Page 1: Service Manual
MS312 and MS317 4514-330 Service Manual • Start diagnostics • Maintenance • Safety and notices • Trademarks • Index July 12, 2018 www.lexmark.com P/N 12G3396...
Page 2: Product Information
Trademarks Lexmark and the Lexmark logo are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. PCL® is a registered trademark of the Hewlett-Packard Company. PCL is Hewlett-Packard Company’s designation of a set of printer commands (language) and functions included in its printer products.
Page 3: Table Of Contents
4514-330 Table of contents Product information..................2 Edition notice....................2 Notices, conventions, and safety information.........13 Laser notice................................13 Conventions.................................16 Safety information.............................. 16 General caution statements........................... 22 Change history....................23 Change history..............................23 General information..................27 Media guidelines............................... 27 Paper guidelines................................27 Using specialty media ..............................31 Supported paper sizes, types, and weights ......................
Page 4 4514-330 Vertical light bands check ............................62 Vertical dark bands check............................63 Vertical dark streaks with print missing check ....................64 White streaks and voided areas check ......................... 67 Fine lines are not printed correctly (speciﬁcally Chinese characters) check ..........69 Clipped pages or images check..........................
Page 5 Load MP feeder with [paper type] [paper size] [orientation] ................108 Memory full [38] ................................108 Memory low, no Resource Save [35]........................109 Non‑Lexmark [supply type], see User’s Guide [33.xy] ..................109 Network error, port [x] [54] ............................109 Network error, standard port [54]..........................110 Paper too short [34] ..............................110 Parallel port disabled [56] ............................110...
Page 6 4514-330 Imaging unit low service check ..........................121 Toner cartridge low service check.........................122 Printer hardware errors..........................122 111 errors ..................................122 121 errors..................................126 126 errors..................................128 132 errors..................................129 133 errors ..................................130 140 errors..................................131 155 errors..................................132 Procedure before starting the 9yy service checks ...................133 900 errors ..................................135 912 errors..................................140 94y errors ..................................140...
Page 7 4514-330 Entering the Diagnostics menu ..........................163 Registration ..................................163 PRINT TESTS ................................164 Print Quality Pages..............................164 Hardware Tests ................................165 Duplex Tests ................................166 Input Tray Tests ................................168 Output Bin Tests .................................169 Base Sensor Test................................170 Device Tests.................................170 Printer Setup................................. 171 EP Setup ..................................172 Reports ..................................
Page 8 4514-330 Data security notice ..............................183 Handling ESD‑sensitive parts..........................184 Controller board/control panel replacement ......................184 Restoring the printer conﬁguration after replacing the controller board ............185 Restoring solutions, licenses, and conﬁguration settings ................188 Updating the printer ﬁrmware ..........................189 Ribbon cable connectors ............................190 Zero Insertion Force (ZIF) connectors......................190 Horizontal top contact connector ........................191 Horizontal bottom contact connector ......................194 Vertical mount contact connector........................197...
Page 9 4514-330 Front door removal ..............................244 Front access cover removal ........................... 247 Front door sensor removal ............................. 247 Front input guide removal............................248 Separator pad removal ............................250 Bottom removals.............................252 Power supply removal..............................252 Power supply shield removal ..........................253 Duplex removal................................254 Duplex sensor and input sensor removal ......................255 Toner density sensor removal..........................257 Trailing edge sensor removal..........................
Page 10 4514-330 Assembly 2: Electronics 1..........................295 Assembly 3: Electronics 2..........................297 Assembly 4: Frame............................300 Assembly 5: Option trays..........................303 Assembly 6: Power cords..........................305 Assembly 7: Miscellaneous.......................... 307 Printer speciﬁcations................309 Product power consumption........................309 Electrical speciﬁcations..........................309 Operating clearances............................. 310 Acoustics................................310 Operating environment........................... 311 Enabling the security reset jumper.......................311 Options and features................
Page 11 4514-330 Part number index..................335 Part name index..................339 Table of contents...
Page 12 4514-330 Table of contents...
Page 13: Notices, Conventions, And Safety Information
4514-330 Notices, conventions, and safety information Laser notice The printer is certiﬁed in the U.S. to conform to the requirements of DHHS 21 CFR, Chapter I, Subchapter J for Class I (1) laser products, and elsewhere is certiﬁed as a Class I laser product conforming to the requirements of IEC 60825-1: 2014.
Page 14 4514-330 Aviso sobre laser Esta impressora foi certiﬁcada nos EUA por estar em conformidade com os requisitos do DHHS 21 CFR capítulo I, subcapítulo J, para produtos a laser de Classe I (1) e, nos demais países, foi certiﬁcada como um produto a laser de Classe I em conformidade com os requisitos da IEC 60825-1.
Page 15 4514-330 Laserprodukte der Klasse I werden nicht als gefährlich betrachtet. Der Drucker enthält im Inneren einen Laser der Klasse IIIb (3b), und zwar einen 12-Milliwatt-Gallium-Arsenid-Laser, der im Wellenlängenbereich von 655 bis 675 Nanometern arbeitet. Das Lasersystem und der Drucker sind so konstruiert, dass unter normalen Betriebsbedingungen, bei der Wartung durch den Benutzer oder bei den vorgeschriebenen Wartungsbedingungen Menschen keiner Laserstrahlung ausgesetzt sind, die die Werte für Klasse I überschreitet.
Page 16: Conventions
4514-330 클래스 I 레이저 제품은 위험한 제품으로 간주되지 않습니다. 프린터에는 655‑675 나노미터의 파장 영역에서 작동하는 공칭 12밀리와트 갈륨 비소 레이저인 클래스 IIIb(3b) 레이저가 내부에 포함되어 있습니다. 레이저 시 스템과 프린터는 정상적인 작동, 사용자 유지 관리 또는 사전 설명된 서비스 조건에는 사람에게 클래스 I 수준 이상의...
Page 17 4514-330 • There may be an increased risk of electrical shock and personal injury during disassembly and servicing of this product. Professional service personnel should understand this risk and take necessary precautions. CAUTION—SHOCK HAZARD: When you see this symbol, there is a danger from hazardous voltage in the area of the product where you are working.
Page 18: Informazioni Sulla Sicurezza
4514-330 Información de seguridad • La seguridad de este producto se basa en las pruebas y comprobaciones del diseño original y los componentes especíﬁcos. El fabricante no se hace responsable de la seguridad en caso de uso de piezas de repuesto no autorizadas. •...
Page 19 4514-330 ATTENZIONE - PERICOLO DI SCOSSE ELETTRICHE: Questo simbolo indica la presenza di un rischio per tensioni pericolose nell'area del prodotto in cui si lavora. Scollegare l'alimentazione prima di iniziare, o prestare la massima attenzione se per effettuare l'operazione il prodotto deve ricevere l'alimentazione.
Page 20 4514-330 Sicherheitshinweise • Die Sicherheit dieses Produkts basiert auf Tests und Zulassungen des Originaldesigns und der speziﬁschen Komponenten. Sofern nicht autorisierte Ersatzteile eingesetzt werden, übernimmt der Hersteller keinerlei Verantwortung in Bezug auf die Sicherheit dieses Produkts. • Die Wartungsinformationen für dieses Produkt wurden für ausgebildete Servicemitarbeiter zusammengestellt und dürfen nicht von anderen verwendet werden.
Page 21 4514-330 FORSIKTIG – POTENSIELLE SKADER: Litiumbatteriet i dette produktet er ikke beregnet for å byttes. Det er fare for eksplosjon hvis litiumbatteriet skiftes ut på feil måte. Ikke lad opp, demonter eller destruer et litiumbatteri. Kast brukte litiumbatterier i henhold til produsentens instruksjoner og lokale regelverk.
Page 22: General Caution Statements
CAUTION—POTENTIAL INJURY: Only a Lexmark Inline Surge Protector that is properly connected between the printer and the power cord provided with the printer may be used with this product. The use of non-Lexmark surge protection devices may result in a risk of ﬁre, property damage, or poor printer performance.
Page 23: Change History
4514-330 Change history Change history July 12, 2018 • For Performing the initial troubleshooting check, relative humidity values were updated (now 8 to 80%). • A note for ambient temperature and relative humidity information was added to the Fuser service check. May 9, 2018 •...
Page 24 4514-330 February 27, 2017 • Added "MS317" in the cover. • Added "MS317dn" in the introduction to the “General information" chapter. • Revised the topic "Covers" in the "Parts catalog" chapter. December 9, 2016 • Revised a graphic in the “Printhead assembly adjustments” topic in the “Repair information” chapter. •...
Page 25 4514-330 – Unsupported imaging unit service check – Supplies mismatch service check February 18, 2016 • Added the topic “Enabling the security reset jumper” in ”Appendix A: Printer speciﬁcations” chapter. February 10, 2016 • Updated the art and table for the topic “Covers” in the “Parts catalog” chapter. January 20, 2016 •...
Page 26 4514-330 April 23, 2015 • Updated the 97y error code table and created “Network port error service check” on page 145 for the 97y error codes. • Updated the 98y error code table and created “Option communication error service check” on page 146 for the 98y error codes.
Page 27: General Information
4514-330 General information The Lexmark MS312 is a single‑function monochrome laser printers designed for small and mid‑sized workgroups. All information in this service manual pertains to all models unless explicitly noted. The printers are available in the following models: Model Conﬁgurations...
Page 28 4514-330 Smoothness Paper smoothness directly affects print quality. If paper is too rough, then toner cannot fuse to it properly. If paper is too smooth, then it can cause paper feeding or print quality issues. Always use paper between 100 and 300 Sheffield points;...
Page 29 (electrophotographic) printers. While no blanket statement can be made that all recycled paper will feed well, Lexmark consistently tests papers that represent recycled cut size copier papers available on the global market. This scientiﬁc testing is conducted with rigor and discipline.
Page 30 Lexmark concerns itself with the responsible use of paper in general based on life cycle assessments of its products. To gain a better understanding of the impact of printers on the environment, the company commissioned a number of life cycle assessments and found that paper was identiﬁed as the primary contributor...
Page 31: Using Specialty Media
4514-330 Storing paper Use these paper storage guidelines to help avoid jams and uneven print quality: • For best results, store paper where the temperature is 21°C (70°F) and the relative humidity is 40 percent. Most label manufacturers recommend printing in a temperature range of 18–24°C (65–75°F) with relative humidity between 40 and 60 percent.
Page 32 Print samples on the labels being considered for use before buying large quantities. Note: Use only paper label sheets. Vinyl, pharmacy, and two‑sided labels are not supported. For more information on label printing, characteristics, and design, see the Card Stock & Label Guide available at http://support.lexmark.com. When printing on labels: •...
