Grid Installation Instructions
V5 – 8/23/12
Frames and Mini Frames
FRAMES (and MEGA FRAMES)
Cartons contain ONE of Three Types of Frames/ Mini Frames:
a. End of Run (power/data opening in one end)
b. Mid Frame (power/data openings in both ends)
c. Freestanding Frame (no openings, single frame only)
Supports that attach to Grid Frames will be one of four styles (Packed separately):
A. Straight Legs - either with or without power infeed hole. Note: Grid legs are available in 2
heights – the shorter height puts power/data below the wksf while the taller height places
power/data above the top.
B. T-Legs - either with or without power infeed hole.
MINI FRAMES
