AXIOMTEK SBC82610 SERIES User Manual page 56

SBC82610 Half-size All-in-One CPU Card Series User's Manual
Soft-off by PWRBTN
This only works with systems using an ATX power supply. It also allows
user to define the type of soft power OFF sequence the system will follow.
This option follows the conventional manner systems perform when power is
Instant-Off
turned OFF. Instant-Off is a soft power OFF sequence requiring only the
(default)
switching of the power supply button to OFF.
Upon turning OFF system from the power switch, this option will delay the
complete system power OFF sequence by approximately 4 seconds. Within this
Delay 4 Sec.
delay period, system will temporarily enter into Suspend Mode enabling you to
restart the system at once.
Wake Up Events
An input signal on the network 2 awakens the system from a soft-off state.
50
Award BIOS Utility
