 CONNECT 28800 COMPRESSION: CLASS 5 COMPRESSION: V.42 bis COMPRESSION: NONE Perle 833IS User Guide Appendix 2: AT Command Set n Value in ATXn Command...
Page 266 CARRIER 36000 CARRIER 38000 CARRIER 40000 CARRIER 42000 CARRIER 44000 CARRIER 46000 CARRIER 48000 CARRIER 50000 CARRIER 52000 CARRIER 54000 CARRIER 56000 CONNECT 32000 CONNECT 34000 CONNECT 36000 CONNECT 38000 CONNECT 40000 Perle 833IS User Guide n Value in ATXn Command...
Page 267: At& Commands
CONNECT 52000 CONNECT 54000 CONNECT 56000 +FCERROR RLSD remains ON at all times. RLSD follows the state of the carrier. (Default.) n = 0 or 1. Perle 833IS User Guide Appendix 2: AT Command Set n Value in ATXn Command...
Page 268 In sync mode, CTS is always ON (RTS transitions are ignored). tracks the state of RTS; In async mode, CTS is normally ON and will turn OFF only if required by flow control. n = 0 or 1. Perle 833IS User Guide...
Page 269: At% Commands
%E1 Enable auto-retrain. %E2 Enable fallback/fall forward. (Default.) Result Codes: ERROROtherwise. Link Disconnect Or Local Request 33600 BPS 33600 BPS 28800 BPS 28800 BPS V42Bis n = 0, 1, or 2. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 270: At\ Commands
Send a break immediately to DTE. (Same as 2.) Send a break in sequence with received data to DTE. Send a break in sequence with received data to DTE. (Same as 4.) (Default.) n = 0 to 5. Perle 833IS User Guide...
Page 271: At+ Commands
Note: The -K1 command can override the \N4 command. Selects MNP error-correction mode. Failure to make an MNP error- correction connection results in the modem hanging up. n = 0 to 5. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 272 +MS: (list of supported <mod> values), (list of supported <automode> values), (list of supported <min_rate> values), (list of supported <max_rate> values) For example, +MS: (0,1,2,3,9,10,11,56, 64,69),(0,1),(300-33600),(300-56000) There may be additional values displayed after the <max_rate> field, but they are not applicable. Perle 833IS User Guide...
Page 273 56000, 54667, 53333, 52000, 50667, 49333, 48000, 46667, 45333, 42667, 41333, 40000, 38667, 37333, 36000, 34667, 33333, 32000, 30667, 29333, 28000 Bell 103 Bell 212 1200 Perle 833IS User Guide Appendix 2: AT Command Set Notes See Note 2 [default]...
Page 274 The value is decimal coded, in units of bps, e.g., 2400 specifies the lowest rate to be 2400 bps. The default is 300 for 300Êbps. Option Selected Automode disabled Automode enabled using V.8 bis/V.8 or V.32 Annex A Perle 833IS User Guide Notes Default...
Page 275: Error Detection And Data Compression Commands
Enables both V.42 bis and MNP 5 data compression. (Default.) n = 0, 1, 2, or 3. 64 characters. 128 characters. (Default.) 192 characters. 256 characters. n = 0 to 3. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 276 Services initiation during V.42 LAPM answer mode detection phase. n = 0 or 2. sub parameter <tx level> range 0 to 30 (0 dBm to -30 dBm) n=0, 1, or 1 and <tx level>=0 to 30 Perle 833IS User Guide...
Page 277: S-Registers
Carrier Detect Response Time Carrier Loss Disconnect Time DTMF Tone Duration Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Perle 833IS User Guide Appendix 2: AT Command Set Units Saved Default** 0-127 ASCII 0-127 ASCII 0-255 ASCII 2-255 1-255 0-255 1-255 0.1 s...
Page 278 Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved LAPM Failure Control Reserved Reserved Reserved Reserved Reserved Reserved Data Compression Control V.42 Negotiation Control Call Failure Reason Code Perle 833IS User Guide Range Units Saved Default** 0-255...
Page 279: S-Register Definitions
The modem always pauses for a minimum of 2 seconds, even if the value of S6 is less than 2 seconds. Range: Default: 2 0-127, ASCII decimal 0-127, ASCII decimal 0-32, ASCII decimal 2-255 seconds Perle 833IS User Guide Appendix 2: AT Command Set...
