Ethernet connection option is provided by one 10/100TX Ethernet
communication port on the CPU module. Use RJ45 Cable with "Straight
Through" wiring.

3.8.2 Upload configuration to the device

Before you start, need to create a new project or open the existing one.
In addition, your project must contain at least one device and you PC
must be connected to the PM180 device by any of interfaces.
Before uploading PLC Configurator reads current Ration settings from
the device and evaluates constants that are used in the logic you want
to upload.
Please note that you must set all analog values for variables in SI
units only (V, A, W, etc.), otherwise the logic you upload will be working
incorrectly.
To upload configuration from the device do the following:
1. Click the right mouse button on a device and select "Send
configuration to the device" from padding menu.
