Zaxcom QRX235

QRX Software Update

PRESS
UPDATE SOFTWARE
The software update menu is where a firmware update for the QRX is initiated from. After the INC key is pressed
the QRX will wait for firmware to be sent from a TRX transmitter. When the QRX receives the firmware the
update process will automatically begin. Please note the QRX needs to be set to mono modulation and in single
mode to update the firmware. Please see the firmware section in the back of this manual for additional
information on updating the QRX.

AES Recognize

SONY F5 AES
OFF (NORMAL AES)
The AES recognize is used for some Sony F5 or F55 cameras that cannot recognize the AES signal from the QRX.
OFF - The QRX will output a normal AES signal.
•
ON: AB KEY - This setting will send a special signal to the AES out, when the A/B key is pressed. This will allow
•
the Sony camera to recognize and lock to the AES signal from the QRX. This is the recommended setting.
ON: ALWAYS - The QRX will constantly send a special recognize signal via the AES out.
•

AES Output Sample Rate Adjust

AES OUTPUT RATE
NORMAL
This menu adjusts the AES output sample rate.
NORMAL - This is the recommended setting.
•
96K - The QRX will output a 96 kHz AES signal for some mixers like the Yamaha 01V that cannot properly
•
sample rate convert the AES signal.

LED Brightness Set

LED DIMMER:
OFF
This menu sets the brightness level of the side mount LED's.
OFF - The LEDs do not illuminate.
•
NUMERIC VALUE - Adjustable brightness levels.
•
BRIGHT - The LED's will illuminate at the brightest setting.
•
TO
14
Extended Menu
