Specifications

Specifications

Dimensions

19.52 in.
(496 mm)
14.4 in.
(366 mm)
Do not place a weight greater than 75 lbs. (34Kg) on top of the
Compressor.
1-4 Part Number 8040437, Revision 104, 06/12/2007, ECO Number 18068
The dimensions of the Compressor are shown in
23.36 in.
(593 mm)
Figure 1-2: 9600 Compressor Dimensions
CAUTION
21.50 in.
(546 mm)
3.18 in.
(81 mm)
Figure 1-2.
1.28
(32mm)
