INSTALLATION

2.3

Easidew Transmitter

NOTE: The transmitter's sensing element is shown for illustration purposes

only. Please keep the HDPE or SS guard ﬁ tted at all times, if possible.

Easidew Online User's Manual

Sensing Element

Process Connection

Hexagonal Nut

Transmitter Label

Transmitter Cover

Electrical Connector

Easidew Transmitter

Figure 7

97094 Issue 18.5, March 2016
