3-11.3.2.
Feed Pump.
a.
Inspect check valve (24, FIGURE 3-7) seats for wear or damage. If defective, replace check valve.
b.
Check piston (29) for damage or cracks. If defective, replace piston.
c.
Check tappet (31) rollers, bushing, and pin for excessive wear, flaws, or peeling. If defective, replace tappet,
refer to FIGURE 3-26.
FIGURE 3-24. Camshaft Bearings
FIGURE 3-25. Bearing Removal
ARMY TM 9-2815-254-24
AIR FORCE TO 38G1-94-2
3-47
