Cylinder High Register; Silicon Systems Proprietary; Table 39: Cylinder High Register - Silicon Systems SiliconDrive CF SSD-C08G(I)-3150 Datasheet

ATA R
EGISTERS
C H
YLINDER IGH
The Cylinder High register is set by the host to specify the cylinder number
high byte. Following an ATA command, the content of the register is set
internally by the device, identifying the cylinder number high byte.
In LBA mode, the 8-bit register maintains the contents of the Logical Block
number address bits A23:A16.
Operation
Read/Write
Default Value