Page 33: Supported Paper Sizes, Types, And Weights
4514-330 Supported paper sizes, types, and weights Supported paper sizes Note: For an unlisted paper size, select the closest larger listed size. For information on card stock and labels, see the Card Stock & Label Guide. Paper size Standard tray Optional 250‑...
Page 34: Supported Paper Types And Weights
4514-330 Paper size Standard tray Optional 250‑ or Multipurpose feeder Duplex mode 550‑sheet tray 10 Envelope 105 x 241 mm (4.1 x 9.5 in.) DL Envelope 110 x 220 mm (4.3 x 8.7 in.) C5 Envelope 162 x 229 mm (6.4 x 9 in.) B5 Envelope 176 x 250 mm (6.9 x 9.8 in.) Other Envelope...
Page 35: Data Security Notice
4514-330 Paper type 250‑ or 550‑sheet tray Multipurpose feeder Duplex mode Preprinted Colored Paper Light Paper Heavy Paper Rough/Cotton One‑sided paper labels designed for laser printers are supported for occasional use. It is recommended to print 20 or fewer pages of paper labels per month. Vinyl, pharmacy, and two‑sided labels are not supported. Bond and Heavy Paper are supported in duplex mode up to 90‑g/m (24‑lb) paper weight.
Page 36 4514-330 • #2 Phillips screwdriver, magnetic • #2 Phillips screwdriver, magnetic short-blade • Needle‑nose pliers • Diagonal side cutters • Spring hook • Feeler gauges • Analog or digital multimeter • Flashlight (optional) General information...
Page 37: Diagnostics And Troubleshooting
Before you start the troubleshooting procedures, perform the following checks: • Use genuine Lexmark supplies and parts for the best results. Third-party supplies or parts may affect the performance, reliability, or life of the printer and its imaging components. •...
Page 38: Fixing Print Quality Issues
Before troubleshooting speciﬁc print problems, complete the following initial print quality check: • Use only genuine Lexmark supplies. Third-party supplies may cause print quality problems. • The printer must be in a location that follows the recommended operating environment speciﬁcations.
Page 39: Gray Background Or Toner Fog Check
Step 2 Go to step 4. Go to step 3. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 40 4514-330 Actions Step 4 Go to step 5. Go to step 6. Remove any packing material left on the imaging unit, including the red separator plastic (A). Note: You may need a pair of pliers to remove a piece of broken plastic inside the imaging unit.
Page 41: Blank Pages Check
4514-330 Actions Step 8 Go to step 9. The problem is solved. Reseat the connections. Does the problem remain? Step 9 Go to step 10. The problem is solved. Note: Poor electrical contact to the photoconductor is the most likely source of a full page background defect. Remove any contamination from the photoconductor charge contact (C) on the right side of the frame.
Page 42 Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 43 4514-330 Actions Step 5 Go to step 6. Go to step 7. Check the coupler to make sure that it is not stuck in the retracted position. While slowly closing the door, observe the coupler to see if it moves inward. Note: With the imaging unit removed, the coupler should retract with the door open and move inward when the front door is closed.
Page 44 4514-330 Actions Step 6 Go to step 7. The problem is solved. Reach inside the printer and manually reposition the coupler in the direction of the red arrow as shown. Does the problem remain? Step 7 Go to step 8. Contact the next level of support.
Page 45 4514-330 Actions Step 10 Go to step 11. The problem is solved. Replace the cable. Does the problem remain? Step 11 Go to step 13. Go to step 12. Check the transfer roller for proper installation. If necessary, remove and then reinstall the transfer roller. Check the transfer roller for contamination and damage.
Page 46 4514-330 Actions Step 15 Go to step 16. The problem is solved. Check the coupler for signs of damage. The coupler is located on the main drive motor. • Good condition • Bad condition If the coupler is damaged, then replace the main drive motor. Does the problem remain? Step 16 Go to step 17.
Page 47: Solid Black Pages Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 48 4514-330 Actions Step 3 Go to step 4. Go to step 5. Remove any packing material left on the imaging unit, including the red separator plastic (A). Note: You may need a pair of pliers to remove a piece of broken plastic inside the imaging unit.
Page 49 4514-330 Actions Step 6 Go to step 7. Go to step 8. Check if the imaging unit contact (C) is contaminated, broken, or bent out of proper position. Is the contact contaminated, broken, or bent out of proper position? Step 7 Contact the next The problem is level of support.
Page 50: Print Is Too Dark Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 51 4514-330 Actions Step 7 Go to step 8. The problem is solved. Make sure that the paper loaded is from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you use it. Does the problem remain? Step 8 Go to step 9.
Page 52: Print Is Too Light Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 53 4514-330 Actions Step 5 Go to step 6. Go to step 7. Check the shutter on the imaging unit for signs of damage. Note: The shutter opens to receive toner from the toner cartridge. Is the shutter on the imaging unit working properly? Step 6 Go to step 7.
Page 54: Paper Curl Check
4514-330 Actions Step 12 Go to step 13. The problem is solved. Replace the cartridge gearbox. See “Cartridge gearbox removal” on page 219. Does the problem remain? Step 13 Go to step 15. Go to step 14. Check connection JCART1 on the controller board and the connection on the cartridge gearbox.
Page 55 Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 56: Folded Or Wrinkled Paper Check
Go to step 2. The problem is solved. Check if the printer is using a non-Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then do not replace the imaging unit. Refer the users to their cartridge supplier.
Page 57: Repeating Defects Check
4514-330 Repeating defects check Actions Step 1 Go to step 2. Go to step 3. From the control panel, navigate to: Menu > Help > Print Defects Guide Using the Print Defects Guide, check if the distance between the defects is equal to any of the following: •...
Page 58: Skewed Print Check
4514-330 Skewed print check Actions Step 1 Go to step 3. Go to step 2. Check the guides in the tray where the skewed prints are sourced from. Note: If paper is sourced from the MPF, then proceed to step Does the position of the guides match the paper loaded? Step 2 Go to step 3.
Page 59 4514-330 Actions Step 7 Go to step 8. The problem is solved. Perform a print test. From the Diagnostics menu, select PRINT TESTS > Tray [x]. Note: [x] refers to the tray where the skewed prints are sourced from. Does the problem remain? Step 8 Go to step 15.
Page 60: Streaked Vertical Lines Appear On Prints Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 61: Horizontal Light Bands Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 62: Vertical Light Bands Check
Actions Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, refer the users to their cartridge supplier.
Page 63: Vertical Dark Bands Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 64: Vertical Dark Streaks With Print Missing Check
4514-330 Actions Step 3 Go to step 4. The problem is solved. Remove, and then reinstall the toner cartridge and imaging unit. Does the problem remain? Step 4 Go to step 5. The problem is solved. If a bright light enters the right side of the printer, then move the printer to avoid the bright light.
Page 65 Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 66 4514-330 Actions Step 5 Go to step 6. The problem is solved. Replace the imaging unit. Does the problem remain? Step 6 Go to step 7. Go to step 8. Check if the imaging unit contacts (C) are contaminated or bent out of proper position.
Page 67: White Streaks And Voided Areas Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, do not replace the imaging unit. Refer the users to their cartridge supplier.
Page 68 4514-330 Actions Step 5 Go to step 6. Go to step 7. Check the shutter tab (A) on the toner cartridge for signs of damage. Is the shutter tab damaged? Step 6 Go to step 7. The problem is solved. Replace the imaging unit and the toner cartridge.
Page 69: Fine Lines Are Not Printed Correctly (Speciﬁcally Chinese Characters) Check
4514-330 Actions Step 9 Contact the next The problem is level of support. solved. Clean or repair the imaging unit contacts. Does the problem remain? Step 10 Go to step 12. Go to step 11. Check connection JPS1 on the controller board and all the connections on the power supply.
Page 70: Clipped Pages Or Images Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 71 Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 72: Compressed Images Appear On Prints Check
4514-330 Actions Step 7 Go to step 8. Contact the next level of support. Check the imaging unit contact block (B) for damage or improper installation. Is the imaging unit contact block damaged or improperly installed? Step 8 Contact the next The problem is level of support.
Page 73: Incorrect Margins On Prints Check
4514-330 Actions Step 1 Go to step 2. Go to step 3. Remove the imaging unit, and then inspect the white photoconductor coupler (A). The coupler should be ﬁrmly connected to the imaging unit and should not freely rotate. Does the coupler move freely or appear damaged? Step 2 Go to step 3.
Page 74: Toner Rubs Off Check
4514-330 Actions Step 1 Go to step 2. The problem is solved. Adjust the guides in the tray according to the size of the paper loaded. Does the problem remain? Step 2 Go to step 3. The problem is solved. Do one of the following: •...
Page 75: Toner Specks Appear On Prints Check
Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 76 Step 1 Go to step 3. Go to step 2. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the printer is using a third‑party cartridge, then refer the users to their cartridge supplier.
Page 77: Paper Jams
4514-330 Paper jams Avoiding jams Load paper properly • Make sure that the paper lies ﬂat in the tray. • Do not remove a tray while the printer is printing. • Do not load a tray while the printer is printing. Load it before printing, or wait for a prompt to load it. •...
Page 78: Understanding Jam Messages And Locations
4514-330 • Make sure that the paper size and type are set correctly on the Embedded Web Server or the computer. Note: Depending on your operating system, access the Paper menu using Local Printer Settings Utility or Printer Settings. • Store paper according to manufacturer recommendations.
Page 79: Jam, Front Door [20Y.xx]
4514-330 Jam, front door [20y.xx] CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it. Press the button on the right side of the printer, and then open the front door. Pull the toner cartridge out using the handle.
Page 80 4514-330 Place the imaging unit aside on a ﬂat, smooth surface. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light can cause print quality problems. Lift the green ﬂap in front of the printer. Firmly grasp the jammed paper on each side, and then gently pull it out.
Page 81: Jam, Standard Bin [20Y.xx]
4514-330 Insert the imaging unit by aligning the arrows on the side rails of the unit with the arrows on the side rails inside the printer, and then insert the imaging unit into the printer. Insert the toner cartridge by aligning the side rails of the cartridge with the arrows on the side rails inside the printer, and then insert the cartridge into the printer.
Page 82: Jam, Rear Door [20Y.xx]
4514-330 Jam, rear door [20y.xx] Press the button on the right side of the printer, and then open the front door. Gently pull down the rear door. CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.
Page 83: Jam, Pull Tray 1. Push Down Blue Flap. [23Y.xx]
4514-330 Close the rear and front doors. From the printer control panel, press to clear the message and continue printing. Jam, pull tray 1. Push down blue ﬂap. [23y.xx] Pull out the tray completely. Diagnostics and troubleshooting...
Page 84: [X]-Page Jam, Open Tray 1. [241.Xx]
4514-330 Locate the blue lever, and then pull it down to release the jam. Note: If the jammed paper is not visible in the duplex area, then open the rear door, and then gently remove the jammed paper. Make sure all paper fragments are removed. Firmly grasp the jammed paper on each side, and then gently pull it out.
Page 85: [X]-Page Jam, Open Tray [2]. [242.Xx]