Page 280 Default: 14 (1.4 seconds) S11 - DTMF Tone Sets the duration of tones in DTMF dialing. Duration Range: Default: 95 (95 milliseconds) 1-255 seconds 0-255 seconds 1-255 tenths of a second 1-255 tenths of a second 50-255 milliseconds Perle 833IS User Guide...
Page 281 Disable negotiation; bypass the detection and negotiation phases; and proceed with LAPM. Enable negotiation. (Default.) proceed at once with the fallback action specified in S36. Can be used to force MNP. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 282: At Command Set Summary
Select V.22 or Bell 212A 1200 bps line speed. (RC144) Select V.22 bis line modulation. (RC144) Select V.32 bis or V.32 4800 line modulation. (RC144) Select V.32 bis 7200 line modulation. (RC144) Select V.32 bis or V.32 9600 line modulation. (RC144) Perle 833IS User Guide...
Page 283 CONNECT, RING, NO CARRIER, NO ANSWER, CONNECT XXXX, BUSY, NO DIAL TONE and ERROR. &C0 Force RLSD active regardless of the carrier state. &C1 Allow RLSD to follow the carrier state. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 284 Send a break immediately to DTE. Send a break with received data to the DTE. Select normal speed buffered mode. Select direct mode. Select reliable link mode. Select auto reliable mode. Force LAPM mode. Force MNP mode. Select modulation. Perle 833IS User Guide...
Page 285: Ecc Commands
Capability to receive. Capability to receive. Report the called station ID. DCE capabilities parameters. Report current session. Current session results. Report remote capabilities. Current sessions parameters. Begin or continue phase C receive data. Perle 833IS User Guide Appendix 2: AT Command Set...
Page 286 Transmit page punctuation. Call termination with status. Session termination. Local ID string. Document for polling. Identify model. Identify manufacturer. Indicates polling request. Page transfer status. Page transfer status. Identify revision. Enable polling Report the transmit station ID. Perle 833IS User Guide...
Page 287: Appendix 3: Specifications
0% - 95%, non condensing Power 100 - 125 VAC, 50 - 60 Hz, 0.5A 200 - 240 VAC, 50 - 60 Hz, 0.25A BTU Output 100 BTU/hour maximum MTTR 30 minutes MTBF 100,000 hours Perle 833IS User Guide Appendix 3: Specifications...
Page 288: Chassis
4 meg Flash for Firmware storage in SIMM sockets. 128K non volatile log Expansion Card 4 meg RAM in SIMM sockets for RAM expansion. LAN Interfaces Ethernet 10/100 Mbps Ethernet Network interface with hardware MAC address range filtering. Protocols Supported 10Base-T 100Base-TX Perle 833IS User Guide...
Page 289: Isdn Bri Interface
100Base-TX: Category 5 Unshielded Twisted Pair or Type 1 shielded twisted pair Early token release at 16 Mbps DB15 (AUI) RJ45 Shielded twisted pair types 1, 2, 6, 9 Unshielded twisted pair type 3, 4, 5 Perle 833IS User Guide Appendix 3: Specifications...
Page 290: Perledsp Modem Interface
V.21 channel 2 V.27 ter V.29 V.33 Other Modem V.42 LAPM error correction Protocols MNP Class 2-4 error correction MNP 10 error correction V.42 bis data compression MNP Class 5 data compression T.30 Fax protocol Facsimile Class 2 Perle 833IS User Guide...
Page 291: Approvals
AS/NZS 3548 Class A Japan VCCI Class 1 EN 50082-1: 1992 (EMC Directive 89/336/EEC) Telephony Europe European Harmonized Standard CTR3 FCC Part 68 Canada IC CS03 Australian Communications Authority Technical Standard: TS-031 (1997) Perle 833IS User Guide Appendix 3: Specifications...
Page 292: Protocols Supported
Header Compression Protocols: IP-VJ, CIPX Security Password Authentication Protocols (PAP/CHAP) LAN Environments Novell Netware 3.x and 4.x Windows NT Advanced Server Windows for Workgroups IBM OS/2 LAN Server Microsoft LAN Manager UNIX IBM Hosts (AS/400, Mainframe) Lantastic Appleshare Server Perle 833IS User Guide...
Page 293: Dial In Clients Supported
