Zaxcom QRX235

Frequency Scan

PRESS
The frequency scan menu is where the QRX can scan and search for a clear frequency. After the scan is
complete a graphical display of the RF that is present, in that specified range will be shown and the QRX235
will suggest a clear frequency. That frequency can be accepted by pressing the INC key. Or press the DEC key
to skip the first chosen frequency and have the QRX235 suggest another frequency.

Single mode scanning

Turn off the transmitter.
•
Press the INC key to initiate a scan.
•
As the block is being scanned, the frequency being examined is
•
displayed on the bottom half of the screen and a graphic map of the
RF that is found will be displayed with a vertical line extending up from
the baseline. The length of the line indicates the level or strength of
the found RF at that frequency.

Selecting a frequency

When the scan is complete a suggested frequency will be shown and a
vertical blinking line will be drawn on the display.
At that point:
Press the INC key to accept the frequency.
•
Press the A/B key or the DEC key to suggest another frequency.
•

Dual mode scanning

Turn on the first transmitter and set it to the chosen frequency.
•
Press the A/B key to scan the B receiver.
•
Press the INC key to initiate a scan.
•
Select the second frequency the same way the first frequency was
•
selected.
TO SCAN
10
Main Menu
SCANNING 568.9
TAKE 578.2