4514-330 Note: The message on the printer display indicates the tray where the jammed paper is located. Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Insert the tray. From the printer control panel, select Next >...
Page 86: Jam, Mp Feeder [250.Xx]
4514-330 Firmly grasp the jammed paper on each side, and then gently pull it out. Note: Make sure all paper fragments are removed. Insert the tray. From the printer control panel, select Next > > Clear the jam, press OK > Jam, MP feeder [250.xx] From the multipurpose feeder, ﬁrmly grasp the jammed paper on each side, and then gently pull it out.
Page 87: 200 Paper Jams
4514-330 Flex the sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. Reload paper into the multipurpose feeder. Note: Make sure the paper guide lightly rests against the edge of the paper. From the printer control panel, press to clear the message and continue printing.
Page 88 4514-330 Error code Description Action 200.09 Printhead did not receive proper motor feedback Go to “Sensor (input) image jam service check” to start laser servo. on page 200.10 Printhead motor not locked when media reaches Go to “Sensor (input) image jam service check” the input sensor.
Page 89 4514-330 Error code Description Action 200.38 Interpage servo gap smaller than expected for Go to “Sensor (input) early/late arriving service galvo offset target evaluation. check” on page 200.42 Rogue sheet at ACM sensor while ﬂushing the Go to “Sensor (input) early/late arriving service paper path prior to declaring tray 1 source empty.
Page 90 4514-330 Sensor (input) early/late arriving service check Action Step 1 Go to step 2. Go to step 5. Check the paper source. Is the paper from the MPF? Step 2 Go to step 3. Replace the MPF pick roller and Check the MPF pick roller and separator pad for damage and separator pad.
Page 91 4514-330 Action Step 9 Contact the next The problem is level of support. solved. Does the error remain? Sensor (input) image jam service check Action Step 1 Go to step 2. Reseat the cables. Check the LSU cables for proper connection. Are they properly connected? Step 2 Go to step 3.
Page 92: 201 Paper Jams
4514-330 Main drive motor control jam service check Action Step 1 Go to step 2. Reseat the cable. Remove the main drive gearbox. Check the main drive gearbox cable for proper connection. Is it properly connected? Step 2 Go to step 3. Replace the main drive gearbox.
Page 93: 202 Paper Jams
4514-330 Sensor (narrow media) jam service check Action Step 1 Go to step 2. Reseat the cable. Check the narrow media sensor cable JNRW1 for proper connection. Is it properly connected? Step 2 Go to step 3. Replace the narrow media sensor.
Page 94 4514-330 Error code Description Action 202.17 Page at fuser nip before fuser reached acceptable Go to “Sensor (fuser exit) jam service check” on operating temperature. Page arrived at fuser page earlier than expected, so it was probably staged. 202.22 Cartridge Motor - Motor Underspeed Error. Motor Go to “Sensor (fuser exit) jam service check”...
Page 95: 23Y Paper Jams
4514-330 23y paper jams 23y paper jam messages Error code Description Action 230.01 Sheet covering internal duplex sensor during Go to “Duplex service check” on page warm up. 230.02 Paper jam around internal duplex. Go to “Duplex service check” on page 230.03 Internal duplex sensor never made by leading Go to...
Page 96: 241 Paper Jams
4514-330 Action Step 3 Go to step 4. Replace the duplex gear assembly. See Remove the input tray. “Duplex gear From under the printer, check the duplex gear assembly and assembly removal” duplex link for wear and damage. on page 220.
Page 97 4514-330 Error code Description Action 241.17 Page was not properly picked from tray 1. Have Go to “Tray 1 jam service check” on page not exhausted all pick retry attempts as there are sheets committed to the paper path from below. 241.20 Took too long to ramp up media feeder motor in Go to...
Page 98 4514-330 Tray 1 jam service check Action Step 1 Go to step 2. Replace the pick tires. Check the pick tires. Are they free of wear or damage? Step 2 Go to step 3. Replace the tray insert. Check the tray guides and wear strips. Are they free of wear or damage? Step 3 Go to step 4.
Page 99: 242 Paper Jams
4514-330 242 paper jams 242 paper jam messages Error code Description Action 242.01 Paper over tray 2 pass thru sensor on warmup. Go to “Option tray jam service check” on page 100. 242.02 Input sensor detected late feed during a pick Go to “Option tray jam service check”...
Page 100 4514-330 Error code Description Action 242.33 Pick received but detected a tray pulled. Go to “Option tray jam service check” on page 100. 242.41 Motor 1 (Pick/Lift) Elevator motor stalled. Go to “Option tray jam service check” on page 100. 242.42 Motor 1 (Pick/Lift) Elevator motor PWM overﬂow Go to...
Page 101: 25Y Paper Jams
4514-330 Action Step 3 Replace the ACM Go to step 4. assembly. See “ACM Does the printer display a 242.06 error? assembly removal” on page 283. Step 4 Go to step 5. Replace the pick roller assembly. See Check the pick roller assembly. “Pick roller removal”...
Page 102: Mpf Service Check
4514-330 MPF service check Action Step 1 Go to step 2. Replace the MPF assembly. See “MPF Check the springs, links, and tray guides on the MPF assembly for assembly removal” damage. on page 239. Are they free of damage? Step 2 Go to step 3.
Page 103: Understanding The Printer Messages
Check if both the toner cartridge and imaging unit are MICR (Magnetic Ink Character Recognition) or non-MICR supplies. Note: For a list of supported supplies, see the “Ordering supplies” section of the User's Guide or visit www.lexmark.com. Change the toner cartridge or imaging unit so that both are MICR or non‑MICR supplies. Notes: •...
Page 104: Cartridge Nearly Low [88.Xy]
4514-330 Cartridge nearly low [88.xy] If necessary, press on the printer control panel to clear the message and continue printing. Cartridge very low, [x] estimated pages remain [88.xy] You may need to replace a toner cartridge very soon. For more information, see the “Replacing supplies” section of the User’s Guide.
Page 105: Change [Paper Source] To [Paper Type] [Paper Size]. Load [Orientation]
4514-330 Change [paper source] to [paper type] [paper size]. Load [orientation]. Try one or more of the following: • Load the correct size and type of paper in the tray, and then press on the control panel. Note: Make sure the paper size and type settings are speciﬁed in the Paper menu on the control panel.
Page 106: Flash Memory Full [52]
4514-330 Flash memory full [52] Try one or more of the following: • From the printer control panel, press to clear the message and continue printing. • Delete fonts, macros, and other data stored in the ﬂash memory. From the printer control panel, navigate >...
Page 107: Load [Paper Source] With [Custom String] [Orientation]
4514-330 Load [paper source] with [custom string] [orientation] Try one or more of the following: • Load the indicated tray or feeder with the correct size and type of paper. • From the printer control panel, press to clear the message and continue printing. Note: If the printer ﬁnds a tray that has the correct paper type and size, then it feeds from that tray.
Page 108: Load Mp Feeder With [Custom Type Name] [Orientation]
4514-330 Load MP feeder with [custom type name] [orientation] Try one or more of the following: • Load the feeder with the correct size and type of paper. • From the printer control panel, press to clear the message and continue printing. Note: If no paper is loaded in the feeder, then the printer manually overrides the request, and then prints from an automatically selected tray.
Page 109: Memory Low, No Resource Save [35]
The printer has detected a non‑Lexmark supply or part installed in the printer. Your Lexmark printer is designed to function best with genuine Lexmark supplies and parts. Use of third- party supplies or parts may affect the performance, reliability, or life of the printer and its imaging components.
Page 110: Network Error, Standard Port [54]
Turn off the printer, wait for about 10 seconds, and then turn the printer back on. • Update the network ﬁrmware in the printer or the print server. For more information, visit the Lexmark Web site at http://support.lexmark.com. Paper too short [34] Try one or more of the following: •...
Page 111: Rear Usb Port Disabled [56]
“Replacing supplies” section of the User’s Guide. Note: If you do not have a replacement cartridge, then see the “Ordering supplies” section of the User’s Guide or visit www.lexmark.com. Replace cartridge, printer region mismatch [42.xy] Install a toner cartridge that matches the region number of the printer.
Page 112: Replace Imaging Unit, 0 Estimated Pages Remain [84.Xy]
“Replacing supplies” section of the User’s Guide. Note: If you do not have a replacement imaging unit, then see the “Ordering supplies” section of the User’s Guide or visit www.lexmark.com. Replace unsupported cartridge [32.xy] Remove the toner cartridge, and then install a supported one to clear the message and continue printing.
Page 113: User Attendance Messages (0-99.99)
4514-330 User attendance messages (0-99.99) User attendance messages (0‑99.99) Error code Description Action 31.21 Missing or unresponsive imaging unit Go to “Unresponsive imaging unit service check” on page 130. 31.22 Excessive CTLS noise. Go to “Unresponsive imaging unit service check” on page 130.
Page 114 4514-330 Error code Description Action 32.01 Unsupported cartridge Go to “Unsupported toner cartridge service check” on page 116. 32.01 Unsupported imaging unit Go to “Unsupported imaging unit service check” on page 117. 32.05 Unsupported cartridge Go to “Unsupported toner cartridge service check”...
Page 115: Unresponsive Toner Cartridge Service Check
The problem is solved. Check if the toner cartridge is a supported and genuine Lexmark supply. If not, then replace it. Make sure that the toner cartridge is properly installed. Check the toner cartridge, toner cartridge button, and cartridge plunger for damage. Replace if necessary.
Page 116: Unsupported Toner Cartridge Service Check
The problem is solved. Check if the toner cartridge is a supported and genuine Lexmark supply. If not, then replace it. Make sure that the toner cartridge is properly installed. Check the toner cartridge, toner cartridge button, and cartridge plunger for damage. Replace if necessary.
Page 117: Unsupported Imaging Unit Service Check
Go to step 2. The problem is solved. Check if the imaging unit is a supported and genuine Lexmark supply. If not, then replace it. Make sure that the imaging unit is properly installed. Make sure that the latest ﬁrmware is installed.
Page 118: Toner Smart Chip Compatibility Service Check
Action Step 1 Go to step 2. The problem is solved. Check if the toner cartridge is a supported and genuine Lexmark supply. If not, then replace it. Does the error remain? Step 2 Contact the next The problem is level of support.
Page 119: Media Size Mismatch Service Check
4514-330 Media size mismatch service check Action Step 1 Go to step 2. The problem is solved. Make sure the media size setting matches the paper in the tray. Restore the engine settings to their defaults: Diagnostics Menu > Printer Setup > Defaults Restore the EP setup settings to their defaults: Diagnostics Menu >...
Page 120: Supplies Mismatch Service Check
The problem is solved. Check if the toner cartridge and imaging unit are supported and genuine Lexmark supplies. If not, then replace the supplies. Make sure that the supplies are compatible. Note: Do not install a MICR cartridge with a non‑MICR imaging unit or vice versa.
Page 121: Flash Full Service Check
4514-330 Flash full service check Action Step 1 Go to step 2. The problem is solved. Format the ﬂash memory. Navigate to Settings > Print Settings > Utilities, then select Format Flash. Does the error remain? Step 2 Go to step 3. Replace the memory card.
Page 122: Toner Cartridge Low Service Check
4514-330 Toner cartridge low service check Action Step 1 Go to step 2. The problem is solved. Replace the toner cartridge. Does the problem remain? Step 2 Go to step 3. The problem is solved. Make sure the toner cartridge smart chip contact cable JARW1 is properly connected to the controller board.
Page 123 4514-330 Error code Description Action 111.00 Pel clock check failed. Go to “Laser scanning unit (LSU) service check” on page 125. 111.01 Downlevel ASIC detected. 111.20 Mirror motor lock is asserted before the motor is turned on. Note: This error is applicable only to printer models installed with a polygon LSU.
