Silicon Systems SILICONDRIVE III SSD-D0120PI-5000 Datasheet

2.5" pata drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
O
VERVIEW
The SiliconDrive III 2.5" PATA Drive is an
optimal time-to-market replacement for
hard drives and flash cards or in host
systems that require low power and
scalable storage solutions.
Numerous SiliconSystems patented and
patent-pending
technologies
can
SiliconDrive III to safeguard application
data and software IP. Application notes
detailing these performance-enhancing
options are available under NDA.
SiliconDrive III technology is engineered
exclusively for the high performance, high
reliability and multi-year product lifecycle
requirements of the Enterprise System
OEM
market.
applications include broadband data and
voice networks, military systems, flight
system
avionics,
industrial
control
surveillance, storage networking, VoIP,
wireless infrastructure, and interactive
kiosks.
Every SiliconDrive III is integrated with
SiliconSystems patented PowerArmor and
patent-pending
SiSMART
eliminate storage systems failures.
PowerArmor prevents data corruption and
loss
from
power
integrating patented technology into every
SiliconDrive III.
SiSMART acts as an early warning system
to eliminate unscheduled downtime by
constantly monitoring and reporting the
exact amount of remaining storage system
useful life.
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
26840 A
V
P
, A
LISO
IEJO
ARKWAY
5000D-00DSR PRELIMINARY
D
ATA
S
application-specific
be
integrated
into
Typical
end-market
medical
equipment,
systems,
video
to
virtually
disturbances
S
S
ILICON
YSTEMS
All unauthorized use and/or reproduction is prohibited.
•
V
, CA 92656
P
LISO
IEJO
HONE
S
HEET
D
III 2.5" PATA D
ILICON
RIVE
F
EATURES
• RoHS 6 of 6 compliant
• Integrated PowerArmor and SiSMART
technology
• Capacity range: 30GB to 120GB
• Available Capacities: 30GB, 60GB,
90GB, and 120GB
• MTBF: 3,000,000 hours
• ATA-6 compliant
• Read transfer rate: Up to 100MBps
• Write transfer rate: Up to 80MBps
• Burst transfer rate: 100MBps
• Temperature: -40°C to 85°C
• Power consumption:
Standby: 0.5W
Read: 1W
Write: 1W
• Vibration: 16.3gRMS
• Shock: 1000G
• Altitude: 80,000ft.
120GB PATA
SSD-D0120PI-5000
by
Click here
P
ROPRIETARY
•
: 949.900.9400
F
: 949.900.9500
AX
[P
RELIMINARY
SSD-D
(
)-5000
XXX
X
Click here
•
http://www.siliconsystems.com
M
ARCH
]
RIVE
16, 2009
