Extended Menu

Navigating the Extended Menu

Press and hold the DEC key from the home screen to enter the extended menu.
•
To advance to the next menu press the MENU key.
•
Press and hold the MENU key at any point to return to the top of the extended menu.
•

Exiting the Extended Menu

To exit the extended menu - press the POWER key briefly.
•

Modulation Select

RX FMT: ZHD96
From this menu the modulation mode is selected. Modulation is simply the way a transmitter "modulates", or
sends, its signal to the QRX235. This setting needs to match the modulation mode that the corresponding
transmitter is set to - if the two setting do not match the QRX will not be able to receive and decode the signal
from the transmitter. Please note the QRX will need to be rebooted after a change is made to the modulation.
Modulation Bandwidth
Minimum Channel to Channel Spacing
6 MHz TV Channel Capacity
Latency
Compatibility with a 235 Series Receiver
Compatibility with a 300-96 Receiver
Compatibility with a 300-48 Receiver
* When used with a QRX300-96 receiver – the minimum spacing is 300 kHz when using all other receivers.
**When used with a QRX300-48 receiver – the minimum spacing is 235 kHz when using all other receivers.

Single / Dual Mode Select

RX MODE:
SINGLE
SINGLE - This configures the QRX to operate as a single receiver. In single mode the QRX can receive one audio
•
channel from one transmitter.
DUAL - This configures the QRX to operate as two independent receivers. In dual mode the QRX can receive
•
audio from two transmitters.
STEREO MONO
235 kHz 235 kHz
400 kHz 400 kHz
15 15
6ms 3.5ms
2 Transmitters 2 Transmitters
NO NO
NO NO
11
XR ZHD 96
235 kHz 96 kHz
400 kHz 235 kHz*
15 30
6ms 6ms
2 Transmitters 2 Transmitters
NO 1 Transmitter
NO NO
Extended Menu
ZHD 48
48 kHz
100 kHz**
60
18ms
1 Transmitter
1 Transmitter
1 Transmitter
