Connections
Switch OFF External Fuses
WARNING:
For outdoor applications where the product may be subject
to transient overvoltages exceeding those for Overvoltage
Current Surge
Protection
Category II, an AC Overvoltage Protection Device (OVP)
complying with IEC 61643-series must be installed on the
AC supply. This device will reduce the overvoltages to levels
corresponding to Overvoltage Category II
!
WARNING:
The other ends of the AC input and DC output cables must be terminated in a protected box or plug of at least IP 65
Device
rating, or in an indoor environment
Hazard
Electric Shock
10 min.
Quick Installation Guide • Chameleon 48V, 650W, HE, IP65, Stand-alone Module
1
Switch
2
Switch
WARNING:
Hazardous voltages may be present inside the Chameleon module, Part # 241125.155, as long as 10
minutes after it is switched OFF (discharge time)
Electrical Installation
U2a
U5
A1
OFF
external AC Mains MCBs/Fuses
OFF
external Load MCBs/Fuses
Power is OFF!
CAUTION:
Suitable for connection to IT networks
For installations in USA and Canada only!
The installation has to comply with the
NEC/CEC requirements
!
11
