XPM601 User Manual
A.1 Dimensions
11.5 mm
(0.45")
12 mm
(0.47")
BREATHER
(DO NOT OBSTRUCT)
GAS IN
35 mm
(1.38")
NOTE: Fixing mounts are NOT symmetrical. This is to ensure correct
orientation.
Michell Instruments
O 234 mm
(9.21")
195 mm
(7.68")
172 mm
(6.77")
171 mm
(6.73")
15 mm
(0.59")
M20 CABLE ENTRIES (3)
EARTHING POINT
35 mm
(1.38")
Figure 32 XPM601 Dimensional Drawings
4 X O 9 mm
(0.35")
GAS OUT
APPENDIX A
172 mm
(6.77")
15 mm
(0.59")
39