Page 124 4514-330 Error code Description Action 111.40 Wrong printhead installed. Go to “Laser scanning unit (LSU) service check” on page 125. 111.50 Open-loop printhead error, open-loop sweep state. 111.51 Open-loop printhead error, open-loop sweep state. 111.52 Open-loop printhead error, check prelim amp state.
Page 125 4514-330 Laser scanning unit (LSU) service check Action Step 1 Go to step 3. Go to step 2. Make sure that the LSU and controller board are compatible. • Check the serial number of the printer to determine whether the LSU is galvo or polygon. The LSU is galvo if the sixth digit character assigned is in the 0–9 or B–N range (example: 4514 20HH 007CR).
Page 126: 121 Errors
4514-330 Action Step 6 Go to step 7. The problem is solved. Check the LSU for damages, and replace if necessary. Installation note: Mechanical and electronic LSU adjustments are required to complete the installation of the LSU. See “Printhead assembly adjustments” on page 204.
Page 127: Fuser Service Check
4514-330 Error code Description Action 121.30 Fuser failed to reach printing temperature by the Go to “Fuser service check” on page 127. time a page reached the fuser. 121.31 Fuser is too hot. Global temperature check. 121.32 Open fuser main thermistor. 121.33 Open fuser edge thermistor.
Page 128: 126 Errors
4514-330 Action Step 4 Perform an LVPS Replace the fuser. service check. See “Fuser Turn off the printer. “LVPS service removal” on Remove the rear door and cover. check” on page 276. Disconnect the fuser cable connected to PCN5 of the power page 128.
Page 129: 132 Errors
4514-330 Action Step 3 Contact your next Replace the power level of support. supply. See “Power Turn off the printer. supply removal” on Remove the power cord. page 252. Measure the resistance between terminals A and D of the power supply socket. Is the resistance approximately 30 ohms? 132 errors 132 error messages...
Page 130: Errors
Go to step 2. The problem is solved. Check if the imaging unit is a supported and genuine Lexmark supply. If not, then replace it. Make sure that the imaging unit is properly installed. Make sure that the latest ﬁrmware is installed.
Page 131: 140 Errors
4514-330 Action Step 5 Go to step 6. The problem is solved. Clean the CTLS. Does the problem remain? Step 6 Go to step 7. Reseat the cables. • Check the cable PCN3 for proper connection to the power supply. •...
Page 132: 155 Errors
4514-330 Action Step 3 Go to “LVPS service Replace the main check” on page 128. drive gearbox. See Check the main drive motor for proper operation: “Main drive gearbox Remove the main drive gearbox. removal” on Note: Do not disconnect the main drive gearbox cable. page 208.
Page 133: Procedure Before Starting The 9Yy Service Checks
4514-330 Action Step 3 Go to step 4. The problem is solved. Remove, and then reinstall the toner cartridge. Make sure that it is properly seated. Check the toner cartridge, toner cartridge button, and cartridge plunger for damage. Replace if necessary. Make sure that the latest ﬁrmware is installed.
Page 134 4514-330 A. Collecting the history information from the SE menu Note: Make sure that your printer is connected to a network or to a print server. Open a Web browser, type http://printer_IP_address/se, and then press Enter. Notes: printer_IP_address is the TCP/IP address of the printer •...
Page 135: 900 Errors
133. Determine the operating system used when the error occurred. If possible determine whether a PostScript or PCL ﬁle was sent to the device when the error occurred. Ask the customer which Lexmark Solutions applications are installed on the device.
Page 136 4514-330 Action Step 1 Go to step 2. The problem is solved. POR the printer. Does the error remain? Step 2 Go to step 3. Go to step 6. Write down the exact 900.xx error code displayed on the device. Turn off the printer.
Page 137 4514-330 Action Step 7 Go to step 8. Go to step 10. Note: Before performing this step, write down the following information about the ﬁle being sent to the printer: • Application used • Operating system • Driver type • File type (PCL, PostScript, XPS, etc.) Reattach the communications cable.
Page 138 4514-330 Action Step 15 Go to step 31. The problem is solved. Install a Lexmark recommended memory option. Send a print job to the printer. Does the error remain? Step 16 Go to step 17. Go to step 21. Is there a modem installed? Step 17 Go to step 18.
Page 139 4514-330 Action Step 24 Go to step 25. The problem is solved. Upgrade the ﬁrmware if it was not upgraded in a previous step. Note: Contact your next level of support for the correct ﬁrmware level to use. POR the printer. Send the printer a print job.
Page 140: Errors
4514-330 Action Step 31 Contact your next level of support. You will need the following information: • Exact 900.xx error digits and complete error message • Printed menu settings page • Printed network settings page • Device error log • A sample print ﬁle if the error appears to be isolated to a single ﬁle •...
Page 141: Errors
4514-330 950–958 errors 950–958 error messages Error code Description Action 950.xx NVRAM mismatch failure—mismatch between Go to “NVRAM mismatch failure service check” controller board EEPROM and control panel mirror. on page 141. ".xx" codes: • 00-29— mismatch between system and mirror •...
Page 142 4514-330 Warning—Potential Damage: These components can be used as a method of troubleshooting as long as the machine is booted into diagnostic mode or is operating in diagnostic mode. Once a component has been installed in a machine and powered up into user mode, it cannot be used in another machine. It must be returned to the manufacturer.
Page 143: Errors
4514-330 959 errors 959 error messages Error code Description Action 959.01 Controller veriﬁcation failure of pensive boot code Go to “Invalid ﬁrmware/controller board service check” on page 144. 959.02 Failure to authenticate Signature Veriﬁcation Code 959.03 Signature Veriﬁcation Code failed to authenticate a code partition 959.04 Jump to unveriﬁed address...
Page 144: 96Y Errors
4514-330 Invalid ﬁrmware/controller board service check Action Update the ﬁrmware. Replace the The problem is controller board. See solved. Note: Contact the next level of support for the correct ﬁrmware “Controller board level. removal” on page 223. Does the error remain? 96y errors 96y error messages Error code Description...
Page 145: 97Y Errors
4514-330 97y errors 97y error messages Error code Description Action 975.xx Network error—Unrecognizable network port. Go to “Network port error service check” on page 145. 976.xx Network error—Unrecoverable software error in network port. 978.xx Network error—Bad checksum while programming network port. 979.xx Network error—Flash parts failed while programming network port.
Page 146: 98Y Errors
4514-330 98y errors 98y error messages Error code Description Action 980.xx Engine experiencing unreliable communication Go to “Option communication error service with the speciﬁed device. check” on page 146. 981.xx Engine protocol violation detected by the speciﬁed device. 982.xx Communications error detected by the speciﬁed device.
Page 147: 99Y Errors
4514-330 Action Step 5 Go to step 6. The problem is solved. Make sure that both ends of the interconnect cables are properly connected to the controller board and engine options card. Does the problem remain? Step 6 Go to step 7. The problem is solved.
Page 148: Input Option Hardware Errors
4514-330 Input option hardware errors 3yy error messages Error code Description Action 321.51 Motor 1 (Pick/Lift) motor no ﬁrst encoder Go to “Option tray pick/lift motor service check” on page 150. 321.52 Motor 1 (Pick/Lift) motor stop error Go to “Option tray pick/lift motor service check”...
Page 149 4514-330 Error code Description Action 332.56 Motor 2 (Separator/Passthru) PWM underﬂow Go to “Option tray separator/pass through (motor overspeed) motor service check” on page 150. 334.57 Motor 3 motor no ﬁrst encoder Go to “Option tray ACM motor service check” on page 151.
Page 150: Option Tray Pick/Lift Motor Service Check
4514-330 Option tray pick/lift motor service check Action Step 1 Go to step 2. Replace the tray insert. Remove the option tray insert. Check the lift plate and gears for proper operation by moving the metal plate. Do the lift plate and gears move freely, and are they free of wear or damage? Step 2 Go to step 3.
Page 151: Option Tray Acm Motor Service Check
4514-330 Option tray ACM motor service check Action Step 1 Go to step 2. Reseat the cable. Check the cable J11 on the option tray controller card. Is it properly connected? Step 2 Go to step 3. Replace the ACM assembly.
Page 152: Other Symptoms
4514-330 Other symptoms Base printer symptoms Symptom Action Buttons on the control panel failed to Go to “Control panel button service check” on page 154. respond Go to “Cooling fan service check” on page 152. • Fan does not come on •...
Page 153: Dead Machine Service Check
4514-330 Dead machine service check Action Step 1 Go to step 2. The problem is solved. Check the power cord for continuity. Replace if necessary. Make sure the nominal voltage source is within speciﬁcation. “Electrical speciﬁcations” on page 309. Step 2 Go to step 3.
Page 154: Control Panel Button Service Check
4514-330 Action Step 4 The problem is Go to step 5. solved. Properly connect all the cables on the controller board. Does the error remain? Step 5 Go to step 7. Go to step 6. Unplug the cable JPS1 from the controller board, and verify the following voltages from the cable: •...
Page 155: Control Panel Service Check
The problem is solved. Check if the toner cartridge is a supported and genuine Lexmark supply. If not, then replace it. Make sure that the toner cartridge is properly installed. Check the toner cartridge and toner cartridge button for damage. Replace if necessary.
Page 156 4514-330 Action Step 2 Go to step 5. Go to step 3. Check the cartridge plunger. Is the cartridge plunger properly attached to the front door and is the spring functioning properly? Step 3 The problem is Go to step 4. solved.
Page 157: Usb Print Service Check
Have the network administrator verify that the device is using the correct SSID, and wireless security protocols. For more network troubleshooting information, consult the Lexmark Network Setup Guide. Diagnostics and troubleshooting...
Page 158 4514-330 Actions Step 1 Go to step 3. If the Go to step 2. network is wireless, If the device is physically connected to the network, verify that the then go to step 3. Ethernet cable is properly connected on both ends. Is the cable properly connected? Step 2 The problem is...
Page 159 4514-330 Actions Step 11 The problem is Go to step 12. solved. Using the subnet address supplied by the network administrator, assign a unique IP address to the printer. Note: The printer IP address should match the IP address on the printer driver.
Page 160 4514-330 Actions Step 22 Go to step 24. Go to step 23. Verify that the antenna is properly connected to the wireless card. Is it connected correctly? Step 23 The problem is Go to step 24. solved. Properly connect the antenna. Did this ﬁx the problem? Step 24 The problem is...
Page 161: Service Menus
4514-330 Service menus Understanding the printer control panel Using the printer control panel Use the Menus button Open the menus. Notes: • The menus are available only when the printer is in the Ready state. • Pressing the button while navigating within the menus returns the printer control panel to the top‑level menu screen.
Page 162: Understanding The Colors Of The Indicator And Sleep Button Lights
4514-330 Use the Select button • Open a menu. • Display available values or settings for a menu. The current default setting is indicated by an asterisk (*). • Save the displayed value as the new user default setting. Left arrow button •...
Page 163: Menus List
4514-330 Menus list Paper Menu Reports Network/Ports Default Source Menu Settings Page Active NIC Paper Size/Type Device Statistics Standard Network Conﬁgure MP Network Setup Page Reports Substitute Size Proﬁles List Network card Paper Texture Print Fonts TCP/IP Paper Weight Print Directory IPv6 Paper Loading Asset Report...
Page 164: Print Tests
4514-330 The Quick test page contains the following information: • Printer registration settings • Code levels • Alignment diamonds at the top, bottom, and each side • Horizontal lines for skew adjustment • General printer information, including current page count, installed memory, processor speed, serial number, engine ID, and system card ID Change the value of any of the margin settings.
