Specification
Part Number
Input Power Cable
(Customer Supplied)
Nominal Helium Pressure
Ambient Operating
perature Range
Interface
Gas Supply Connector
Gas Return Connector
Remote Control Receptacle
Adsorber Service Schedule
©2007 Helix Technology Corporation
Table 1-4: General Compressor Operating Specifications
8135901G001
600 VAC
12 Gauge, 3 conductor wire with ground
Must conform to local electrical codes
Refer to
Tem- 50 - 100º F (10 - 38º C)
Cryopump Power Receptacles: mates with the
CTI-CRYOGENICS supplied cryopump power cable for single
pump use.
Mates with remote junction box power cable for multiple cry-
opump use.
1/2 in. Aeroquip self-sealing coupling
1/2 in. Aeroquip self-sealing coupling
24VAC, 2.7A inductive mates with P5 connector Type
MS3106A*
3 Years
* Supplied by CTI-CRYOGENICS
NOTE: The 9600 Compressor is designed for continuous operation and
should remain ON when the cryopumps are in a regeneration cycle.
Part Number 8040437, Revision 104, 06/12/2007, ECO Number 18068
Values
Table 4-1
1-7
