Electrical Installation
Pinout ~ Panel Mount Connectors
Input Connector
PE
3
L2
2
L1/N
1
(not connected)

Location of Terminals ~ Cable Connectors

3
L2
2
L1/N
1
(Not
Connected)
Connector,
A (Part 343665)
For torque reference T3, T4, read
10
Quick Installation Guide • Chameleon 48V, 650W, HE, IP65, Stand-alone Module
Pinout
Panel Mount
(not connected)
Chameleon Stand-alone Module
AC Mains
Input
Terminals
Flat 2.5mm
T3
Cable
female
"Tools & Torque Recommendations" on page 3
Pinout
Panel Mount
Output Connector
2
—
-48VDC
6
AL-NO
5
AL-C
3
CAN H
Contacts
shown with
de-energized
CAN L
coil (Alarm
5
condition)
AL-C
DC Load
Output
6
Terminals
AL-NO
Flat 2.5mm
T4
1
+
0VDC
1
+
0VDC
Contacts
shown with
de-energized
coil (Alarm
condition)
4
CAN L
4
3
CAN H
2
—
-48VDC
Insert, male
with Coupling Ring
Sleeve
with Pinch Ring
Seal Ring
Pressing Screw
Seal
Ring, SR1
Cable
Connector,
Seal
male
Ring, SR2
F (Part 343667)
•••
