Check Power Mode — 98h, E5h
The Check Power Mode command verifies the device's current power mode.
When the device is configured for standby mode or is entering or exiting
standby, the BSY bit is set, the Sector Count register set to 00h, and the BSY
bit is cleared. In idle mode, BSY is set and the Sector Count register is set to
FFh. The BSY bit is then cleared and an interrupt is issued.
Register
Feature
Sector Count
Sector Number
Cylinder Low
Cylinder High
Drive Head
Command
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
3150C-10DSR
S D
ET ESCRIPTION
Table 48: Check Power Mode — 98h, E5h