Page 165: Hardware Tests
4514-330 Note: This test cannot be canceled after it has begun. If duplex is activated, then the report is printed in duplex. To print the Print quality pages: From the Diagnostics menu, navigate to Print Tests > Print Quality Pages. Hardware Tests If the hardware test fails, replace the failing part.
Page 166: Duplex Tests
4514-330 F:##### represents the number of times the memory test failed and ﬁnished with errors. • The maximum pass count is 999,999. After the maximum pass or fail count is reached or when all the DRAM has been tested, the test stops and the ﬁnal results appear.
Page 167 4514-330 • Horizontal lines for skew adjustment • General printer information, including current page count, installed memory, processor speed, serial number, engine ID, and controller board ID Check the Quick test page for the correct offset between the placement of the ﬁrst scan line on the front and back side of a duplexed sheet.
Page 168: Input Tray Tests
4514-330 To run this test: From the Diagnostics menu, navigate to: Duplex Tests > Sensor Test Testing… appears while the printer is verifying the state of the sensor. The control panel displays the current state of the sensor. Manually actuate the sensor to make it toggle between Open and Closed. If the sensor does not toggle, then it is malfunctioning.
Page 169: Output Bin Tests
4514-330 Sensor Test Use this test to determine if the input tray sensors are working correctly. From the Diagnostics menu, navigate to: Input Tray Tests > Sensor Test Select the input source. All installed sources appear. Not all sensors appear for all trays. The following table indicates which tray sensors are available for each input source: Input source Tray empty sensor Pass through sensor...
Page 170: Base Sensor Test
4514-330 Base Sensor Test Use this to determine that the sensors located inside the printer are operating correctly. The following sensors can be checked using this test: • Narrow Media • Input • Exit/Output • Front Door CAUTION—SHOCK HAZARD: Do not use your hand to toggle these switches. Use a nonconducting item.
Page 171: Printer Setup
4514-330 Printer Setup Defaults Warning—Potential Damage: Modiﬁcation of the printer setting defaults causes the NVRAM space to be restored to the printer factory settings. This setting is used by the printer to determine whether US or non-US factory default values should be used. The following printer settings have different US and non-US values: Printer default values US value...
Page 172: Ep Setup
4514-330 Engine Setting [x] These settings are used by Engine code ECs to ﬁx ﬁeld problems. The value of [x] is any value from 1 to 16. Edge to Edge When set to On, this shifts all four margins (top, bottom, left, and right) to the physical edge of the page (printable area of a supported paper size).
Page 173 4514-330 Transfer Adjust This setting controls the transfer roll algorithm. To adjust this setting: From the Diagnostics menu, navigate to: EP Setup > Transfer Adjust Press OK to save any changes. Print Contrast This setting controls the developer voltage offset. To adjust this setting: From the Diagnostics menu, navigate to: EP Setup >...
Page 174: Reports
4514-330 Each time this setting executes, the printer performs the following: • Calibrates its toner density sensor • Measures the reﬂectivity of its bare drum • Prints patches on the drum and measures the reﬂectivity of the drum through the patches •...
Page 175: Exit Diags
4514-330 The speciﬁc events that appear in the report vary depending on the operational history of the printer. Logs may be printed from the following events: • Job accounting log failures • NV reset failures • NV mirror entries • 9yy and 1yy (print engine) service error entries •...
Page 176: Factory Defaults
4514-330 Turn on the printer. Release the buttons when a line of dots appears. Factory Defaults This restores the printer's settings to the network settings (on network models only) or to the base printer settings. Restore Base Warning—Potential Damage: This operation cannot be undone. This restores all non-critical base device NVRAM settings to their factory default settings.
Page 177: Tray Linking
4514-330 To print the Event log: From the Conﬁguration menu, navigate to Reports > Event Log. Tray Linking This feature links all trays with the same paper size and type. When a tray becomes empty, the printer will feed paper from the linked tray. Available options: •...
Page 178: Safe Mode
4514-330 Available options: • • Safe Mode The settings for this menu item are On and Off (default). When enabled, Safe Mode lets the printer operate in a special limited mode in which it attempts to continue offering as much functionality as possible despite known issues.
Page 179: Font Sharpening
4514-330 Font Sharpening This allows a user to set a text point-size value below which the high‑frequency screens will be used when printing font data. Available options: • • USB Speed This setting is used to set the throughput of the USB port on the printer. Available options: •...
Page 180: Accessing The Network Se Menu
4514-330 Turn on the printer. Release the buttons when a line of dots appears. Accessing the Network SE menu This menu contains settings for ﬁne tuning the communication settings for the network interfaces and protocols. Navigate to: Networks/Ports > Standard Network > Standard Network Setup. Press and hold simultaneously.
Page 181 4514-330 Top level menu Intermediate menu TCP/IP • netstat‑r • arp‑a • Allow SNMP Set • • Meditech Mode • RAW LPR Mode • Gather Debug • Enable Debug Service menus...
Page 182 4514-330...
Page 183: Parts Removal
4514-330 Parts removal Removal precautions CAUTION—SHOCK HAZARD: For personal safety and to prevent damage to the printer, remove the power cord from the electrical outlet before you connect or disconnect any cable, electronic board or assembly. Data security notice This printer contains various types of memory that are capable of storing device and network settings, information from embedded solutions, and user data.
Page 184: Handling Esd-Sensitive Parts
4514-330 Handling ESD‑sensitive parts Many electronic products use parts that are known to be sensitive to electrostatic discharge (ESD). To prevent damage to ESD-sensitive parts, use the following instructions in addition to all the usual precautions, such as turning off power before removing logic boards: •...
Page 185: Restoring The Printer Conﬁguration After Replacing The Controller Board
Note: The software bundle contains the latest version of the ﬁrmware, applications, and software licenses from the Lexmark Virtual Solutions Center (VSC). The printer ﬁrmware may be at a different level from what was used before replacing the controller board.
Page 186 4514-330 Save the zip ﬁle. Note: Make sure that the serial number in the zip ﬁle matches the serial number of the printer being restored. Extract the contents of the zip ﬁle, open the Readme ﬁle, and then follow the instructions in the ﬁle. Notes: •...
Page 187 4514-330 After performing the installation instructions in the Readme ﬁle, conﬁrm from the customer if all the eSF apps have been installed. Notes: • If you are unable to access the administrative menus to verify that the printer is restored, then ask the customer for access rights.
Page 188: Restoring Solutions, Licenses, And Conﬁguration Settings
4514-330 Restoring solutions, licenses, and conﬁguration settings To load the zip ﬁles that are extracted from the Service Restore Tool, do the following: Open a Web browser, and then type the printer IP address. Navigate to Settings > Conﬁguration Files. From the Conﬁguration File History tab, navigate to Import >...
Page 189: Updating The Printer Firmware
4514-330 Click Import. Repeat steps 3 through 5 for the other zip ﬁles that are included in the expanded zip ﬁle. Updating the printer ﬁrmware Warning—Potential Damage: Before updating the printer ﬁrmware, ask the next level of support for the correct code.
Page 190: Ribbon Cable Connectors
4514-330 Using a network computer Using the File Transfer Protocol (FTP) Make sure that the printer is in ready state before ﬂashing the printer. Turn on the printer. Obtain the IP address: • From the home screen • From the TCP/IP section of the Network/Ports menu From the command prompt of a network computer, open an FTP session to the printer IP address.
Page 191: Horizontal Top Contact Connector
4514-330 • Vertical mount contact connector • Horizontal sliding connector Horizontal top contact connector This FRU contains a horizontal top contact cable connector. Read the instructions before proceeding. The horizontal top contact connector uses a back ﬂip locking actuator to lock the ribbon cable into the Zero Insertion Force (ZIF) connector.
Page 192 4514-330 Inserting a cable into the horizontal top contact connector When installing the cable, check the locking actuator to ensure it is in the unlocked position. The tabs on the ends of the actuator are vertical when the actuator is unlocked. Insert the cable with the contacts on the cable facing up.
Page 193 4514-330 Rotate the locking actuator to the locked position. The cable should not move while this step is performed. If the cable moves, open the actuator, reposition the cable, and then close the actuator to the down position. Parts removal...
Page 194: Horizontal Bottom Contact Connector
4514-330 Horizontal bottom contact connector This FRU contains a horizontal bottom contact cable connector. Read the instructions before proceeding. The horizontal bottom contact connector uses a ﬂip locking actuator to lock the ribbon cable into the Zero Insertion Force (ZIF) connector. The cable is inserted horizontally into the connector. Warning—Potential Damage: When opening or closing this type of actuator, gently lift the center of the actuator using your ﬁnger.
Page 195 4514-330 Inserting a cable into the horizontal bottom contact connector Check the actuator to verify it is in the open position. Insert the cable into the ZIF connector with the contacts facing downward and away from the locking actuator. The cable needs to be inserted below the actuator. Note: Verify that the cable is installed squarely into the connector.
Page 196 4514-330 Place your ﬁnger in the middle of the actuator, and then rotate the locking actuator to the locked position. Parts removal...
Page 197: Vertical Mount Contact Connector
4514-330 Vertical mount contact connector This FRU contains a vertical mount contact connector. Read the instructions before proceeding. The vertical mount contact connector uses a back ﬂip locking actuator to lock the ribbon cable into the Zero Insertion Force (ZIF) connector. The cable is inserted vertically into the connector. Warning—Potential Damage: When opening or closing this type of actuator, gently lift the center of the actuator using your ﬁnger.
Page 198 4514-330 Inserting a cable into the vertical mount contact connector When installing the cable, check the locking actuator to verify it is in the open position. Insert the cable with the contacts on the cable away from the locking actuator. Insert the cable on top of the actuator.
Page 199 4514-330 Rotate the locking actuator to the locked position by pressing down on both ends of the actuator. The cable should not move when this step is performed. If the cable moves, open the actuator, reposition the cable, and then close the actuator to the down position. Parts removal...
Page 200: Horizontal Sliding Contact Connector
4514-330 Horizontal sliding contact connector This FRU contains a horizontal sliding contact connector. Read the instructions before proceeding. The horizontal sliding contact connector uses a slide locking actuator to lock the ribbon cable into the Zero Insertion Force (ZIF) connector. The cable is inserted horizontally into the connector. Warning—Potential Damage: When opening or closing this type of actuator, gently push or pull the two tabs located on each end of the actuator.
Page 201 4514-330 Inserting a cable into the horizontal sliding contact connector When installing the cable, check the locking actuator to verify it is in the open position. If you are opening the connector, pull back on both end tabs using equal force to avoid breaking the connector. Insert the cable with the contacts on the cable facing away from the locking actuator.
