Comtech EFData Documentation Update
Subject:
Date:
Part Number:
Related Document:
Collating Instructions:
Comments:
The highlighted change revises the connector pinout label.
Change Specifics:
3.1.1 C
ONNECTOR
205
TO
WARNING
Filename: T_ERRATA
Errata A
Revised Pin lable for Connector J3
February 12, 2007
MN/XSAT7080.IOM
XSAT-7080, X-Band Transceivers Installation and Operation
Manual, Rev. 0 dated October 21, 2005
Attach this errata sheet to the cover.
J3: AC P
OWER
240 VAC.
To avoid a serious shock hazard, correctly determine the mating
connector type in use and wire it according to the following table:
EARLY UNITS
Pin Mating Connector Type
KPT06J12-3S
MS3116J12-3S
A Line
B Ground
Labeled Neutral
C or G
, M , 100 125 VAC,
AINS TO
NEWER UNITS
Mating Connector Type
CA3106E18-22SB
Ground
Neutral
Line
1
OR
