Block Diagram Chameleon Stand-alone Power Supply Module
AC Fuses,
external
AC Input
(230V 1x phase)
Dimensions Chameleon Stand-alone Module
Panel Mount
Connectors
Chameleon Stand-alone Module
Part 241125.105 (2.8Kg, H=320.6)
Part 241125.185 (2.8Kg, H=320.6)
Part 241125.155 (3.6Kg, H=450.0)
4
Quick Installation Guide • Chameleon 48V, 650W, HE, IP65, Stand-alone Module
Chameleon
48V, 650W, HE
Stand-alone Module
Alarm
Relay
C-NO
CAN bus
All dimentions in mm (not in scale)
Telecom &
Industrial
Equipment
(Load)
DC Output
(48V)
(Ref. Doc# 2175763, v1.0)
•••
