Time Code Mute Time Set

TCJAM MUTE TIME:
0MS (DEFAULT)
Time code jam mute sets the length of time that the time code output is muted whenever a time code jump is
detected. So if there is a change in time code the time code out of the QRX235 will be muted for the time set in
this menu. This simulates removing the time code completely from a device and plugging it back in so that the
receiving device recognizes that there is new time code. This was added to help the RED camera jam its time code
properly. In the case of a Red camera this would normally be set this to 1000MS.

Audio Delay Set

AUDIO DELAY:
OFF
This menu delays the IFB audio that is broadcasted via ZaxNet. This is useful when a delay is needed so the audio
feed can match the video dely. The adjustable range is from 5 to 400 MS in 5 MS increments.

ZaxNet Output Enable

ZAXNET OUTPUT:
OFF
The QIFB time code output on the 3.5mm connector can contain ZaxNet commands to communicate to other
Zaxcom products. This menu enables / disables the QIFB to output the embedded commands that is within the
time code. If the time code output is not connected or feeding another Zaxcom device this should be set to OFF.

IFB Transmit Power Level Set

This menu is only available when the IFB MODE is set to is to transmit (TX)
IFB TX POWER: 7
The IFB transmit power of the QIFB ZaxNet transmitter is set from this menu. The power range is 0 through 7
with 7 being the highest.

Send Record Commands

ALWAYS SEND REC
COMMANDS: OFF
This menu is enables the QIFB to send record commands to the transmitter. To have the ability to start and stop
the transmitters recording feature this needs to be set to ON.
