Chapter 3. SYSTEM OPERATION

This section contains instructions for operating the XSAT-7080, X-Band Transceiver.
The Primary customer interface to the XSAT is via the Remote Communications port.
Chapter 4 provides details regarding the protocol and command/response structure used
on this interface. This chapter will define in detail the controllable parameters provided
via the command/response structure.
3.1 P -
IN OUTS
3.1.1 C
ONNECTOR
205 240 VAC.
TO
WARNING
J3: AC P
OWER
To avoid a serious shock hazard, correctly determine the mating
connector type in use and wire it according to the following table:
Early Units
Pin Mating Connector Type
KPT06J12-3S
MS3116J12-3S
A Line
B Ground
C Neutral
, M , 100 125 VAC,
AINS TO
Later Units
Mating Connector Type
CA3106E18-22SB
Ground
Neutral
Line
3–1
