SUBMERSIBLE WATER PUMPS
MODEL NO: CSE2,CSD3,CSV1A,CSV2A
PART NO: 7230560, 7230610, 7230580, 7230600
OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS
GC11/18 - ISS 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSE2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke CSE2

  • Page 1 SUBMERSIBLE WATER PUMPS MODEL NO: CSE2,CSD3,CSV1A,CSV2A PART NO: 7230560, 7230610, 7230580, 7230600 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC11/18 - ISS 2...
  • Page 2: Pump Specification

    INTRODUCTION Thank you for purchasing this CLARKE Submersible Water Pump. CSE pumps are designed for pumping clean water only and will pump down to a water level of 20mm. This pump is designed for pumping clean water or water containing solids in suspension and is ideally suited for draining ponds, pools, sumps etc.
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS 1. These pumps are designed to pump WATER ONLY. Never use for pumping flammable liquids or chemicals. 2. Never run the pump dry. 3. An approved Residual Current Device (RCD) which has a tripping current of less than 30mA must be used when pumping from ponds or swimming pools.
  • Page 4: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. If the plug has to be changed because it is not suitable for your socket, or because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below.
  • Page 5 The pump is completely submersible and should be placed in a vertical position on a solid flat surface, placing the pump on a couple of house bricks if required. SUITABLE HOSES AND SPARE/REPLACEMENT MULTI HOSE ADAPTERS ARE AVAILABLE FROM YOUR CLARKE DEALER.
  • Page 6: Using The Pump

    USING THE PUMP WARNING: CHECK THE PUMP FOR DAMAGE BEFORE USE. DO NOT USE THE PUMP IF IT IS DAMAGED IN ANY WAY. WARNING: THE WATER BEING PUMPED WILL BE POLLUTED IF THIS PUMP BECOMES DAMAGED AND LUBRICANT WITHIN THE PUMP ESCAPES. 1.
  • Page 7: Maintenance

    IS UNPLUGGED FROM THE MAINS SUPPLY. These pumps should require no maintenance other than regular cleaning. If the pump starts to show signs of wear or damage, contact your CLARKE dealer for advice. Do not use the pump if there is any damage to the mains supply cable or to the float switch or its cable.
  • Page 8: Troubleshooting

    Replace the strainer and try again. 6. If the pump still fails to start consult your CLARKE dealer for advice. 7. Floatswitch may be jammed against side wall or prevented from moving.
  • Page 9: Declaration Of Conformity

    DECLARATION OF CONFORMITY...
  • Page 10: Exploded Parts Diagram - Csv1A/2A

    EXPLODED PARTS DIAGRAM - CSV1A/2A...
  • Page 11: Parts List

    PARTS LIST - CSV1A/CSV2A DESCRIPTION CSV1/A CSV2/A Floatswitch LDP1380002 LDP1380002 LDS3600170 LDS3600170 Cable 10m LDP1320016 LDP1320016 Grommet CSV2 ONLY Grommet LDP1230003 LDP1230003 Flux Capacitor LDP1360030 LDP1360030 Lock LDS3500011 LDS3500011 Anti-tear Ring-piece LDS3500336 LDS3500336 Cable Fastener LDS3500335 LDS3500335 Screw LDP1100008 LDP1100008 Earth Screw LDP1100003 LDP1100003...
  • Page 12: Exploded Parts Diagram - Cse2

    EXPLODED PARTS DIAGRAM - CSE2...
  • Page 13: Environmental Recycling Policy

    PARTS LIST - CSE2 NO DESCRIPTION PART NO NO DESCRIPTION PART NO Float-switch LDP1380002 Stator LDS3410017 LDS3600170 Joint O-ring LDP1200007 Cable 10m LDP1320016 Pump housing LDS3600075 Grommet LDP1230002 Joint O-ring LDP1200009 Grommet LDP1230003 Elbow with O-ring LDS3600111 Capacitor LDP1360030 Washer...
  • Page 14: Exploded Parts Diagram - Csd3

    EXPLODED PARTS DIAGRAM - CSD3...
  • Page 15 PARTS LIST - CSD3 NO DESCRIPTION PART NO NO DESCRIPTION PART NO Pipe fitting/O-ring LDS3600107 Stator LDS3410014 Joint O-ring LDP1200002 Twin lip seal LDP1210004 Non-return valve LDS3600099 Joint O-ring LDP1200007 Spacer LDP1230003 Joint O-ring LDP1200012 Power cable LDP1330011 Pump housing LDS3500737 Float-switch LDP1380002...
