Zaxcom QRX235

Time Code Connector - 3.5mm

Time Code in to QRX

Time Code out of QRX

IFB Audio Connector - 3.5mm

Same wiring is used for both input and output
3.5 mm Connector
TIP
RING
SLEEVE
3.5 mm Connector
TIP
RING
SLEEVE
3.5 mm Connector
TIP
RING
SLEEVE
TC Connector
NO CONNECTION
SIGNAL
GROUND
TC Connector
SIGNAL
NO CONNECTION
GROUND
Connector
LEFT
RIGHT
GROUND
30
Wiring Diagrams
