Set Sleep Mode — 99h, E6h
The Set Sleep Mode command allows the host to set the device in sleep
mode. When the onboard controller transitions to sleep mode, it clears the
BSY bit and issues an interrupt. The device interface then becomes inactive.
Sleep mode can be exited by issuing either a hardware or software reset.
Register
Feature
Sector Count
Sector Number
Cylinder Low
Cylinder High
Drive Head
Command
