Device configuration

© Danfoss | July 2016
CAN Baudrate
The CAN Baud-rate refers to the rate (speed) at which data is transmitted on the network. This is typically
expressed in kilobits-per-second (kbit/s) Selecting the incorrect Baud-rate can cause erratic behavior on
the network, by default it is set to 250 Kbit/s (J1939 standard).
CAN Baud-rate selection
Feedback Mode
The Feedback Mode enables the successfully transmitted CAN Messages to be sent back to the host in
order of transmission. The Feedback Mode by default is not checked. Error status and feedback output
with timestamp are available only if Feedback Mode is checked with Timestamp Mode not Off, this
allows the transmission of error status and feedback output with timestamp.
