AXIOMTEK SBC82610 SERIES User Manual page 50

SBC82610 Half-size All-in-One CPU Card Series User's Manual
USB Keyboard Support
Select Enabled if your system contains a Universal Serial Bus (USB)
controller and you have a USB keyboard. The options available are
Enabled, Disabled.
CPU to PCI Write Buffer
When this field is Enabled, writes from the CPU to the PCI bus are
buffered, to compensate for the speed differences between the CPU and
the PCI bus. When Disabled, the writes are not buffered and the CPU
must wait until the write is complete before starting another write cycle.
PCI Dynamic Bursting
This item allows you to enable/ disable the PCI dynamic bursting function.
PCI Master 0 WS Write
When Enabled, writes to the PCI bus are executed with zero wait states.
PCI Delay Transaction
The chipset has an embedded 32-bit posted write buffer to support delay
transactions cycles. Select Enabled to support compliance with PCI
specification version 2.1. The default setting is Disabled.
PCI#2 Access #1 Retry
When disabled, PCI#2 will not be disconnected until access finishes
(default). When enabled, PCI#2 will be disconnected if max retries are
attempted without success.
AGP Master 1 WS Write
When Enabled, writes to the AGP (Accelerated Graphics Port) are
executed with one wait states.
AGP Master 1 WS Read
When Enabled, read to the AGP (Accelerated Graphics Port) are
executed with one wait states.
44
Award BIOS Utility