RADIUS Windows NT Domain Token Security Dynamics SecureID Authorization Axent Management 833IS Manager connected via IPX or IP enables configuration and management through LAN and dial up Manager supported on Windows 95/98/NT/2000 Workstation Perle 833IS User Guide Appendix 3: Specifications...
Page 294: Rfcs Supported
RFC 1696 - Modem Management Information Base (MIB) using SMIv2. RFC 1742 - AppleTalk Management Information Base II. RFC 1743 - IEEE 802.5 MIB using SMIv2. RFC 1990 - The PPP Multilink Protocol. (MP) RFC 2127 - ISDN Management Information Base using SMIv2. Perle 833IS User Guide...
Page 295: Appendix 4: Radius Server Attributes
Appendix 4: RADIUS Server Attributes Account Request Messages This section describes the attributes which will be included by the 833IS when re- questing authentication from a RADIUS server. Number Name Description User-Name The name of the user to be authenticated.
Page 296: Access-Accept Messages
Access-Accept Messages Access-Accept Messages This section describes the attributes which will be accepted by the 833IS from a RADIUS authentication server in response to an authentication request. The values returned will override any values currently in use. This includes values derived from a record in the local user database or from the default user record.
Page 297 = destination network yy = number of bits to use for subnet (optional) vv = router IP address (0 = use address assigned to router by 833IS) m = hop count This value is sent to the accounting server un- modified by the 833IS.
Page 298: Accounting Messages
Accounting Messages Accounting Messages This section describes the attributes which will beincluded by the 833IS when sending an accounting message to the RADIUS server. Number Name Description Acct-Status-Type Indicates if this is the beginning or end of a session. Supported values include:...
Page 299 3 = Lost Service 4 = Idle Timeout 5 = Session Timeout 14 = Port Suspended 16 = Callback 7KLV DWWULEXWH LV RQO\ YDOLG LQ DQ D..RXQWLQJ PHVVDJH ZKHUH WKH $..W6WD WXV7\SH LV VHW WR $945 Perle 833IS User Guide...
Page 300 Accounting Messages Perle 833IS User Guide...
Page 301: Appendix 5: Cisco Configuration Mode
833IS. For example, access to the program storage on flash on a Cisco router is handled like a disk drive. The firmware and configuration storage on the flash on the 833IS can also be accessed like a disk drive through various Cisco commands.
Page 302: Overview Of 833Is
The configuration can then be customized and updated using Cisco Configuration Mode. Regardless of the method with which you configure the 833IS unit, you can view the statistics and current status of the 833IS via Telnet. Using standard Cisco commands and/or a Syslog server, events occurring on the 833IS can be monitored and analyzed.
Page 303 The flash volume is a Read/Write flash memory where versions of firmware or configuration files for the 833IS can be stored. The 833IS can be updated by downloading a new release firmware image to the flash volume using the 833IS Manager or TFTP. The release firmware filename convention that is used for the 833IS are as follows: pcc6600s.img :BRI Line with ‘S/T’...
Page 304: Differences Between 833Is And Cisco Products
“startup-config” file. The 833IS can hold up to two Feature cards. The card in Slot 1 is called the System card and the card in Slot 2 is called the Expansion card. The system card is the main processing card and must be present in the 833IS in Slot 1 but the Expansion card is optional.
Page 305 Instead of initial configuration being performed over a direct serial connection, the 833IS configures IP parameters through the front panel of the unit. The 833IS is able to configure the IP Address, gateway, subnet mask and LAN speed from the front panel enabling connections to be established across the LAN (Ethernet or Token Ring).
Page 306 IP addresses to clients. If a router dials in to the WAN, the 833IS can route traffic from the dial in router to the LAN. This feature is referred to as "LAN-to-LAN". Note that it is not possible to route from this dial in router to a client or router on the Internal WAN network.
