Write Sector(s) — 30h, 31h
The Write Sector(s) command writes from 1 to 256 sectors as specified in the
Sector Count register. A sector count of 0 requests 256 sectors. When issued,
the device sets the BSY bit within 400ns and generates an interrupt at the
completion of a transferred block of sectors. The DRQ bit is set at the
beginning of a block transfer.
Register
Feature
Sector Count
Sector Number
Cylinder Low
Cylinder High
Drive Head
Command
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
3150C-10DSR
S D
ET ESCRIPTION
Table 73: Write Sector(s) — 30h, 31h
