Option 2: Pole Mounting ~ Fasten the Chameleon Module to the Pole

5
5 5
Chameleon Stand-alone Module
7
A
Half Pole Clamp
Optionally, you can cut the clamp bolts to suitable lengths after fastening them
(steps 6 and 7).
Quick Installation Guide • Chameleon 48V, 650W, HE, IP65, Stand-alone Module
3 3 3
1
(Top View)
Pole
B
6
A=B
OK
Mechanical Installation
Pole
Half Pole Clamp
Half Pole Clamp
5
5 5
WARNING:
Both bolts tightening a half pole
5
5 5
clamp pair must be screwed almost at
the same time and the same length,
maintaining the half pole clamps par-
alleled while fastening
Chameleon Stand-alone Module
(Top View)
A
A≠B
NOT OK
2
3
3 3
CW
M5 (4x)
T-IW
T2
4
B
7
!
