  • Page 1 User Manual Lock Cylinder C10S/P iLOQ 2.5.2013 Operation, Maintenance and Installation instructions for iLOQ Lock Cylinders C10S/P info@stedaparts.nl www.stedaparts.nl...
  • Page 2 Table of content Operation instructions......................2 Maintenance instructions .....................2 Installation instructions......................3 info@stedaparts.nl www.stedaparts.nl...
  • Page 3 Do not use force when inserting a key into the cylinder. Warning Do not insert anything else than the iLOQ Key K10S/P into the cylinder. The product should not be modified in any way expect in accordance with those modifications described in the instructions.
  • Page 4 These instructions should be carefully followed during installation. Use appropriate cylinder type according the installation environment: C10S.1 for outdoor use and C10S.10 only for indoor use where temperature and humidity are equivalent to normal indoor conditions. Use Scandinavian oval cylinder compatible lock cases.
  • Page 5 Align the cylinder front with the escutcheon front. Use appropriate height of the escutcheon and/or adjust the cylinder height using an extension piece. A cylinder extension piece iLOQ A10.33 must be used between the cylinder and the lock case in case of the cylinder height adjustment is necessary. When using the extension piece, also use appropriate longer tail piece.
  • Page 6 For high security purposes, use iLOQ escutcheons E10.D1, E10.D3, E10.E1, E10.E2 or E10.E8 to meet attack resistance grade 2 according standard EN15684. In harsh environment where the cylinder is exposed to a dust or long term salt water spatter use a weather cover such as iLOQ E10.D3 escutcheon with a lid.
