Silicon Systems SiliconDrive CF SSD-C08G(I)-3150 Datasheet page 23

E S
LECTRICAL PECIFICATION
Signal Name
V
CC
(PC Card I/O
mode)
V
CC
(True IDE mode)
-VS1, -VS2
-VS1, -VS2
(PC Card I/O
mode)
-VS1, -VS2
(True IDE mode)
-WAIT
(PC Card memory
mode)
-WAIT
(PC Card I/O
mode)
-IORDY
(True IDE mode)
-WE
(PC Card memory
mode)
-WE
(PC Card I/O
mode)
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
3150C-10DSR
Table 8: Signal Descriptions (Continued)
Pin Type Description
33, 40 O
42 O
36 I
S S
ILICON YSTEMS
All unauthorized use and/or reproduction is prohibited.
P 13
AGE
SSD-C
XXX
This signal is the same for all modes.
This signal is the same for all modes.
Voltage Sense Signals.
• -VS1 is grounded so that the
SiliconDrive CF CIS can be read at
3.3V.
• -VS2 is reserved by PC Card for a
secondary voltage.
This signal is the same for all modes.
This signal is the same for all modes.
The -WAIT signal is driven low by the
SiliconDrive CF to signal the host to
delay completion of a memory or I/O
cycle that is in progress.
This signal is the same as the PC
Card Memory Mode signal.
In true IDE mode, this output signal
may be used as IORDY.
This is a signal driven by the host and
used for strobing memory write data
to the registers of the SiliconDrive CF
when the card is configured in the
memory interface mode. This signal is
also used for writing the configuration
registers.
In PC Card I/O mode, this signal is
used for writing the configuration
registers.
