Digital Watchdog MEGApix DWC-MV72Wi28A User Manual page 26

Setup - Video & Audio Setup
Video Configuration
6 GOP(Group of Pictures) Size
Set up the number of frames (P-frame) which contain only
changed information based on basic frame (I-frame).
Regarding videos with lots of movement, if you set GOP size
bigger, only the number of P-frames is bigger. As a result,
video resolution will be low but 'File size' and 'Bit-rate can
be decreased.
GOP(Group of Pictures) Size is..
I-frame and P-frame can be created for MPEG4 and H.264 video
compression. I-frame(=key-frame) means the whole image data
been changed information compared to I-frame GOP is made up
of one I-frame and corresponding several P-frames. To improve
video quality, set the number of P-frames smaller and to decrease
image size, set the number of P-frames bigger.
7
H.264 stream, including color reproduction and additional
video compression.
Baseline
Main
High
Smart Bitrate Control
8
You can not use the Smart Bitrate Control function.
CVBR (Framerate priority)
This Mode is for cameras which do not want absolute any
frame drop, but still want to get lower bitrate. It has
limitation when the Target bitrate is set to be very low,
but actual motion is big or scene is very noisy.
CVBR (Quality priority)
When the Target bitrate is set to very low, and motion is big,
be lower, so that it can save its and make the output frames
to have better quality.
CBR
This Mode is a CBR alike mode which is close to traditional
security IPCAM, and it's not designed for LBR, It's provided
as an option in LBR library just to help comparison.
2
6
7
8
