Challenger Lifts Versymmetric CL9 Installation, Operation & Maintenance Manual page 17

PARTS BREAKDOWN (continued)
Fig E. Carriage & Arms
ITEM # PART #
A1025
70
A1040
71
A1078
72
A1091
73
A1094-R
74
A1104
75
A1101
76
31061
77
39111
78
A1086-P
79
A1086-I
A1094-F
80
31305
81
31037
82
A1070
83
12568
84
A1075
85
A1073
86
31109
87
A1072
88
36014
89
A1090
A1085-P
A1085-I
A1100
A1077
Replace all worn or broken parts with genuine Challenger Lifts Inc. parts.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. (502) 625-0700 for the Parts Distributor in your area)
Model CL9
Installation, Operation and Maintenance
QTY/LIFT DESCRIPTION
2 CARRIAGE WELD
16 SLIDE BLOCK
4 ARM PIN WELD
2 REAR FEMALE ARM WELD
2 MALE ARM WELD (REAR)
4 FOOT PAD RUBBER INSERT
4 FOOT PAD WELD
8 1/4-20 KEPS NUT
4 FOOT PAD RETAINER RING
1 FRONT FEMALE ARM WELD (POWER)
1 FRONT FEMALE ARM WELD (IDLER)
2 MALE ARM WELD (FRONT)
4 3/8 MALE ARM RETAINER SCREW
4 3/8 LOCK WASHER
4 INNER GEAR
8 3/8-16NCx1 Lg. HEX .FLG.LOCK.HD.C.S. GR.5 ZN PLT
4 PULL RING
4 SHAFT
4 COMPRESSION SPRING (RESTRAINT SHAFT)
4 OUTER GEAR
4 1" EXT. RETAINING RING
2 REAR ARM ASSY
1 FRONT ARM ASSY (POWER)
1 FRONT ARM ASSY (IDLER)
4 FOOT PAD ASSY
4 ARM RESTRAINT SHAFT ASSY
Page 17
(ITEMS NO: 73, 74, 81, 82)
(ITEMS NO: 79, 80, 81, 82)
(ITEMS NO: 79, 80, 81, 82)
(ITEMS NO: 75, 76, 77)
(ITEMS NO: 85, 86, 87, 88, 89)
