13 SCANNING / ERASING IMAGING PLATES

User's & installation manual
13 SCANNING / ERASING IMAGING PLATES
NOTE
The imaging plates must be removed from the
hygienic bag for scanning. To prevent the plates
from being exposed to light remove the plate
from the hygienic bag right before placing it onto
the tray. If there is a protective cover on the
imaging plate also remove the cover.
NOTE
In shared use (N-to-N mode) images of one
patient cannot be scanned on different scanners
at the same time.
1. Open the Planmeca ProScanner imaging
window in Planmeca Romexis 2D module (if not
already open).
When the following screen appears the scanner
is ready for scanning and the imaging plate can
be placed on the tray.
2. Place the imaging plate towards the front and
centre of the tray with the active (blue) side up.
The following two images illustrate the
positioning of the imaging plates.
incorrect
Planmeca ProScanner 37
