Executive Drive Diagnostic — 90h
The Executive Drive Diagnostic performs an internal read write diagnostic test
using (AA55h and 55AAh). If an error is detected in the read/write buffer, the
Error register reports the appropriate diagnostic code.
Register
Feature
Sector Count
Sector Number
Cylinder Low
Cylinder High
Drive Head
Command
