Easidew Online User's Manual
A.1

Dimensions

FRONT VIEW
Easidew Online
OVERLAY
Michell Instruments
132mm
(5.19")
ø27mm
10mm
(0.39")
(1.06")
Transmitter
1/8" NPT
55.2mm
1/8" NPT
2.2"
48mm
(1.9")
96mm
(3.7")
94mm
(3.7")
Hygrometer
46mm
(1.8")
Figure 33
46mm
(1.81")
5/8" 18 UNF
10mm
(0.39")
5/8" Bonded Seal
5/8"-18 UNF
Sample Block
76mm
(3")
SIDE VIEW
10.5mm
(0.41")
TOP VIEW
Monitor
Dimensions
APPENDIX A
ø25.4 x 2mm
(ø1 x 0.07")
5/8"-18 UNF
44mm
(1.73")
92mm
(3.6")
47
