Write Multiple — C5h
The Write Multiple command operates in the same manner as the Write Sector
command. When issued, the device sets the BSY bit within 400ns and
generates an interrupt at the completion of a transferred block of sectors. The
DRQ bit is set at the beginning of a block transfer.
Register
Feature
Sector Count
Sector Number
Cylinder Low
Cylinder High
Drive Head
Command
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
3150C-10DSR
S D
ET ESCRIPTION
Table 72: Write Multiple — C5h
