Appendix A – Dimensions
WS103 dimensions
WS103 dimensions (mm [in])
59.00 [02.32]
75.00
[02.95]
WS103 connectors and indicator element
©
Danfoss | July 2016
23.50 [0.925]
WS103 is equipped with the following connectors and indicator element
1
1. CAN / Power connector
2. RS232 connector
3. Power / CAN / Status LED indicator element
33.50 [01.32]
2
3
kwa1459393937324
Ø4.3
59.00
[02.32]
Ø4.3
AN00000339en-US0101 | 57
kwa1459375229783