Page 202 4514-330 Slide the locking actuator towards the connector, locking the cable into place. The cable should not move when this step is performed. If the cable moves, open the actuator, reposition the cable, and then close the actuator to the down position. Parts removal...
Page 203: Low Insertion Force (Lif) Connector
4514-330 Low Insertion Force (LIF) connector This FRU contains a Low Insertion Force (LIF) connector. Read the instructions before proceeding. Warning—Potential Damage: When installing a cable into an LIF connector, care must be taken to avoid bending the edges of the cables and damaging the contacts on the cables. Inserting a cable into the LIF connector Looking at the connector, take note on which side the contacts are located.
Page 204: Printhead Assembly Adjustments
4514-330 Printhead assembly adjustments Printhead assembly mechanical adjustment A printhead needs to be correctly positioned after it has been removed. Use a sharp pencil or a small, ﬂat-blade screwdriver to mark the location of the old printhead on the printer frame. Align the new printhead relative to the location of the old printhead.
Page 205 4514-330 Fold a second vertical fold near the center so that the left side top edge aligns with the right side top edge. If the grid lines of the right ﬂap align below the corresponding lines on the left ﬂap, then adjust the printhead clockwise relative to the printer, and recheck.
Page 206 4514-330 Sample Quick test page. Use the actual sheet. From the Registration menu, select the Right margin setting: Diagnostics Menu > Registration > Right Margin To determine the Right margin setting: Choose the value of the darkest bar on the right side of the Quick test page. Add that value to the current Right margin setting found on the left side of the Quick test page.
Page 207: Removal Procedures
4514-330 Removal procedures Keep the following tips in mind as you replace parts: • Some removal procedures require removing cable ties. You must replace cable ties during reassembly to avoid pinching wires, obstructing the paper path, or restricting mechanical movement. •...
Page 208: Main Drive Gearbox Removal
4514-330 Main drive gearbox removal Remove the left cover. See “Left cover removal” on page 207. Squeeze the latch, and then detach the link from the front door. Parts removal...
Page 209 4514-330 Remove the 4 screws (A), and then remove the main drive gearbox. Disconnect the cable from the main drive gearbox. Parts removal...
Page 210: Mpf Solenoid Removal
4514-330 Remove the spring (B) and the fuser gear (C). MPF solenoid removal Remove the left cover. See “Left cover removal” on page 207. Remove the main drive gearbox. See “Main drive gearbox removal” on page 208. Disconnect the MPF solenoid cable from the controller board. Remove the screw (A).
Page 211 4514-330 Cut the cable (B). Remove the other half of the cable from the printer. Installation notes: Install the MPF solenoid. Secure the cable to the holder (A). Parts removal...
Page 212 4514-330 Insert the cable into the hole (B). Route the cable using the new path, and secure it with a cable tie (C). Parts removal...
Page 213: Mpf Gearbox Removal
4514-330 MPF gearbox removal Remove the left cover. See “Left cover removal” on page 207. Remove the main drive gearbox. See “Main drive gearbox removal” on page 208. Remove the front door. See “Front door removal” on page 244. Disconnect the spring (A) from the printer. Parts removal...
Page 214 4514-330 Remove the three screws (B), and then remove the left front mount. Parts removal...
Page 215 4514-330 Remove the three screws (C), and then remove the MPF gearbox. Release the two latches (D), and then remove the main input drive gears. Parts removal...
Page 216: Reverse Solenoid Removal
4514-330 Remove the E-clip (E), and then remove the MPF sector gear (F). Reverse solenoid removal Remove the right cover. See “Right cover removal” on page 222. Remove the left cover. See “Left cover removal” on page 207. Remove the rear door and cover. See “Rear door and cover removal”...
Page 217: Acm Clutch Removal
4514-330 Remove the two screws (A) securing the reverse solenoid. ACM clutch removal Remove the left cover. See “Left cover removal” on page 207. Remove the right cover. See “Right cover removal” on page 222. Remove the main drive gearbox. See “Main drive gearbox removal”...
Page 218 4514-330 Remove the screw (B). Pull out the ACM clutch, and cut the cable to detach the ACM clutch. Remove the other half of the cable from the printer. Installation notes: Pull out the shaft. Reinstall the ACM clutch. Route the cable using the new path. Parts removal...
Page 219: Cartridge Gearbox Removal
4514-330 Secure the cable with a cable tie (A). Cartridge gearbox removal Remove the left cover. See “Left cover removal” on page 207. Remove the four screws (A) securing the cartridge gearbox. Disconnect the cable from the cartridge gearbox. Parts removal...
Page 220: Duplex Gear Assembly Removal
4514-330 Duplex gear assembly removal Remove the left cover. See “Left cover removal” on page 207. Remove the rear door and cover. See “Rear door and cover removal” on page 270. Remove the power supply. See “Power supply removal” on page 252.
Page 221 4514-330 From behind the three gears, remove the duplex coupling (D). Remove the duplex link (E) from the duplex. Parts removal...
Page 222: Right Side Removals
4514-330 Right side removals Right cover removal Open the front door. Position the printer so that it sits on its left side. Remove the two screws (A) securing the right cover. Release the latches (B) to remove the right cover. Cooling fan duct removal Note: This is not a FRU.
Page 223: Controller Board Removal
4514-330 Remove the two screws (A) securing the fan mount to the printer. Remove the two screws (B) securing the fan to the fan mount. Controller board removal Remove the right cover. See “Right cover removal” on page 222. Disconnect all cables from the controller board. Parts removal...
Page 224 4514-330 Remove the three screws (A) from the rear side of the printer. Remove the ﬁve screws (B) securing the controller board. Installation note: After installing a new controller board, perform the printer conﬁguration restoration. See “Restoring the printer conﬁguration after replacing the controller board” on page 185.
Page 225: Toner Cartridge Smart Chip Contact Removal
4514-330 Toner cartridge smart chip contact removal Remove the right cover. See “Right cover removal” on page 222. Disconnect the cable JARW1 from the controller board. Remove the two screws (A). Remove the two screws (B), and then detach the right cartridge guide. Warning—Potential Damage: Do not cut or disconnect the cable at the rear of the right cartridge guide.
Page 226 4514-330 From behind the right cartridge guide, release the 4 latches (C) to detach the toner cartridge smart chip contact. Note: Pay attention to the original position of the spring and the actuators. Parts removal...
Page 227: Front Removals
4514-330 Installation notes: Test for proper installation of the spring and the actuators. Press the cartridge actuator. The cartridge lock should move up. Release the cartridge actuator. The cartridge lock should move back to its original position. Front removals Left front mount removal Remove the left cover.
Page 228 4514-330 Disconnect the spring (A) from the printer. Remove the three screws (B), and then remove the left front mount. Parts removal...
Page 229: Right Front Mount Removal
4514-330 Right front mount removal Remove the right cover. See “Right cover removal” on page 222. Disconnect all control panel cables from the controller board. Disconnect the cable JCVR1 from the controller board. Remove the screw (A) to disconnect the ground wire. Parts removal...
Page 230 4514-330 Remove the four screws (B), and then remove the right front mount. Parts removal...
Page 231: Transfer Roll Removal
4514-330 Transfer roll removal Warning—Potential Damage: Do not touch the transfer roll with bare hands. Oil from the skin can damage it. Squeeze the latches at each end of the transfer roll. Lift to remove the transfer roll. Warning—Potential Damage: Do not remove the spring under the left latch. Doing so will damage the printer.
Page 232: Cartridge Plunger Removal
4514-330 Cartridge plunger removal Open the front door. Tilt the cartridge plunger. Parts removal...
Page 233 4514-330 Twist and then remove the cartridge plunger. Installation notes: Use a spring hook to hold the spring, and then reinstall the cartridge plunger. Parts removal...
Page 234 4514-330 Set the spring over the plunger. Parts removal...
Page 235: Bezel Removal
4514-330 Bezel removal Open the front door. Push the latches (A) at the left side to remove the bezel. Parts removal...
Page 236: Nameplate Removal
4514-330 Nameplate removal Open the front door. Remove ﬁve screws (A) securing the nameplate. Control panel assembly removal Remove the right cover. See “Right cover removal” on page 222. Remove the nameplate. See “Nameplate removal” on page 236. Remove the bezel. See “Bezel removal”...
Page 237 4514-330 Remove the screw (A) securing the ground connector to the controller board. Disconnect the cable JOPP1 or JOPP2 from the controller board. Remove the screw (B) from the right front mount, and route the cable through the slot. Parts removal...
Page 238: Uicc Removal
4514-330 Remove the two screws (C) securing the control panel assembly. Route all cables off the printer to completely remove the control panel assembly. UICC removal Remove the right cover. See “Right cover removal” on page 222. Remove the nameplate. See “Nameplate removal”...
Page 239: Mpf Assembly Removal
4514-330 MPF assembly removal Remove the nameplate. See “Nameplate removal” on page 236. Remove the two springs (A). Parts removal...
Page 240 4514-330 Squeeze the latches (B) to release the left and right links. Parts removal...
Page 241 4514-330 Release the lock (C) remove the MPF link. Do the same on the other MPF link. Release the right tab (D) of the MPF. Slide the MPF assembly to remove. Parts removal...
Page 242: Mpf Pick Roller Cover Removal
4514-330 MPF pick roller cover removal Open the front door. Remove the two screws (A), and then remove the MPF pick roller cover. MPF pick roller removal Remove the MPF pick roller cover. See “MPF pick roller cover removal” on page 242.
Page 243: Bail Removal
4514-330 Warning—Potential Damage: Do not touch the pick tire with bare hands, as this can damage the pick roller. Bail removal Remove the MPF pick roller cover. See “MPF pick roller cover removal” on page 242. Rotate the bail. Squeeze the latches, and then remove the bail. Jam access cover removal Remove the MPF pick roller cover.
Page 244: Front Door Removal
4514-330 Remove the four screws (A), and then remove the jam access cover. Front door removal Note: This is not a FRU. Remove the right cover. See “Right cover removal” on page 222. Disconnect the cable JOPP1 or JOPP2 from the controller board. Disconnect the cable JCVR1 from the controller board.
Page 245 4514-330 Squeeze the latch, and then detach the link from the front door. Remove the screw (A) to disconnect the ground wire. Parts removal...
Page 246 4514-330 Remove the four screws (B). Remove the right front mount, and then remove the front door. Below are the front door and the right front mount. Installation notes: Mount the left side of the front door to the printer. Attach the right front mount to the front door.
Page 247: Front Access Cover Removal
4514-330 Install the right front mount to the printer. Front access cover removal Remove the right cover. See “Right cover removal” on page 222. Remove the front door. See “Front door removal” on page 244. Remove the nameplate. See “Nameplate removal” on page 236.
Page 248: Front Input Guide Removal
4514-330 Front input guide removal Remove the right cover. See “Right cover removal” on page 222. Remove the front door. See “Front door removal” on page 244. Remove the MPF pick roller cover. See “MPF pick roller cover removal” on page 242.
Page 249 4514-330 Rotate the MPF shaft inward so that the cams at each end point up. Release the front guide from the guides at each end. Installation note: The cams at each end of the MPF shaft must point down. Parts removal...
Page 250: Separator Pad Removal
4514-330 Separator pad removal Remove the right cover. See “Right cover removal” on page 222. Remove the front door. See “Front door removal” on page 244. Remove the MPF pick roller cover. See “MPF pick roller cover removal” on page 242.