Page 307: Command Overview
The Cisco command set does not accommodate all the configuration and management features for the 833IS. Therefore, Perle commands have been developed to modify these features on the 833IS unit which are not present in a Cisco environment. The Perle commands use a similar syntax as Cisco commands but are uniquely identified by the “_”...
Page 308 Set the parameters needed for communication with the Management PC or Telnet/TFTP session Monitor the 833IS's operation on the network to verify correct configuration and provides information to diagnose network problems. To navigate through the Front Panel screens the following keys are used: Left Selects a menu.
Page 309 To enter an IP address, press Enter to go to Edit mode. IP Address 233.233.233.011 to select the digit to change. Use When completed, press Enter to accept the new IP Address and the 833IS unit new IP configuration takes effect immediately Press IP Subnet Mask 255.255.255.000...
Page 310 RJ45 interface. For these units, you can use this panel to override the auto port detect feature of the 833IS. Once set, the 833IS will no longer try to auto detect this port, even after a restart of the unit. The only way to re-enable the auto detect feature is via this menu item.
Page 311 This configuration takes affect immediately and does not require an IPL of the 833IS. At this time you can connect to the 833IS through a Telnet session on your PC. The front panel of the unit can be used to verify that communications between the PC and the server are operational.
Page 312: Monitoring The 833Is
Telnet interface. The 833IS can also send Event Log messages in real time to up to 4 Syslog servers concurrently. These Syslog servers can be attached to either the LAN or the WAN interfaces.
Page 313 However, these command actions have no validity mechanism to ensure a logical configuration is operating and not causing any disruption to the online session. When the 833IS Manager downloads a new configuration to the 833IS it performs a validity check on the configuration file beforehand. This prevents illogical configuration parameters from being downloaded to the unit.
Page 314 Differences between 833IS Manager and Cisco Configuration Mode Perle 833IS User Guide...
Page 315: Bootp (Bootstrap Protocol)
Consists of 2 bearer B channels and a data D channel. See ISDN and PRI Bridge A Network Device that connects two networks so that devices on one network can communicate with devices on the other network. Sometimes called a Filtering Bridge. See Router. Perle 833IS User Guide...
Page 316 See Fixed and Roaming Callback CBCP (Callback Control Protocol) A callback protocol defined by a RFC. Central Site A generic term that refers to the Perle 833IS that you are using. Channel Usually what you rent from the Telephone Company. Acts like an individual telephone line and has a defined frequency response, gain, and bandwidth.
Page 317 Feature Card An optional circuit board addition that increases the capabilities of the 833IS. The card can be installed by the reseller. Available cards are Token Ring, Ethernet, ISDN BRI U, ISDN BRI S/T and PerleDSP Modem. Fixed Callback A method where the number used for callback is contained within the 833IS database.
Page 318 IP address of a node. Remote Node Support The ability of the 833IS to treat a remote user as if they were in "the office". By dialing in they become part of the LAN. RFC (Request for Comment) Standards, procedures and specifications for various TCP/ IP protocols.
Page 319 The Service Profile Identifier is a numeric string assigned to an interface or channel by the service provider. The SPID configured on the 833IS is sent to the service provider at start-up. This is used by the service provider to assign class of service to a channel.
