8 SYSTEM DESCRIPTION

8.1 USB or direct 1-to-1 Ethernet

Planmeca
ProScanner
100 - 240 VAC
User's & installation manual
The Planmeca ProScanner systems consists of
a scanner, Planmeca Romexis computer, and
an optional Planmeca ProID RFID reader. The
scanner can be connected to the computer via
Ethernet or USB cable.
NOTE
N-to-N Ethernet mode and 1-to-1 Ethernet mode
cannot be used in the same network at the same
time.
Planmeca ProScanner is attached to the PC
using direct USB or Ethernet connection.
Crossed Ethernet cable must be used.
USB cable Max. 2m
Ethernet cable Max. 2m
CAT.5E, RJ45 FTP Cross Type Cable
8 SYSTEM DESCRIPTION
Romexis PC
Planmeca ProScanner 13