Page 251 4514-330 While pressing down the MPF sensor ﬂag and separator pad, move the restraint roller (G) to the right. Remove the E‑clip (H), and then move the shaft (I) to the right. Remove the separator pad and the spring underneath. Parts removal...
Page 252: Bottom Removals
4514-330 Bottom removals Power supply removal Remove the left cover. See “Left cover removal” on page 207. Remove the rear door and cover. See “Rear door and cover removal” on page 270. Disconnect the cable (A) from the rear, and disconnect the cable (B) from the left side. Position the printer so that it sits on its right side.
Page 253: Power Supply Shield Removal
4514-330 Remove the ﬁve metal screws (D) and the plastic screw (E) securing the power supply. Remove the power supply, and then disconnect all cables from the power supply. Power supply shield removal Remove the left cover. See “Left cover removal” on page 207.
Page 254: Duplex Removal
4514-330 Remove the three screws (A), and then remove the power supply shield. Duplex removal Remove the left cover. See “Left cover removal” on page 207. Remove the rear door and cover. See “Rear door and cover removal” on page 270.
Page 255: Duplex Sensor And Input Sensor Removal
4514-330 Remove the four screws (A) securing the duplex. Note: The duplex link (B) is part of the FRU. Duplex sensor and input sensor removal Remove the left cover. See “Left cover removal” on page 207. Remove the right cover. See “Right cover removal”...
Page 256 4514-330 Remove the power supply. See “Power supply removal” on page 252. Remove the power supply shield. See “Power supply shield removal” on page 253. Remove the duplex. See “Duplex removal” on page 254. Disconnect the cable JDUPPI 1 from the controller board. Remove the two screws (A), and cut the cable near the frame to detach the sensors.
Page 257: Toner Density Sensor Removal
4514-330 Toner density sensor removal Remove the left cover. See “Left cover removal” on page 207. Remove the main drive gearbox. See “Main drive gearbox removal” on page 208. Remove the rear door and cover. See “Rear door and cover removal” on page 270.
Page 258 4514-330 Remove the two screws (B), and then remove the sensor. Disconnect the cable from the sensor. Parts removal...
Page 259 4514-330 Installation notes: Apply RheoGel 793 to the top and bottom of the shutter blade extension. Apply RheoGel 793 to the point of contact between the bracket (A) and cam. Parts removal...
Page 260: Trailing Edge Sensor Removal
4514-330 Apply RheoGel 793 to the point of contact to the lower edge (B) where the wiper bracket glides. Trailing edge sensor removal Remove the left cover. See “Left cover removal” on page 207. Remove the right cover. See “Right cover removal” on page 222.
Page 261 4514-330 Remove the screw (A), and then remove the sensor. Remove the other half of the cable from the printer. Installation notes: Install the sensor to the ACM. Route the cable along the two cable holders on the side of the ACM. Note: Make sure that the cable is not loose.
Page 262 4514-330 Bring the cable in front of the two cable holders near the ACM shaft. Parts removal...
Page 263 4514-330 Loop the cable behind the right cable holder. Twist the cable so that it forms a loop. Parts removal...
Page 264 4514-330 Place the loop over the left cable holder. Pull the free end to make sure that the cable is tightly looped around the cable holders. Parts removal...
Page 265: Acm Assembly Removal
4514-330 Route the cable using the new path, and secure it with a cable tie (A). ACM assembly removal Remove the left cover. See “Left cover removal” on page 207. Remove the main drive gearbox. See “Main drive gearbox removal” on page 208.
Page 266 4514-330 While blocking the roller, remove the screw (B). Pull out the ACM clutch, and leave it hanging. Remove the screw (C) and then detach the trailing edge sensor. Parts removal...
Page 267 4514-330 Disconnect the two springs (D). Parts removal...
Page 268 4514-330 Pry the pointed end of the ACM bushing to release the locking pin underneath. Rotate, and then remove the ACM bushing. Pry the pointed end of the 2nd pickup pushing to release the locking pin underneath. Parts removal...
Page 269 4514-330 Rotate, and then remove the 2nd pickup bushing. Pull out the shaft, and remove the ACM. Parts removal...
Page 270: Rear Side Removals
4514-330 Rear side removals Dust cover removal Press the latches on each side of the dust cover. Remove the dust cover. Rear door and cover removal Position the printer so that it sits on either its left or right side. Open the rear door at an angle of 45 degrees.
Page 271: Narrow Media/Bin Full Sensor Removal
4514-330 Pull the rear door to remove. Remove the two screws (A) securing the rear cover. Press the two latches to release the rear cover. Narrow media/bin full sensor removal Remove the right cover. See “Right cover removal” on page 222.
Page 272 4514-330 Remove the top cover. See “Top cover removal” on page 277. Disconnect the cable JNRW1 from the controller board. Remove the six screws (A) securing the sensor and upper exit guide to the redrive assembly. Remove the ground (B), sensor (C), and sensor ﬂag (D). Parts removal...
Page 273: Redrive Assembly Removal
4514-330 Redrive assembly removal Remove the right cover. See “Right cover removal” on page 222. Remove the left cover. See “Left cover removal” on page 207. Remove the rear door and cover. See “Rear door and cover removal” on page 270.
Page 274: Redrive Shaft Removal
4514-330 Remove the six screws (B) securing the redrive assembly. Redrive shaft removal Remove the right cover. See “Right cover removal” on page 222. Remove the left cover. See “Left cover removal” on page 207. Remove the rear door and cover. See “Rear door and cover removal”...
Page 275 4514-330 Remove the shaft. If necessary, remove the bushing (B) from the redrive assembly. Installation note: Install the bushing (A) on the redrive assembly before installing the shaft. Parts removal...
Page 276: Fuser Removal
4514-330 Fuser removal Remove the right cover. See “Right cover removal” on page 222. Remove the rear door and cover. See “Rear door and cover removal” on page 270. Remove the redrive assembly. See “Redrive assembly removal” on page 273. Disconnect the cable JEXIT1 from the controller board.
Page 277: Top Side Removals
4514-330 Top side removals Top cover removal Remove the right cover. See “Right cover removal” on page 222. Remove the left cover. See “Left cover removal” on page 207. Remove the rear door and cover. See “Rear door and cover removal” on page 270.
Page 278: Laser Scanning Unit (Lsu) Removal
4514-330 Laser scanning unit (LSU) removal Before performing this task, determine ﬁrst whether your printer supports a galvo or polygon LSU. • Check the serial number of the printer. The LSU is galvo if the sixth digit character assigned is in the 0–9 or B–N range (example: 4514 20HH 007CR).
Page 279 4514-330 The color and location of the cables as well as the screws vary depending on the type of LSU that the printer supports. • For the Galvo LSU, disconnect the two cables (A), and then remove the three screws (B). •...
Page 280: 250/550-Sheet Option Tray Removals
4514-330 Installation notes: • Mechanical and electronic LSU adjustments are required to complete the installation of the LSU. See “Printhead assembly adjustments” on page 204. • When reinstalling the polygon LSU, make sure to follow the sequence, as indicated by the number, in the tightening of the screws;...
Page 281: Separator Roll Assembly Removal
4514-330 Separator roll assembly removal Remove the screw (A) from under the tray insert. Remove the E-clip, and then remove the gear. Parts removal...
Page 282 4514-330 Remove the four screws (B). Push out the top part of the drawer cover, and then remove the separator roll assembly. Parts removal...
Page 283: Acm Assembly Removal
4514-330 ACM assembly removal Remove the seven screws (A), and release the two latches (B) from the top of the drawer. Remove the two screws (C), and then release the two latches under the screws. Parts removal...
Page 284 4514-330 Swing the right cover backward to remove. Remove the screw (D). Parts removal...
Page 285 4514-330 Disconnect the spring (E). Remove the two screws (F), and then remove the controller card cover. Disconnect the cable J11 from the controller card. Route the cable off the option, and then remove the ACM assembly. Parts removal...
Page 286 4514-330...
Page 287: Component Locations
4514-330 Component locations Exterior locations Front view Part name Control panel Paper stop Standard bin Front door release button Controller board access door Standard 250‑sheet tray Optional 250‑ or 550‑sheet tray 50‑sheet multipurpose feeder Front door Component locations...
Page 288: Rear View
4514-330 Rear view Part name USB port USB printer port Ethernet port Parallel port Power switch Power cord socket Security slot These ports are available only in select printer models. Component locations...
Page 289: Maintenance
• Damaged, missing, or altered covers, especially in the area of the top cover and the power supply cover • Possible safety exposure from any non-Lexmark attachments Use the following table to determine when speciﬁed parts should be inspected: PART...
Page 290: Cleaning The Printer
4514-330 Cleaning the printer Note: You may need to perform this task after every few months. Warning—Potential Damage: Damage to the printer caused by improper handling is not covered by the printer warranty. Make sure that the printer is turned off and unplugged from the electrical outlet. CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock when cleaning the exterior of the printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before proceeding.
Page 291 4514-330...
Page 292: Parts Catalog
4514-330 Parts catalog Legend The following column headings are used in the parts catalog: • Asm‑index—Identiﬁes the item in the illustration. • Part number—Identiﬁes the unique number that correlates with the part. • Units/mach—Refers to the number of units actually used in the base machine or product. •...
Page 293: Assembly 1: Covers
4514-330 Assembly 1: Covers Parts catalog...
Page 294 MPF tray links “MPF assembly removal” on page 239 40X8051 Nameplate “Nameplate removal” on page 236 40X9658 Bezel (MS312) “Bezel removal” on page 235 41X1983 Bezel (MS317) “Bezel removal” on page 235 40X8053 Left cover “Left cover removal” on page 207...
Page 295: Assembly 2: Electronics 1
4514-330 Assembly 2: Electronics 1 Parts catalog...
Page 296 4514-330 Assembly 2: Electronics 1 Asm-index Units/mach Units/FRU Description Removal procedure ‑‑ 41X0363 Polygon laser scanning unit (LSU) frame* 41X0362 Polygon LSU* “Laser scanning unit (LSU) removal” on page 278 40X8082 Galvo LSU* “Laser scanning unit (LSU) removal” on page 278 40X8343 Fuser, 100 V “Fuser removal”...
Page 297: Assembly 3: Electronics 2
4514-330 Assembly 3: Electronics 2 Parts catalog...
Page 298 4514-330 Assembly 3: Electronics 2 Asm-index Units/mach Units/FRU Description Removal procedure 40X8048 Front door sensor “Front door sensor removal” on page 247 40X8266 Toner cartridge smart chip “Toner cartridge smart chip contact contact removal” on page 225 40X8046 Toner density sensor “Toner density sensor removal”...
Page 299 4514-330 Parts catalog...
Page 300: Assembly 4: Frame
4514-330 Assembly 4: Frame Parts catalog...
Page 301 4514-330 Assembly 4: Frame Asm-index Units/mach Units/FRU Description Removal procedure 40X8393 Transfer roll “Transfer roll removal” on page 231 40X8298 Redrive assembly “Redrive assembly removal” on page 273 40X8850 Redrive shaft “Redrive shaft removal” on page 274 40X8299 Front mounts “Left front mount removal”...
Page 302 4514-330 Parts catalog...
Page 303: Assembly 5: Option Trays
4514-330 Assembly 5: Option trays Parts catalog...
Page 304 4514-330 Assembly 5: Option trays Asm-index Units/opt Units/FRU Description Removal procedure 40X8287 250-sheet tray 40X8286 550-sheet tray 40X9654 550-sheet tray, lockable 40X8520 Dust cover, 250‑sheet tray “Dust cover removal” on page 270 40X8521 Dust cover, 550‑sheet tray “Dust cover removal” on page 270 40X8262 ACM assembly (option tray...
Page 305: Assembly 6: Power Cords
4514-330 Assembly 6: Power cords Asm-index Units/mach Units/FRU Description Removal procedure 40X0269 Power cord, 2.5 m (straight)—USA, Canada N/A 40X3141 Power cord, 2.5 m (straight)—Europe and others 40X0288 Power cord, 2.5 m (straight)—Argentina 40X0271 Power cord, 2.5 m (straight)—United Kingdom 40X0275 Power cord, 2.5 m (straight)—Israel 40X1772...
