Write DMA — CAh
The Write DMA command allows the host to write data using the DMA transfer
protocol.
Note: This function does not apply to SiliconDrives that have DMA
disabled.
Register
Feature
Sector Count
Sector Number
Cylinder Low
Cylinder High
Drive Head
Command
