MCD Remote Operator
OPERATING INSTRUCTIONS: MCD REMOTE OPERATOR
Order Codes:
1. Introduction
1.1. Important User Information
Observe all necessary safety precautions when controlling the soft starter remotely. Alert personnel that
machinery may start without warning.
It is the installer's responsibility to follow all instructions in this manual and to follow correct electrical
practice.
Use all internationally recognised standard practice for RS485 communications when installing and using
this equipment.
1.2. General Description
The Remote Operator can be used with MCD 200, MCD 3000 and MCD 500 soft starters, and offers the
following functionality:
Operational control (Start, Stop, Reset, Quick Stop)
Starter status monitoring (Ready, Starting, Running, Stopping, Tripped)
Performance monitoring (motor current, motor temperature)
Trip code display
4-20 mA analog output (motor current)
Optional RS485 network connection
The Remote Operator can act as a gateway device for connection to an RS485 serial communications
network, allowing remote control of a motor from an RS485 network using Modbus RTU or standard AP
ASCII communications protocol. For further information, please refer to the Modbus Module
Instructions.
175G9004 (for MCD 200)
175G3061 + 175G9000 (for MCD 500)
175G3061 (for MCD 3000)
MG.17.E5.02 - VLT® is a registered Danfoss trademark
Introduction
Advertisement
Table of Contents
Related Manuals for Danfoss 175G9004
Summary of Contents for Danfoss 175G9004
-
Page 1: General Description
The Remote Operator can act as a gateway device for connection to an RS485 serial communications network, allowing remote control of a motor from an RS485 network using Modbus RTU or standard AP ASCII communications protocol. For further information, please refer to the Modbus Module Instructions. MG.17.E5.02 - VLT® is a registered Danfoss trademark... -
Page 2: Installation
In long cable runs prone to excessive noise interference, termination resistors should be installed between the data lines at both ends of the RS485 cable. This resistance should match the cable impedance (typically 120 Ω). Do not use wire wound resistors. MG.17.E5.02 - VLT® is a registered Danfoss trademark... - Page 3 Once the Remote Operator Module has been installed, wire between the Remote Operator and the module as follows: For the Remote Operator to accept serial commands, a link must be fitted across terminals A1-N2 on MCD 200 starters. MG.17.E5.02 - VLT® is a registered Danfoss trademark...
- Page 4 Serial Port + GND - - GND + - GND + ~/+ ~/- B8 B7 B6 B10 B11 B1 B2 B3 B6 B7 B8 4-20 mA Supply Voltage Analog Output 18~30 VAC/VDC MG.17.E5.02 - VLT® is a registered Danfoss trademark...
- Page 5 To connect the Remote Operator to an MCD 3000 soft starter: N.B.!: In order for the Remote Operator to operate correctly, the MCD 3000 must be in Local mode (set Parameter 20 = 2: Local Control Only). MG.17.E5.02 - VLT® is a registered Danfoss trademark...
-
Page 6: Specifications
This product has been designed as Class A equipment. Use of this product in domestic environments may cause radio interference, in which case the user may be required to employ additional mitigation methods. Standards Approvals ............................. IEC 60947-4-2 UL and C-UL ........................... UL 508 ............................ IEC 60947-4-2 3.2. Dimensions MG.17.E5.02 - VLT® is a registered Danfoss trademark... -
Page 7: Operation
Display Mode: Indicates the data type shown on the display: • Motor current • Motor temperature • Trip code N.B.!: When the MCD 500 is in the Quick Menu, Main Menu or Alarm Log, all three Display Mode LEDs are illuminated. MG.17.E5.02 - VLT® is a registered Danfoss trademark... -
Page 8: Trip Codes
Network communication (between module and network) Input A trip (Auxiliary input A) FLC too high (FLC out of range) Motor connection CPU error Incorrect main control module => the soft starter's LCP for trip details. MG.17.E5.02 - VLT® is a registered Danfoss trademark... -
Page 9: Programming Procedure
There is a 20 second timeout when the Remote Operator is in Programming Mode. Programming Mode will automatically close if no input is registered for 20 seconds. Any changes already made will be saved. MG.17.E5.02 - VLT® is a registered Danfoss trademark... -
Page 10: Programmable Parameters
Set Par. 6 to a value 10 times greater than the actual motor nameplate FLC (e.g. for actual FLC = 4.6 A, set Par. 6 to 46). Set Par. 9 = 1. MG.17.E5.02 - VLT® is a registered Danfoss trademark... -
Page 11: Troubleshooting
If connected to an MCD 500, check that terminals 17 and 25 to 18 are linked and the starter is in Auto On mode. Parameter 8 on the Remote Operator must be set to 0 or 1 MG.17.E5.02 - VLT® is a registered Danfoss trademark...
