- Page 1 D50S.XXX(A).SD EUROPROFILE LOCK CYLINDER MOUNTING AND CARE INSTRUCTIONS USER GUIDE iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •...
-
Page 2: Table Of Contents
10. INSTRUCTIONS FOR USE .............. 10 11. GENERAL NOTES ................11 12. DECLARATION OF CONFORMITY ..........11 iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •... -
Page 3: Before Installation
Test the cylinder functionality after installation to ensure that it doesn’t prevent the lock case from working properly. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •... -
Page 4: Care
A. Ensure the cam is pointing downwards. Slide the lock cylinder through the lock case. B. Fix the cylinder into the lock case using an iLOQ fixing screw A10.64. If necessary, cut the screw. Use a tightening torque of 0.9...1.1 Nm. Make sure the cylinder frame is a maximum of 1.0 mm from the door leaf or escutcheon. -
Page 5: Installation Of Iloq D50S.2Xx(A).Sd Series
1.0 mm from the door leaf or escutcheon. Fix the cylinder into the lock case using an iLOQ fixing screw (A10.64). If necessary, cut the screw. Use a tightening torque of 0.9 … 1.1 Nm. -
Page 6: Installation Of Iloq D50S.3Xx(A).Sd Series
1.0 mm from the door leaf or escutcheon. D. Fix the cylinder into the lock case using an iLOQ fixing screw (A10.64). If necessary, cut the screw. Use a tightening torque of 0.9…1.1 Nm. -
Page 7: Installation Of Iloq D50S.7Xx(A).Sd Series
A. Ensure the cam is pointing downwards. Slide the lock cylinder through the lock case. B. Fix the cylinder into the lock case using an iLOQ fixing screw A10.64. If necessary, cut the screw. Use a tightening torque of 0.9...1.1 Nm. Make sure the cylinder frame is a maximum of 1.0 mm from the door leaf or escutcheon. -
Page 8: Cylinder Extensions
A. Remove the three body fixing screws with a Torx T6 tool. B. Take the lock unit apart. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •... - Page 9 F. Fix the lock unit onto the cylinder using 3 fixing screws with a Torx T6 tool. G. Tighten the screws. Use a tightening torque of 0.55…0.65 Nm. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •...
-
Page 10: Instructions For Use
2. Turn the lock-reader knob to unlock the door. 3. Open the door. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •... -
Page 11: General Notes
The key is to be kept securely so that only authorized person may have access. In case of losing a key, blocklisting of the lost key shall be done with the iLOQ Manager software and affected locks shall be reprogrammed.
