0.00E+00
-2.00E+01
-4.00E+01
-6.00E+01
-8.00E+01
-1.00E+02
-1.20E+02
-1.40E+02
-1.60E+02
-1.80E+02
1.00E+01 1.00E+02 1.00E+03 1.00E+04 1.00E+05 1.00E+06 1.00E+07 1.00E+08
Blue = RF Generator

Figure 88. RF Generator, Si5326, Si5324; No Jitter (For Reference)

0.00E+00
-2.00E+01
-4.00E+01
-6.00E+01
-8.00E+01
-1.00E+02
-1.20E+02
-1.40E+02
-1.60E+02
-1.80E+02
1.00E+01 1.00E+02 1.00E+03 1.00E+04 1.00E+05 1.00E+06 1.00E+07 1.00E+08
Blue = RF Generator

Figure 89. RF Generator, Si5326, Si5324 (50 Hz Jitter)

622.08 MHz in, 622.08 MHz out
Offset Frequency (Hz)
Green = Si5326
622.08 MHz in, 622.08 MHz out
Offset Frequency (Hz)
Green = Si5326
Rev. 0.52
Si53xx-RM
Red = Si5324
Red = Si5324
165