Page 306 4514-330 Parts catalog...
Page 307: Assembly 7: Miscellaneous
4514-330 Assembly 7: Miscellaneous Asm-index Units/mach Units/FRU Description Removal procedure 40X8737 RFID card reader 40X8330 MarkNet N8352 802.11 b/g/n Wireless Print Server Kit 40X8570 Font card, Arabic 40X8571 Font card, Hebrew 40X8568 Font card, Korean 40X8569 Font card, Japanese 40X8556 Font card, Traditional Chinese 40X8557 Font card, Simpliﬁed Chinese...
Page 308 4514-330...
Page 309: Printer Speciﬁcations
The product is plugged into an electrical outlet, but the power switch is turned off. The power consumption levels listed in the previous table represent time-averaged measurements. Instantaneous power draws may be substantially higher than the average. Values are subject to change. See www.lexmark.com for current values. Electrical speciﬁcations Low-voltage models •...
Page 310: Operating Clearances
4514-330 Operating clearances Right 110 mm (4.3 in.) Front 305 mm (12 in) Left 65 mm (2.6 in.) Rear 100 mm (3.9 in.) 305 mm (12 in.) Allow additional clearance around the printer for adding the optional input trays. Acoustics All measurements are made in accordance with ISO 7779 and conform with ISO 9296.
Page 311: Operating Environment
4514-330 Operating environment Environment Speciﬁcation Ambient operating environment 10–32°C (50–90°F) 15–80 %RH Extended low humidity operating environment 16–32°C (60–90°F) 8–15 %RH Altitude—operating 0–2896 m (9500 ft) Atmospheric pressure 74.6 kPa Toner cartridge and imaging unit long term storage 1–35°C 8–80 %RH Enabling the security reset jumper The security reset jumper can reset a printer that is locked due to a forgotten password or lost network connectivity.
Page 312 4514-330...
Page 313: Options And Features
4514-330 Options and features Available internal options • Flash memory – Fonts Media handling options Note: Only one optional tray can be installed. • 250-sheet tray • 550-sheet tray Options and features...
Page 314 4514-330...
Page 315: Theory Of Operation
4514-330 Theory of operation POR sequence As the printer turns on, the engine code goes through a series of tests to verify hardware integrity. If a hardware failure is detected, then it is reported to the printer. If the POR sequence cannot be completed successfully, then the printer may post an error message.
Page 316: Simplex Printing
4514-330 The MPF can be accessed by opening the MPF tray on the front door. In an MPF paper feed, the MPF paper present sensor detects the media. The instant the MPF pick roll shaft rotates, the cams on each end of the shaft disengage the MPF tray.
Page 317: Duplex Printing
4514-330 Part Output bin Photoconductor drum Input sensor First input roller Transfer roller Fuser exit roller Fuser assembly Paper exit roller Duplex printing After the ﬁrst side of the media has been printed on and is partially fed out to the output bin, the duplex solenoid activates.
Page 318: Media Handling Components
4514-330 Part First input roller Secondary input roller Duplex front deliver roller Duplex rear deliver roller Paper exit roller Media handling components Main drive gearbox The gearbox supplies all mechanical power requirements of the printer. Its motor, through several gears, transfers power to following paths: photoconductor drum, transfer roll, fuser, paper exit, input, duplex, and MPF.
Page 319: Key Components
4514-330 Key components Sensors Bin full sensor Input sensor Fuser exit MPF paper present sensor sensor Duplex sensor Trailing edge sensor Pass through sensor Index sensor Media present Trailing edge sensor sensor Trailing edge sensor Detects the media’s trailing edge as it passes the pick tires. Among other capabilities, this sensor can be used to determine the paper size sensor and the media stack height.
Page 320: Other Key Components
4514-330 Pass through sensor (option tray) Detects when the media from the option tray passes. This will trigger the pick roller to pick the next media. Capactive Toner Level Sensor (CTLS) Detects the amount of toner in the imaging unit. If the toner level is low, the cartridge auger motor is triggered to add toner from the toner cartridge to the imaging unit.
Page 321: Electrophotographic Process (Ep Process)
4514-330 Rollers Paper exit roller Photoconductor drum Fuser assembly First input roller Fuser exit roller MPF pick roller Secondary input roller Duplex rear deliver roller Transfer roll Pick rollers Duplex front deliver roller Separator roll Pick rollers Electrophotographic process (EP process) Printhead The printhead scans the photo conductor drum surface with a laser beam.
Page 322 4514-330 Step 1: Charge During the charge step, voltage is sent from the HVPS to the charge roll beside the photoconductor. The charge roll applies a uniform negative charge over the entire surface of the photoconductor to prepare it for the laser beam.
Page 323 4514-330 Step 2: Expose The laser ﬁres a focused beam of light at the surface of the photoconductor and writes an invisible image, called a latent image. The laser beam only discharges the surface where the beam hits the photoconductor. This creates a difference in charge potential between the exposed area and the rest of the photoconductor surface.
Page 324 4514-330 This process would be similar to using glue to write on a can and then rolling it over glitter. The glitter sticks to the glue but not to the rest of the can. HVPS Developer Metering Roll Blade Toner DRUM -VDC Drum Surface...
Page 325 4514-330 Step 5: Clean The cleaning blade removes any toner that remains on the photoconductor after the transfer process. The toner removed is collected inside the imaging unit. Used Toner Cleaning Blade Charge roll DRUM Theory of operation...
Page 326 4514-330...
Page 327: Acronyms
4514-330 Acronyms Acronyms ASIC Application-Speciﬁc Integrated Circuit BLDC Brushless DC Motor Black Only Retract Cyan Charge Coupled Device Carbonless Copy Paper Cyclic Redundancy Check Customer Setup CTLS Capacitance Toner Level Sensing DIMM Dual Inline Memory Module DRAM Dynamic Random Access Memory Enhanced Data Out Electrophotographic Process EPROM...
Page 328 4514-330 Microswitch Nonvolatile Memory NVRAM Nonvolatile Random Access Memory Original Equipment Manufacturer Optical Sensor Photoconductor pel, pixel Picture element Power-On Reset POST Power-On Self Test Position Sensing Device Pulse Width Modulation Raster Imaging Processor Read Only Memory SDRAM Synchronous Dual Random Access Memory SIMM Single Inline Memory Module SRAM...
Page 329: Index
4514-330 Index font density 178 Symbols font sharpening 179 [x]‑page jam, open tray 1. [241.xx] 84 menu settings page 176 [x]‑page jam, open tray 2. [242.xx] 85 panel menus 177 PPDS emulation 177 print event log 176 ACM, theory 318 print quality pages 177 acronyms 327 reduced curl 177...
Page 330 4514-330 EP defaults 172 140 error messages 131 exit diagnostics 175 155 error messages 132 ﬂash test 170 200 paper jam messages 87 fuser temperature 172 201 paper jam messages 92 202 paper jam messages 93 gap adjust 173 23y.xx paper jam messages 95 input tray feed test 168 241 paper jam messages 96 input tray sensor test 169...
Page 331 Jam, standard bin [20y.xx] 81 Network error, standard port [54] 110 jams network SE menu accessing 78 accessing 180 avoiding 77 Non‑Lexmark [supply type], see User’s Guide understanding messages 78 [33.xy] 109 jams, clearing notices 309 behind front door 79 behind rear door 82...
Page 332 Network error, port [x] [54] 109 [x]‑page jam, open tray 1. [241.xx] 84 Network error, standard port [54] 110 [x]‑page jam, open tray 2. [242.xx] 85 Non‑Lexmark [supply type], see User’s Guide Bin full. Remove paper. 103 [33.xy] 109 Cannot collate large document [37] 103 Paper too short [34] 110 Cannot defrag ﬂash memory [37] 103...
Page 333 4514-330 Rear USB port disabled [56] 111 front input guide 248 Reinstall missing or unresponsive cartridge fuser 276 [31.xy] 111 input sensor 255 Reinstall missing or unresponsive imaging unit jam access cover 243 laser scanning unit 278 [31.xy] 111 left cover 207 Replace cartridge, 0 estimated pages remain left front mount 227 [88.xy] 111...
Page 334 4514-330 service engineer (SE) menu 180 paper curl 54 accessing 180 print is too dark 50 solid black pages 47 print is too light 52 speciﬁcations repeating defects 57 skewed print 58 acoustics 310 solid black pages 47 electrical 309 streaked vertical lines appear on prints 60 environment 311 operating clearances 310...
Page 335: Part Number Index
4514-330 Part number index Part name Page 40X0269 Power cord, 2.5 m (straight)—USA, Canada..................305 40X0270 Power cord, 2.5 m (straight)—Japan......................305 40X0271 Power cord, 2.5 m (straight)—United Kingdom..................305 40X0273 Power cord, 2.5 m (straight)—Traditional Italy..................305 40X0275 Power cord, 2.5 m (straight)—Israel......................305 40X0288 Power cord, 2.5 m (straight)—Argentina....................305 40X0301...
Page 336 4514-330 Part name Page 40X8083 Cartridge gearbox............................301 40X8085 Main drive gearbox............................301 40X8262 ACM assembly (option tray only)......................304 40X8265 ACM clutch...............................301 40X8266 Toner cartridge smart chip contact......................298 40X8273 Rubber foot..............................294 40X8275 Duplex assembly............................301 40X8276 Cooling fan..............................296 40X8277 Duplex gear assembly..........................301 40X8278 MPF gearbox..............................
Page 337 Adapter, N8130 10/100 ﬁber........................307 40X9654 550-sheet tray, lockable..........................304 40X9656 Controller board for model MS312dn with galvo LSU*............... 296 40X9658 Bezel (MS312)..............................294 41X0362 Polygon LSU*..............................296 41X0363 Polygon laser scanning unit (LSU) frame*....................296 41X0364 Controller board for model MS312dn with polygon LSU*..............296 41X0759 Polygon LSU cable*............................296...
Page 338 4514-330 Part number index...
Page 339: Part Name Index
40X8262 ACM assembly (option tray only)......................304 41X0919 ACM assembly (standard tray only)......................301 40X8265 ACM clutch...............................301 40X9652 Adapter, N8130 10/100 ﬁber........................307 40X9658 Bezel (MS312)..............................294 41X1983 Bezel (MS317)..............................294 40X8083 Cartridge gearbox............................301 40X9148 Cartridge plunger............................294 40X8291 Control panel assembly..........................296 40X9656 Controller board for model MS312dn with galvo LSU*...............
Page 340 4514-330 Part name Page 40X8056 Front access cover............................294 40X8048 Front door sensor............................298 40X8280 Front input guide............................296 40X8299 Front mounts..............................301 40X8343 Fuser, 100 V..............................296 40X8023 Fuser, 110 V..............................296 40X8024 Fuser, 220 V..............................296 40X8082 Galvo LSU*..............................296 40X8279 Jam access cover............................
Page 341 4514-330 Part name Page 40X1772 Power cord, 2.5 m (straight)—Switzerland..................... 305 40X1791 Power cord, 2.5 m (straight)—Taiwan...................... 305 40X0273 Power cord, 2.5 m (straight)—Traditional Italy..................305 40X0271 Power cord, 2.5 m (straight)—United Kingdom..................305 40X0269 Power cord, 2.5 m (straight)—USA, Canada..................305 40X7795 Power supply, 100 V/110 V..........................
Page 342 4514-330 Part name index...
Page 343 CAUTION—SHOCK HAZARD: This type of caution indicates a danger from hazardous voltage in the area of the product where you are working. Unplug the product before you start working, or use caution if the product must receive power to perform the task. CAUTION—POTENTIAL INJURY: The lithium battery in this product is not intended to be replaced.

This manual is also suitable for:

Ms317

Lexmark MS312 Service Manual

Product Information

Edition Notice

Notices, Conventions, and Safety Information

Change History

General Information

Diagnostics and Troubleshooting

Service Menus

Parts Removal

Component Locations

Maintenance

Parts Catalog

Quick Links

Service Manual

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexmark MS312

Summary of Contents for Lexmark MS312