Page 320 UTP (Unshielded Twisted Pair) A cable that has one or more pairs of twisted insulated copper conductors bound inside a single plastic sheath. WAN (Wide Area Network) A communication network that connects geographically separated areas. Perle 833IS User Guide...
Page 321 Token Ring Cable 30 Attempts Modem 207 AUI 16, 299 Autonomous Unit Interface see AUI 299 Axent 176 B8ZS 299 Basic Rate Interface see BRI 299 Bayonet-Neill-Concelman Connector see BNC 299 Beacon 299 Beaconing 299 BIOS version 200 Perle 833IS User Guide...
Page 322 MNP 10 269 Set Summary 266 Compression 300 Configuration, Off-line 57 Configuration File Creating a new 68 Downloading 69 Opening 68 Saving 69 Uploading 68 Window 70 Configure 300 Menu 53 Configuring 75, 120, 122 Feature Card 75 Perle 833IS User Guide...
Page 323 Disabled 300 Diskette Packet 21 Display IP RIP Table 211 IPX RIP Table 213 Download 69 a configuration to an 833IS 69 DSX-1 300 DTMF 300 Dual Tone Multi-Frequency see DTMF Dynamic 300 Dynamic Host Configuration Protocol see DHCP 300 E &...
Page 324 Call back 185 Dial in 183, 185 Dial out 183, 185 Enable 185 Name 185 group preferred call back 156 Grouping 2 Group Settings 166 Hardware Assembling 27 LAN cable 29 Power Cord 27 Help Manager 56 Perle 833IS User Guide...
Page 325 206 digital 206 l 84 LAN 44 Cabling 14 frames RX 38 TX 38 MAC Address 38 Overruns 39 Port 38 Speed 38 Status 38 Using 43 LAN cable Attaching 29 Ethernet 29 Token Ring 30 Perle 833IS User Guide...
Page 326 Initialization String Modify 87 initialization string 301 Name 87 Modem Initialization String 301 Modems group 186 main pool 186 MODulate/DEMmodulate see Modem MTBF 271 MTTR 271 multicast 302 Filter 188 multiplexing 302, 303 time division 303 Perle 833IS User Guide...
Page 327 PPP 129, 302 Compression 129 Time-outs 129 PRI 80, 130, 302 Primary Rate Interface see PRI 302 Print 52 Preview 52 Setup 53 Private Branch eXchange see PBX 302 Protocol 302 Filter 302 Statistics 209 Protocols Configuring Perle 833IS User Guide...
Page 328 Local 171 Netware Bindery 172 Network Bindery 172 PAP 169 Radius 173 SecurID 176, 179 Static Routing 170 User Authentication 169 Security Screen Access 171 Serial Number label 27 Server 163, 200–?? Asset ID 200 Connecting 47 Perle 833IS User Guide...
Page 329 Lan 38 Modem 207 Status Bar 51 STP 30, 303 Token Ring 18 Subnet mask 303 Subnetwork Access Protocol see SNAP Support 303 Switch Power 27 System Active 24, 25 Card 25 System Requirements 44 Manager 44 Perle 833IS User Guide...
Page 330 Type, Call 206 Unit Placement 13 Unpacking 8, 22 contents of box 21 Unshielded Twisted Pair see UTP 304 Uploading a configuration from an 833IS 68 User Call Backs 145, 156 disabled 139 Password 304 Records 136 Standard Profile 187...
Page 331 Perle 833IS User Guide...
Page 332 Perle 833IS User Guide...
Page 333 Perle 833IS User Guide...
Page 334 Perle 833IS User Guide...
Page 335 Perle 833IS User Guide...
Page 336 Perle 833IS User Guide...
Page 337 Perle 833IS User Guide...
Page 338 Perle 833IS User Guide...
Page 339 Perle 833IS User Guide...
Page 340 Perle 833IS User Guide...

Perle 833IS User Manual

Introduction

Section 1: Installation

Chapter 1: Quick Installation Overview

Chapter 2: Site Preparation

Chapter 3: Setting up and Installing

Chapter 4: Using the Perle 833IS Manager

Section 2: Configuration

Chapter 5: Configuring the Perle 833IS

Chapter 6: Configuring the Interfaces

Chapter 7: Configuring the Protocols

Chapter 8: Configuring the User Database

Chapter 9: Configuring the Server

Section 3: Management

Chapter 10: Managing the Perle 833IS

Appendix 1: Menu Descriptions and Maps

Appendix 2: at Command Set

Appendix 3: Specifications

Appendix 4: RADIUS Server Attributes

Appendix 5: Cisco Configuration Mode

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Perle 833IS

Summary of Contents for Perle 833IS
