______________________________________________________________
The IOLAN SCG gives you a way to access serial devices remotely from anywhere there
is a network connection.
This guide covers basic installation and configuration and is intended for first time
setup or product evaluation.
Complete details can be found in the following guides at
www.perle.com/downloads.
• IOLAN User's Guide V5.0 or greater
• IOLAN Command Line Interface Reference Guide V5.0 or greater
• IOLAN SCG Hardware Installation Guide – Expandable Models

IOLAN SCG Models

All IOLAN SCG models have the following basic hardware set. 16/32/48 RS232 RJ45
and/or 16/32/48 USB ports (any combination of USB/RS232 RJ45 ports), using 16 port
expansion modules.
• 2 RJ45 auto-sensing Ethernet 10/100/1000 Mbps ports
• 2 SFP 100/1000 Ethernet transceiver ports
• 1 Micro-USB and 1 RS232 RJ45 Console Admin Port
• 2 USB front ports for serial class devices
• Front Panel Display with keyboard
Note: When using Ethernet Combo ports (RJ45 and SFP pair), only one interface
will be active at a time.

Optional hardware

• Internal V.92 modem with one RJ11 connector
• Cellular WWAN capability based on 4G LTE technology (North American or
European)
• SIM card slot to be used for 4G LTE networks
• Wireless LAN (Wifi) client 802.11 a,b,g,n @2.4Ghz/5Ghz support
What's in the box?
The following components are included with your product:
IOLAN SCG Chassis: 1U-tall (1.75 inch), rack-mountable chassis
• Combination of:
• 16 port USB modules
• 16 port RS232 RJ45 modules
IOLAN SCG Quick Start Guide – Expandable Models
IOLAN SCG
Expandable Models
Quick Start Guide
P/N 5500437-10 (Rev C)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IOLAN SCG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Perle IOLAN SCG

  • Page 1 Expandable Models Quick Start Guide ______________________________________________________________ The IOLAN SCG gives you a way to access serial devices remotely from anywhere there is a network connection. This guide covers basic installation and configuration and is intended for first time setup or product evaluation.
  • Page 2 IOLAN unit to the network • Data Plan subscription with a supported carrier and activated 3FF SIM Card for SCG-LA or SCG-LE models only Hardware Features SCG Front View SCG Back View IOLAN SCG Quick Start Guide – Expandable Models...
  • Page 3 The IOLAN SCG features several different configuration methods (i.e. HTTP, Telnet, SNMP) as well as an external Windows based Utility (DeviceManager). For the most up to date documentation on any IOLAN SCG feature refer to the Perle website at www.perle.com Initial Setup for the IOLAN SCG 1.
  • Page 4 12. Press the Back button twice to go back to the Main Menu. 13. You will need to reboot the IOLAN SCG using the power switches on the back of the unit to have the new IP address take effect.
