IFB Input Mix Assign

IFB INPUT MIX:
QRX ONLY
The IFB mix assign sets what audio will be broadcast via ZaxNet. That audio can be used for return confidence
monitoring and or as an audio feed to ERX receivers. Any combination of the UHF receive audio or the audio
inputted via the audio in connector can be selected.
Please note the "QRX" audio is set in the IFB output mix menu located in the extended menu.
RIGHT + QRX - Sums the right IFB audio input with the QRX mix.
•
LEFT + QRX - Sums the left IFB audio input with the QRX mix.
•
L + R + QRX - Sums both IFB audio inputs and the QRX mix.
•
L - R + QRX - Sums the difference of the left and right IFB audio inputs plus the QRX mix.
•
QRX ONLY - QRX mix only (set in the IFB output mix menu).
•
RIGHT - The right input of the IFB audio connector only.
•
LEFT - The left input of the IFB audio connector only.
•
L + R - Sums the left and right IFB audio inputs.
•
L - R - Sums the difference of the left and right IFB audio inputs. This effectively makes the IFB audio input a
•
balance connection.
Please note that ZaxNet transmitted audio is mono so all audio selected will be summed to mono.
