EVAL-M1-05F804 User Manual
iMOTION™ Modular Application Design Kit
Main features
3
Main features
EVAL-M1-05F804is a complete power evaluation board including a 3-phase IPM for motor drive application.
The kit demonstrates Infineon's IPM technology for motor drives.
Main features of CIPOS™ Nano Intelligent Power Module IRSM005-800MH are:
•
MOSFET Drain-to-Source Voltage 40V
•
Maximum DC current at 25°C case temperature I
•
Up to 165W power output at 10 kHz PWM frequency.
•
Package with low thermal resistance and minimal parasitics
•
Independent gate driver in phase with logic input
•
Gate drive supply range from 10V to 20V
•
Propagation delay matched to defined spec
•
3V, 5V and 15V logic input compatible
•
Integrated gate drivers
•
Under-voltage lockout protection inside the driver
•
On board overcurrent protection
•
Exposed driver outputs and HEXFET gate terminals for dV/dt setting through a resistor
The evaluation board characteristics are:
•
Up to165W motor power range
•
Possibility to easy change between 3 Leg shunt to single shunt configuration
•
Compatible with the following CIPOS™ Nano module:
IRSM005-800MH
•
RoHS compliant
•
PCB is 118 x 85 mm and has two layers with 35 μm copper each
User Manual
= 80A
C
80A / 2.7mΩ, 40V
5
<Revision 1.1>
<2018-07-09>
