11 CAPTURING IMAGES WITH PLANMECA PROSCANNER

11 CAPTURING IMAGES WITH PLANMECA
PROSCANNER
12 READING IMAGING PLATES WITH PLANMECA
ProID READER
36 Planmeca ProScanner
For detailed instructions on how to capture
ProScanner images see Planmeca Romexis
User's manual (publication number 10014593)
When the scanner is shared between several
treatment rooms the imaging plates must be
read in the treatment room with the Planmeca
ProID reader before scanning.
The Planmeca ProID reader identifies the serial
number of the plate. The serial number is used
to automatically route the images to the correct
patient file.
NOTE
Select the patient and open the Planmeca
ProScanner imaging window in 2D module
before proceeding to reading.
1. Open the Planmeca ProScanner imaging
window in Planmeca Romexis 2D module.
2. Show the imaging plate to the Planmeca ProID
reader.
When the imaging plate serial number has been
recognized the serial number appears on the
Planmeca Romexis Imaging window (see
Planmeca Romexis 2D User's Manual).
3. When all imaging plates have been read leave
the imaging window open and proceed to
exposing of the plates.
NOTE
Never close the imaging window before all
images have been scanned.
4. Scan the plates as described in section 13
"SCANNING / ERASING IMAGING PLATES" on
page 37.
