4 Printing self-adhesive label with "plusoptiX P12" (optional
accessory)
After confirming the entry or the anonymous measurement, a print job for label printing is
sent via the infrared interface and a measurement report is saved to the inserted SD card
(plusoptiX A12) or USB stick (plusoptiX A16) at the same time.
To print a self-adhesive label, you just need to hold the camera towards the "plusoptiX P12"
label printer to print a self-adhesive label. The "plusoptiX P12" prints self-adhesive labels on
heat-sensitive paper (i.e. no printer cartridges are required). It is battery-operated and has an
infrared interface.
Device
Note:
You can find information about operating the "plusoptiX P12" in its user manual.
This can be downloaded from our homepage (www.plusoptix.com).
Name or ID
OD
measurements
Referral criteria
and software
version
Interface

Figure 8: Printing self-adhesive labels

First name Last name *12/31/2013
OD
-1,50 dpt Sphere
-1,50 dpt Cylinder
176° Axis
6,6 mm Ø Pupil
Pupil distance
Gaze asymmetry
Ver. 7.1.1.0
www.plusoptix.com
Figure 9: Self-adhesive label
(74 mm x 49 mm)
Seite 10 von 10
Data file
Recipient
Date of birth
OS
-3,25 dpt
-2,25 dpt
4°
6,8 mm
measurements
56 mm
1,5 °
Date of
10/06/2018
measurement
OS
