button to store new Output level. Start by setting the output signal at a low level
for example 5 dBmV.

Calibrating a Fiber Node

Before you can calibrate a node, you must make sure that you have set up the Data
Carrier, Set the Node ID, and Set the Output Signal Level. See the Start-Up section of
this manual before continuing the node calibration process.
Please Note: You will need to change Node ID and Output Level at each calibration
site.

Turning Calibrator Output Signal ON and OFF

Once you have set the parameters required for node calibration (Data Carrier, Node
Number, and Output Signal Level) you will switch the output signal On so that the
Quiver can send its simulated CPD signal to the headend radar. To switch the output
signal to On, use the ∨ to highlight menu item Start or hit 4 on the numerical keypad
then press <ENTER>.
57
